- Page 1 Assembly Instructions (W x D x H) m1.83 x m0.54 x m2.77 Product Name: Rustic Arch PLEASE KEEP THIS INSTRUCTION Zest4Leisure 01352 752555 option 1 – sales@zest4leisure.co.uk...
- Page 2 Rustic Arch Assembly Instructions Requires 2 person assembly. All screw holes to be pre-drilled. Tools required: Corded / Cordless Drill, Pozi-drive Bit / Screwdriver, 3mm Drill Bit, 13mm Spanner. Rustic Arch Pack List Item Description Quantity Roof Panel Side Panel...
- Page 3 Connect Side Panel B to Roof Panel A using 2no Diagonal Bracings C (Fig.3) using 4no 100mm Screws – 2no per bracing. Repeat stages 2 & 3 for remaining Side Panel B and Bracings C. Rustic Arch is now complete.
