Assembly Instructions
CM7106BL
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
DIFFICULT
EASY
2 PERSONS RECOMMENDED
Page 1 of 9
Rev.14-07-10
Advertisement
Related Manuals for Furniture of America CM7106BL
Summary of Contents for Furniture of America CM7106BL
- Page 1 Assembly Instructions CM7106BL ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some products, two persons are recommended.
- Page 2 Thank you for your purchase! We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase.
- Page 3 Page 3 of 9...
- Page 4 Parts List #1 x 1 pc #2 x 1 pc Left Top Panel Right Top Panel #3 x 1 pc #4 x 1 pc Left H/Board Side Right H/Board Side #5 x 2 pcs #6 x 2 pcs Sign Handle #8 x 1 pc #7 x 1 pc Right F/Board Side...
- Page 5 Before you begin, please read Page 3 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Hardware List #A x 18 pcs #B x 16 pcs Bolt M6x10 Bolt M6x15 #C x 14 pcs #D x 6 pcs Bolt M6x25 Bolt M6x30...
- Page 6 Due to the size and/or weight of this product, it is highly recommended that the assembly should be done near the area of its intended location. Make sure you have enough space to move around during the assembly. ALWAYS have at least two people to help with transporting and assembling the product to avoid any potential injury and/or damage.
- Page 7 #A x 4 pcs #B x 2 pcs #L x 2 pcs Turn right (clockwise) to tighten #C x 2 pcs #E x 2 pcs #F x 2 pcs #G x 1 pc Turn right (clockwise) to tighten Page 7 of 9...
- Page 8 #C x 4 pcs #E x 4 pcs Turn right (clockwise) to tighten #A x 4 pcs #B x 6 pcs #C x 4 pcs #D x 2 pcs #H x 8 pcs Turn right (clockwise) to tighten Page 8 of 9...
- Page 9 #B x 8 pcs #I x 16 pcs Turn right (clockwise) to tighten #K x 8 pcs Safety is ALWAYS the main priority. For extra safety measure and before using the bed, please take the time to inspect the assembly again and make sure that ALL bolts and screws are FULLY tightened.
