- Page 1 DVR-4N DVR-8N DVR-16N 4/8/16 Camera DVR INSTRUCTIONS PRESET " ' SLOW SPOT FUNCTION AUTO FREEZE COPY SEARCH LIVE/PB STANDBY ALARM RX/TX RESET PLAY MULTI CAMERA / NUMBER INPUT FAST PLAY/ PAUSE MENU D-ZOOM STATUS HOME...
- Page 2 WARNING This symbol is intended to alert the user to the presence of unprotected “Dangerous voltage" within the product's enclosure that may be strong enough to cause a risk of electric shock. This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- Page 3 All the safety and operating instructions must be read before the unit is operated. • Make sure to switch the power off before you install the DVR. • There is the danger of an electric shock if the DVR is opened by an unqualified service engineer or installer.
-
Page 4: Table Of Contents
INSTALLL THE INTERNAL HARD DISK DRIVE(S)..81 CHAPTER 9 NETWORK VIEWER... 82 INSTALLATION OF NETWORK VIEWER SOFTWARE ... 82 CONNECTING TO DVR... 82 DVR Search ... 84 HDD Search ... 84 File Search ... 85 ARRANGE THE SCREEN ... 85 Option... -
Page 5: Features
Remote control on a networked PC with the exclusive client viewer (The viewer software is supplied for free.) Flexible connections - 10/ 100 Mbps Ethernet/ ADSL Up to 16 network users access simultaneously Audio transmission between DVR and Client Dynamic IP is available... - Page 6 FEATURES Audio 4 channels audio recording in real time Copy USB 2.0 external HDD USB 2.0 memory stick CD-RW/ DVD-RW (option) General Software downloading facility via network and USB memory stick Auto detection of PAL / NTSC Built-in hardware Watchdog Automatic time adjustment through Network VGA output for PC monitor(Option) Optional Removable HDD,CD-RW or DVD-RW...
-
Page 7: Packing Detail
PACKING DETAIL Packing Detail Chapter 2 2. Network Viewer Program CD 5. R-HDD Rack Key (option) 1. DVR 2. Network Viewer Program CD 3. User’s Manual 4. Remote Controller 5. R-HDD Rack Key(option) 6. Power Cord 7. Batteries F(-) F(+) -
Page 8: Location And Control
LOCATION AND CONTROL Location and Control Chapter 3 3.1 FRONT PANEL CONTROLS 1 SPOT / ESC Button to control spot monitor/ return to the previous menu 2 FUNCTION Using this button when you select “USER” in Relay 4 3 AUTO / F / ( - ) Button to begin the auto sequence mode/ decrease the value/ focus in PTZ mode Display of the status of power(STANDBY), HDD(HDD) , network(RX / TX),REC,P 4 LED Display... -
Page 9: Rear Panel Connectors
BNC output port for the main monitor 12 VIDEO OUT(Option) (Same as the RCA video output of the front panel) Connector for debugging. This DVR can be controlled by the other device 13 S-VIDEO OUT through this connector(RS-232C). 14 SERIAL... -
Page 10: Installation
INSTALLATION Installation Chapter 4 4.1 TOTAL CONNECTION LAY-OUT... -
Page 11: Individual Connection
INSTALLATION 4.2 INDIVIDUAL CONNECTION 4.2.1 Camera * Connect a female BNC connector of each camera to a male BNC connector, “CAMERA IN” port. * Connect the looping BNC output to other inputs as required. - Page 12 - AUDIO OUT : Connect the RCA Line output to a monitor with a built-in speaker. NOTE This DVR can be connected only with a line audio and not support a microphone for audio input and output. To record audio should be enable in the AUDIO setup at the MENU setup.
- Page 13 INSTALLATION 4.2.3 Monitor - Connect the female BNC for monitor output. - Connect the male Y/C cable socket for S-VID .2.4 Power - Auto-detect the correct voltage of power (110~240 VAC) - Connect the power cord. EO monitor output. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING:...
- Page 14 2. Most CD-RW disks are compatible using CD-RW device, problem occurs only to some brands. Therefore, when data is unable to be achieved from the CD-RW DVR, please try again using other brand CD-RW disks. 3. When compatibility problem occurs using DVD-RW device, please try again using other...
-
Page 15: Operation
OPERATION Operation Chapter 5 5.1 FACTORY DEFAULT MENU Setup> QUICK SETUP> QUICK SETUP…………………………..………OFF IMAGE SIZE………………………………………720x240 RECORD FRAME…………………………………60 EVENT……………………….…..…………...ALL PRE RECORD TIME……….……………………..5 sec POST RECORD TIME………………………..…..10 sec IMAGE QUALITY.. ………………………………FINE AUDIO RECORD ………………………………….OFF REMOTE CONTROL ID.…………….………..… ..ALL SCREEN> POSITION HORIZONTAL POSITION………………….0 VERTICAL POSITION.……………………..0 AUTO SEQUENCE QUAD-A~E/ SIX/ SEVEN/ NINE-A~B/... - Page 16 OPERATION ADD SPOT MULTI……………………………...OFF RECORD> RECORD SETUP RECORD PROGRAM..………………….……...6 RECORD PROGRAM (Refer to page 52) IMAGE QUALITY RECORD QUALITY……………………….……...FINE AUDIO RECORD AUDIO 1………………..…………………….…... OFF AUDIO 2………………..…………………….…... OFF AUDIO 3………………..…………………….…... OFF AUDIO 4……………..……………………….…... OFF REPEAT RECORD REPEAT RECORD..………………………………..ON REPEAT RECORD ALARM.…………………..…..5% PLAY MODE.…………………………………….……...FRAME BACKUP MODE..……………………………….……...OFF HOLIDAY...
- Page 17 OPERATION REC/PLAY CHECK…..………………….……………...…OFF VIDEO STANDARD…………….…………………………..AUTO LANGUAGE……………….………..………………….…….ENGLISH REMOTE CONTROL ID.…………….………..…………….ALL KEY ECHO…..………………….……………………………ON DVR INITIALIZE.………………….………..………………..NO FIRMWARE UPGRADE………………….…………………NO LINK> NETWORK DHCP……..……………………………………………OFF RS-232 BAUD RATE..………………….……………………..115200 DATA BIT……..……………………………………….8 PARITY BIT….……..…………………………………NONE STOP BIT……..……………………………………….1 RS-422/485 SYSTEM ID……..…………………………………….1 OUTPUT MODE.…………………………………….RS-485 BAUD RATE..………………….……………………..115200 DATA BIT……..……………………………………….8 PARITY BIT….……..…………………………………NONE STOP BIT……..……………………………………….1 CH 1~16: MODEL/ ID….………………….……...
-
Page 18: Front Panel Controls
OPERATION 5.2 FRONT PANEL CONTROLS 5.2.1 POWER ON/ OFF SWITCH(located in rear panel) After the connection of power cord and other devices(HDDS) with this DVR, turn the power on. a. The video signal system (NTSC or PAL) is automatically detected. - Page 19 OPERATION Use the +10 Button when you select two digit camera numbers. EX) Camera Number 12 = Press the +10 Button, and then press the No. 2 Button. CAMERA/NUMBER INPUT buttons are used to input the password in the password lock function. 5.2.2.2 Auto Sequence Display <ADD AUTO SINGLE : ON>...
- Page 20 OPERATION 5.2.3 RECORD Press the REC button and the following message will be displayed as below; MANUAL MODE Press the REC button to begin recording. To stop recording, press the REC button again. The screen will be turned into real time display mode.
- Page 21 OPERATION 5.2.4.1 CALENDAR SEARCH At the SEARCH menu; ① Move the cursor to CALENDAR SEARCH using ② Press the ENTER button and CALENDAR SEARCH screen appears. ③ Select the desired HDD ID using the (-) or (+) button. ④ Move the cursor to CHANNEL using the (-) or (+) button.
- Page 22 OPERATION 5.2.4.2 SEARCH & COPY At the SEARCH menu; ① Move the cursor to SEARCH & COPY using ② Press the ENTER button and SEARCH & COPY screen appears. ③ Select the desired HDD ID using the (-) or (+) button. ④...
- Page 23 Press the ALARM RESET button to remove this signal. - When the unit receives a signal from the sensor input, DVR begins to record the input data according to the PRE/POST TIME in the RECORD setup and the details will be listed in the EVENT LIST.
- Page 24 OPERATION ③ Select the desired HDD ID using the (-) or (+) button. ④ Move the cursor to the desired position of SEARCH TIME using the then set up the desired time using the(-), (+) buttons. (Or turn the wheel scroll of mouse to search the block list.) ⑤...
- Page 25 OPERATION ③ Press the ENTER button, and the list searched appears. ④ When the list appears on the screen, select the desired list using of mouse ⑤ Press the ENTER button for the playback. <H ow to mak e Bookmark list> ①...
- Page 26 OPERATION 5.2.5 SEARCH BUTTON INFORMATION ○ ○ .1.5.1 SLOW ( Press this button to make th e speed level which is slower than normal speed (X1) and displayed it at the upper left side of screen as below; (If you press this button again, the playb speed level) 1/2 - 2 times slower than normal playback speed...
- Page 27 In the MENU setup, below buttons can be used : Press this button to modify the setup value. SHUTTLE RING JOG DIAL image while the DVR is in the playback mode. hen press the PTZ button. f PTZ. value in MENU setup.
- Page 28 OPERATION 5.2.7 DIGITAL ZOOM ① Press the desired camera number button you wish to display on the monitor. ② Press the D-ZOOM button. The indication screen appears on the main screen. ③ Turn wheel scroll of mouse or press the ④...
- Page 29 OPERATION ** Please refer to 6.2.7 SPOT of SCREEN 5 .10 COPY Press the COPY button to copy the recorded images into other media and the COPY MENU screen appears. .2.10.1 COPY .2.10.1-1 COPY TO EXTERNAL HDD (USB) At the COPY menu, ①...
- Page 30 “COPY 30%”) will be displayed on the right side of the monitor. You can search and playback the copied images in HDD with DVR itself (Please refer to 5.2.4.6 FILE SEARCH, page 23.) ** You have to format in case of the media to be .2.10.1-2 COPY TO USB memory stick...
- Page 31 When the copy is in process, the copying status(ex. “COPY 30%”) will be displayed on the right side of the monitor. You can search and playback the copied images in USB stick memory with DVR itself as well as PC. (Please refer to 5.2.4.6 FILE SEARCH, page 23.) 5.2.10.1-3 COPY TO CD-RW/ DVD-RW...
- Page 32 - If you want a built-in CD-RW or DVD-RW, must purchase it from a authorized dealer. - You can search and playback the copied images in CD or DVD with DVR itself as well as PC. (Please refer to 5.2.4.6 FILE SEARCH, page 23.) ** You have to format in case of the media to be used in DVR for the first time.
- Page 33 NOTE If you don’t connect any media device, you can see the message, “Fail”. 5.2.11 DVR STATUS Press the “STATUS” button or double-click the left button of Mouse, The SYSTEM INFOMATION screen will appear. To see the next page, press the Press the STATUS button again to move on next information screen or press the “ESC”...
- Page 34 This DVR has the Programming capacity for 8 preset locations for 8CH. This DVR has the Programming capacity for 4 preset locations for 4CH. - This DVR has RS-422/485 terminal block telemetry port on the rear panel. button to tilt up and down.
- Page 35 OPERATION 5.2.13 FUNCTION BUTTON <Audio select > You can select audio channels regardless of monitoring screen. Press the “function(audio select)” button and then press the desired number button and you can hear audio of selected channel regardless of monitoring screen. <...
-
Page 36: Remote Controller
OPERATION 5.3 REMOTE CONTROLLER ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Button Name ○ FUNCTION ○ ○ ○ IRIS - ○ COPY ○ RECORD ( ● ) ○ ALARM RESET ○... -
Page 37: Mouse Control
MENU SETUP 5.4 MOUSE CONTROL ○ ○ Status d Status d ○ Menu dis ○ ○ Exit ○ ○ ○ Value ch ○ Select * You isplay isplay Double-click Doubl e-click of th of th e left button e left button play One-c lick of the r... -
Page 38: Menu Setup
This menu is simply used when user want to change just a few important settings. Note: If you select QUICK SETUP setting is “ON”，the DVR System will according to this Setup Page setting to record the recording data，If you select QUICK SETUP setting is “OFF”, the DVR System will recording data according to the Record Setup Page setting. -
Page 39: Quick Setup
Select the desired time for pre-recording using the (-), (+) buttons or wheel scroll of mouse. When video loss, alarm or motion is detected, the DVR wi store pre-recorded data during the selected time. The pre-recording time can be set from 0 second to 5 second and the default is “5”. -
Page 40: Screen
REMOTE CONTROL ID using the (-), (+) buttons or wheel scroll of mouse. If you are operating more than one DVR in the same place and wish to use the remote controller, the remote controller ID setup is required . -
Page 41: Add Auto Single
MENU SETUP ② Change the value of the HORIZONTAL mouse to adjust the horizontal position of the screen. * The value is from -4 to +4 and the default is “0”. ③ Change the value of the VERTICAL POSITION using the (-), (+) buttons or w to adjust the vertical position of the screen. -
Page 42: Display
MENU SETUP 6.2.3 DISPLAY the SCREEN menu, ① Move the cursor to the DISPLAY using ② Press the ENTER button when the cursor is on the DISPLAY and the following items appear. ③ To exit this DISPLAY menu, press the ESC button. 6.2.3.1 HDD FREE SPACE At the DISPLAY menu, ①... -
Page 43: Date&Time Mode
MENU SETUP ON: The date and time will be displayed on the screen. 6.2.3.5 DATE&TIME MODE At the DISPLAY menu, ① Move the cursor using the ② Use the (-), (+) buttons or wheel scroll of mouse to choose “NUMBER” or “INITIAL”. * The default is “NUMBER”. -
Page 44: Title
BITMAP: It is possible to download new characters using the s 6.2.5 MULTI-SCREEN You can select the desired channels and make a 4、7、9、10、13 split scre this menu. buttons. buttons and then press the ENTER b oftware (DVR Viewer) if you want. buttons and the utton. en(for 16CH) using... -
Page 45: Live 4E
MENU SETUP At the SCREEN me ① Move the cursor to the MULTI SCREEN using ② Select the character using the ③ Press the ENTER button when the cursor is on the appears. ④ To exit this MULTI SCREEN menu, press the ESC button. 6.2.5.1 LIVE 4E / LIVE 7/ LIVE 9B/ LIVE 10/ LIVE 13 ①... -
Page 46: Live 13
MENU SETUP [LIVE 13] ② Set the desired number of camera in each channel screen using the (-), (+) buttons or wheel scroll of mouse. ③ Use the buttons to set the other channel screen. ④ To exit this screen, press the ESC button. Note: In the each of LIVE SPLIT, same camera numbers should not be selected. -
Page 47: Record
MENU SETUP 6.2.7 SPOT At the SCREEN menu, ① Move the cursor to the SPOT using ② Press the ENTER button when the cursor is on the SPOT and the following screen appears. ③ o exit this SPOT menu, press the ESC button. 6.2 7.1 SPOT MODE ①... -
Page 48: Record Setup
MENU SETUP 6.3.1 RECORD SETUP At the RECORD menu, ① Move the cursor to the RECORD SETUP using ② Press the ENTER button when the cursor is on appears. ③ Move the cursor to choose the desired time using the ④... - Page 49 MENU SETUP ② Press the ENTER button when the cursor is on the RECORD PROGRAM and the following screen appears. ③ Use the buttons to move the cursor to the desired item. ④ Select the desired RECORD TYPE using the (-), (+) buttons or wheel scroll of mouse. - SINGLE : Only one event channel will be record d by setting event recording frame rate and the other channels will be recorded by rest event recording fps/N(channel number) when an event happened.
- Page 50 TIME and POST TIME using the (-), (+) buttons or wheel scroll of mouse. When the event is dete cted, the DVR will store pre- and post-recorded data during the sele value o f “PRE TIME” is from 0 to5 seconds and the value of “POST TIME” is from 0 to 60 default of pre-recording time is 5 seconds and post-recording is 10 seconds.
-
Page 51: Image Quality
MENU SETUP < PROGRAM DEFAULT> These are 10 kinds of program and you can change the program setting. PROGRAM RECORD SINGLE TYPE RECORDING INTERVAL x480 IMAGE 360x24 x240 360x SIZE x240 NORMAL EVENT SINGLE EVENT COMPLEX QUALITY NORMAL QUALITY EVENT PRE-ALARM RECORDING POST-... -
Page 52: Audio Record
ENTER button when the cursor is on appea ③ Select the recording channel for each audio channel using the mouse. NOTE : 16CH、8CH、4CH DVR has 4CH Audio inputs. 6.3.5 REPEAT RECORD At the RECORD menu, ① Move the cursor to the REPEAT RECORD using ②... -
Page 53: Play Mode
MENU SETUP ③ Use the (-), (+) buttons or wheel scroll of mouse to set “ON” or “OFF”. ④ It is possible to set a point of time to work the REPEAT RECORD ALARM. Move the c ursor to ”REPEAT RECORD ALARM” using value using (-), (+) buttons or wheel scroll of mouse. -
Page 54: Event
MENU SETUP ③ Set up “ON” or “OFF” of HOLIDAY RECORD using the (-), (+) buttons or wheel scroll of mouse. ④ Move the cursor using buttons and set up the value using the (-), scroll of mouse. ⑤ To exit this HOLIDAY menu, press the ESC button. 6.4 EVENT To se t up the EVENT menu,... -
Page 55: Channel
MENU SETUP MENU SETUP 6.4.1.1 CHANNEL 6.4.1.1 CHANNEL At the MOTION DETECTION menu, At the MOTION DETECTION menu, ① ① Move the cursor t Move the cursor t o CHANNEL using o CHANNEL using ② Select the desired channel using the (-), (+) buttons ②... -
Page 56: Event Message
③ Select the desired channel using the ④ Select the type of sensor whi ch is connected with DVR using the (-), (+) buttons or wheel scroll of mouse. ⑤ To exit this SENSOR INPUT menu, press the ESC button. -
Page 57: Relay Output
MENU SETUP 6.4.8 RELAY OUTPUT At the EVENT menu, ① Move the cursor to the “RELAY OUTPUT” using the ② Press the ENTER button when the cursor is on the “RELAY OUTPUT” and the ③ Move the cursor using the wheel scroll of mouse. -
Page 58: System
MENU SETUP 6.5 SYSTEM To set up the SYSTEM menu, ① Move the cursor to the SYSTEM icon using the ② Press the ENTER button when the cursor is on the SYSTEM icon and the following items appear. 6.5.1 HDD At the SYSTEM menu, ①... -
Page 59: Rec Hdd Initialize
MENU SETUP ③ Use the buttons to move the cursor and use the (-), (+) buttons or wheel scroll of mouse to change the value. HDD MODE - REC: Normal and Event recording - BACKUP: Only for backup 6.5.1.2 REC HDD INITIALIZE At the HDD menu, ①... -
Page 60: Clock
MENU SETUP ③ If you want to initialize, move the cursor to “YES” nd then press the ENTER button. If not, move the cursor to “NO” and then press the ENTER button. ④ To exit this screen, press the ESC button. ⑤... -
Page 61: Time Adjust
③ Select “ON” or “OFF” using the (-), (+) buttons or wheel scroll of mouse when the cursor is on “INTERNET TIME ADJUST”. If the INTERNET TIME ADJUST is “ON”, the time of DVR will be adjusted to the tim e offered by the internet server. - Page 62 MENU SETUP At the SYSTEM menu, ① Move the cursor to the PASSWORD using the ② Press the ENTER button when the cursor is on the appears. ③ To exit this PASSWORD menu, press the ESC button. 6.5.3.1 MASTER PASSWORD At the PASSWORD menu, ①...
-
Page 63: Menu Display Check
MENU SETUP ⑤ And you have to insert the same numbers again to verify the password after entering the NEW PASSWORD. ⑥ To exit this MASTER PASSWORD menu, press t 6.5.3.2 SUPERVISOR PASSWORD t the PASSWORD menu, ① Move the cursor to th e SUPERVISOR PASSWORD using the ②... -
Page 64: Rec/Play Check
① Move the cursor to the VIDEO STANDARD using the ② Select the desired value using the (-), (+) buttons or wheel scroll of mouse. If you select “ AUTO”, this DVR can detect NTSC/PAL automatically. The default is “AUTO”. 6.5.5 LANGUAGE At the SYSTEM menu, ①... -
Page 65: Dvr Initialize
At the SYSTEM menu, ① Move the cursor to the DVR INITIALIZE using the ② Press the ENTER button when the cursor is on the DVR INITIALIZE and the following screen appears. ③ If you want to initialize, move the cursor to “YES” and then press the ENTER button. If not, move the cursor to “NO”... -
Page 66: Link
MENU SETUP 6.6 LINK To set up the LINK menu, ① Move the cursor to the LINK icon using the ② Press the ENTER button when the cursor is on the LINK icon and the following items appear. 6.6.1 NETWORK At the LINK menu, ①... - Page 67 ① Move the cursor to the PORT using the ② Select the desired position using the wheel scroll of mo NOTE: Port setting on DVR and client viewer softw e must be matched. <Dynamic IP> At the NETWORK menu, ① Move the cursor to the DHCP using the ②...
- Page 68 MENU SETUP...
-
Page 69: Baud Rate
MENU SETUP 6.6.2 RS-232 At the LINK menu, ① Move the cursor to the RS-232 using the ② Press the ENTER bu tton when the cursor is on the RS-232 and the following screen appears. ③ Use the buttons to choose the item and use the (-), (+) buttons or wheel scroll of mouse to set the data value. -
Page 70: Ptz
MENU SETUP 6.6.4 PTZ At the LINK menu, ① Move the cursor to the PTZ using ② Press the ENTER button when the cursor is on the PTZ and the following 2 pages screen appears. ③ Select the desired channel using ④... - Page 71 .5.2 SMTP SERVER At the E-MAIL menu, ① Move the cursor to the SMTP SERVER using the to be used by DVR. ② Press the ENTER button and the following screen appears. ③ Select the character using the ④ To exit this CHARACTE R TABLE screen, press the ESC button.
- Page 72 To exit this CHARACTER TABLE screen, press the ESC button. 6.6.5.5 DVR E-MAIL ADDR At the E-MAIL menu, ① Move the cursor to the DVR E-MAIL ADDR using the to receive the e-mail when an event happe ② Press the ENTER button and the following scre ③...
-
Page 73: Search
MENU SETUP 6.7 SEARCH To set up the SEARCH m enu, ① Move the cursor to SEARCH icon using the ② Press the ENTER button when the cursor is on the SEARCH icon and the following items appear. ** Please, refer to Search & Playback of Chapter 5 Operation. 6.8 COP To set up the COPY menu, ①... -
Page 74: Exit
MENU SETUP 6.9 EXIT At the MENU screen, ① Move the cursor to the EXIT icon using the ② Press the ENTER button when the cursor is on the EXIT icon and the following items appear. ③ Move the cursor to the des ired item using the SAVE ONLY : Select this item if you want only to save the changed setup. -
Page 75: External Terminal Information
EXTERNAL TERMINAL INFORMATION External Terminal Information apter 7 7.1 RS-422/48 This port can be used to connect the external controller. 7.2 T.ADJ This function is not supported. -
Page 76: Relay Out
EXTERNAL TERMINAL INFORMATION 7.3 RELAY OUT For controlling alarm output by relay. 7.4 ALARM H for alarm 1 to alarm 16 CH fo r alarm 1 to alarm 8 CH for alarm 1 to alarm 4 RS-422/485 / T-ADJ / RELAY OUT RS-422/485 / T-ADJ / RELAY OUT NC 1 CM 1... -
Page 77: Vga
EXTERNAL TERMINAL INFORMATION 7.5 VGA This DVR is compatible with TFT LCD monitor in PAL mode. s DVR supports 1024 x 768 reso lution & 70Hz refreshed rate in NTSC/PAL mode. 4~12 7.6 SERIAL his DVR is compatible with TFT LCD monitor in PAL mode. -
Page 78: Ethernet / Usb
EXTERNAL TERMINAL INFORMATION .7 Ethernet / USB For both 10Base-T and 100 Base-TX. ETHERNET USB2 USB1 Note: Definition (under Menu o ption): USB1 = USB_REAR1 USB2 = USB_REAR2 7.8 REMOTE 1, 2, 3, 4, 5, 6, 7, 8 9, 10, 11, 12 13, 14, 17, 18, 19, 20, 23 21, 22 24, 25... -
Page 79: Specifications
: Rear 4 port RCA 1 CH : Rear 1 port HDD extension/ Mouse/ USB memory stick/ CD-RW/ DVD-RW (Fro nt 1 port, Rear 2 ports) This DVR is compatible with TFT MPEG4 (Refer to the below table) detection, Video loss,... - Page 80 Dimension Weight 10. BACKUP & COPY Digital Backup Copy 11. SEARCHING & PLAYBACK Searching Method 12. MULTI-REMOTE SURVEILLANCE Monitoring Environment Max. connection DVR Max. client 13. SYSTEM MONITORING & RECOVERY System logging Monitoring Recovery 14. Others Duplexer or Triplexer Control Device...
- Page 81 720 x 288 720 x 576 Compression Method < 1. RECORDING CONDITIONS Based on 120GB of storage with the installation of 1 camera. This DVR can support up to 22TB wi 2. RECORDING TIME TABLE IDEO RECOR IMAGE SIGNAL IMAGE...
-
Page 82: Installl The Internal Hard Disk Drive(S)
WESTERN DIGITAL : www.westerndigital.com DISK DISK DRIVE(s). DRIVE(s). D(s) D(s) into DVR. Refer to HDD jumper settin into DVR. Refer to HDD jumper settin d 4 by slave. d 4 by slave. Jumper Setting Jumper Setting Master No.1 for Master and No. -
Page 83: Network Viewer
.1.2 Network Environment Client PC Minimum More than 1Mbps Recommended More than 3Mbps (16 Frames/Sec) ∗ Transfer rate of image varies with the number of client accessed to DVR. ® NOTE : The software , Dvrv iewer is comp 9.1.3 Inst... -
Page 84: Network Viewer Installation
Click the “Select a DVR” button to display the DVR List on the screen. ○ Fill out Type, DVR Name, IP address and Password to add the desired units into the DVR formation box, and then click on the “Add” button to save the information. -
Page 85: Dvr Search
If you want to see the next list, click the Next button before playing. NOTE - You can directly install the removable HDD rack from DVR to PC if compatible rack guide is installed on the PC. In this case, please check the jumper setting for proper operation. -
Page 86: File Search
Arrange Shown above is the m ain menu controlle ○ Click the “Arrange” bu n when you in a grid on your PC scre ccess more than one DVR and the windows are arranged... -
Page 87: Option
NETWORK VIEWER INSTALLATION * 1 site windows *5 ~ 9 site windows NOTE - You can connect up to 16 DVRs with your PC simultaneously. (16 users x 16 units: Master connection is only one.) - With the windows arranged in a grid, double-click the desired to make it the full screen .7 OPTION sert the CD into the CD-ROM drive, and then please double-click the icon of Dvrviewer and the llowing main menu controller will appear on the PC screen. -
Page 88: Control
Click the “MULTI” button and the multi-screen will be displayed. ○ Click the “MULTI” button again to view other multi-screen. NOTE Selecting a Multi-display may slow down the updates as multiple connections are made to the DVR at the same time. . Auto Sequence display ○... - Page 89 You can enter the PTZ mode only while connecting the PTZ camera. - Preset setup A preset is user-defined camera position using pan and tilt, zoom, and focus commands. The DVR has programming capacity for 16 preset locations. Program a preset ○...
- Page 90 DVR. .8.4.1 How to download firmware ○ Click the “SETUP” button on the control menu bar to display the DVR setup screen after connecting the view screen. (It is possible only for master connection.) ○ Click the DOWNLOAD tap and you can see the “Firmware Download” button.
- Page 91 After connecting the view screen, ○ Click the “Audio In” button on the control menu bar to input ○ Sound of your PC will travel into the DVR. 9.8.9 AUDIO OUT fter connecting the view screen, ○ Click the “Audio Out” button on the control menu bar to output the audio.
- Page 92 NETWORK VIEWER INSTALLATION ○ You can hear the DVR sound from the speaker of your PC. 9.8.10 TIME SEARCH You can search and playback the images by the time. fter connecting the view screen, ○ Click the “TIME” but ton on the control menu bar to display t ○...
- Page 93 Set the Search Time, and then click the Search button. ○ Click the “Next” button to search the next list. NOTE: When the DVR is in Setup mode, this search function will not be performed. - Normal HDD: Hard Disk Drive inst alled in the DVR - Backup HDD: Hard Disk Drive installed in the DVR to backup(Event backup or Mirroring).
-
Page 94: Key Information
NETWORK VIEWER INSTALLATION 9.9 KEY INFORMATION 9.9.1 PAUSE ○ Click this button to pause the images during the playback or live. 9.9.2 PLAY (Reverse & Forward) ○ Use these buttons to playback images at normal speed in either direction. 9.9.3 FAST (Reverse & Fo rward) ○... - Page 95 This warranty does not cover damages in shipment, failures caused by other products not supplied by Channel Vision Technology, or failures due to accident, misuse, abuse, or alteration of the equipment. This warranty is extended only to the original purchaser, and a purchase receipt, invoice, or other proof of original purchase date will be required before warranty repairs are provided.
