Diagnostics

For routine measurements the
actual measurements that go into the Measure screen the
is invaluable, especially for troubleshooting and for setting values in the
Configuration screen.
With the measure screen open, click on the little waveform icon on the upper
right of the Measure screen or select
upper left. This will bring you to the
the right the probe is 16" with 16 elements. The same color coding applies to
the Diagnostics screen but with the addition of sensor elements, height from
the bottom sensor and the values of each element—actual frequency and
scaled frequency (0 to 10,000).
Immersing the probe in an actual interceptor or a container with water and
oil will show a screen like the one on the right.

7 Troubleshooting

As with any sophisticated electronic device undergoing beta testing,
issues arise that need to be improved. The major hardware issue that
we have discovered is that the ribbon cable that connects the
electronic guts of the probe to the controller in the black enclosure
can come loose with rough handling. If the probe connects but
doesn't show a bar graph like in the figures above it's a 20:1 bet that
the ribbon cable came loose.
Simply unscrew the top of the enclosure. The ribbon cable slips over
If problems persist contact us at
AM-FOG Operating Manual
Measure screen is sufficient. To view the
Diagnostics from the menu icon in the
Diagnostics screen. For the screenshot on
the connector on the board such
that the one gray conductor
connects to the Power pin. See
picture below. It's possible, but unlikely, that the ribbon disconnects
from the other end that connects to the sensors in the probe.
Reattach as shown in the picture below.
support@wateranalytics.net
8
Diagnostics screen
or call us at 978-749-994.
