Summary of Contents for stefani Reverse Osmosis
- Page 2 INCLUDED ACCESSORY: For your convenience the following accessory is included: Pressure Limiting Valve with dual check valve - limits the pressure to 345kPa (50psi). For further information please contact Stefani +61 8 93506178...
-
Page 3: Table Of Contents
REVERSE OSMOSIS SYSTEM DIAGRAM ..........3 LIST OF PARTS .................... 4 INSTALLATION INSTRUCTIONS REVERSE OSMOSIS SYSTEM CONTENTS DIAGRAM ......5 STEP 1 – MAINS WATER CONNECTION ........... 6 OPTION 1........................6 CONNECTING TO ½” COPPER PIPE WHERE EXISTING PLUMBING FITTINGS ARE AVAILABLE OPTION 2........................7... -
Page 4: Reverse Osmosis System Diagram
Reverse Osmosis Syetem EXPLODED DIAGRAM... -
Page 5: List Of Parts
LIST OF PARTS Stefani 5 Stage Reverse Osmosis Water Filtration System component identi cation & content check list: Description Product No. Filter Housing HOUSING ¼”QC Pressure limiting valve with dual check valves Bracket BRACKET Multi-Function valve (MFV) Stopper Plug for Multi-Function valve Ball Valve ¼”... -
Page 6: Reverse Osmosis System Contents Diagram
Reverse Osmosis Syetem CONTENTS DIAGRAM Filter Housing and Accessories Assembled... -
Page 7: Installation Instructions
INSTALLATION INSTRUCTIONS STEP 1 – MAINS WATER CONNECTION The 5 Stage Reverse Osmosis Filtration System can be xed in 3 di erent ways below are the options: 1. Connecting to ½” copper pipe where existing plumbing ttings are available 2. Connecting to ½” copper pipe 3. -
Page 8: Option 2
6. Upon completing the above steps, proceed to STEP 2 (page 9) BRASS TEE MULTI FUNCTION VALVE BALL VALVE STOPPER PLUG OPTION 2 Connecting to ½” copper pipe 1. Turn the main water supply o . 2. Caution: Make sure the ½” copper pipe is a cold water line. 3. -
Page 9: Option 3
OPTION 3 Installing with an existing mixer tap/dishwasher tap 1. Turn the main water supply o . 2. Locate the cold water supply or dishwasher tap and then disconnect the exible hose from the mixer or dishwasher tap (the use of a exible hose which complies with Australian Standards is recommended). -
Page 10: Step 2 - Faucet Installation
STEP 2 – FAUCET INSTALLATION 1. Find the suitable location to install the faucet, and stabilise the faucet by using the faucet ttings provided. 2. Remove the locking nut from the faucet. Place Chrome Cover Plate and O-ring on the Small Rubber Washer shaft of faucet. -
Page 11: Step 4 - 5 Filter Components & Manifold Installation
STEP 4 – 5 FILTER COMPONENTS & MANIFOLD INSTALLATION Select the location for the Reverse Osmosis components under your sink. Allow space for the storage tank and at least 50mm to the underside of the housing to cater for lter cartridge changeover. -
Page 12: Step 6 - Final Tubing Connection
IN on the Reverse Osmosis Membrane lter 3. Connect the desired length of tubing to the OUTLET of the Reverse Osmosis Membrane to the T connection on the Carbon Post lter 4. -
Page 13: The Quick Connection Push System
5. Install new membrane, be sure to push the membrane into the housing as far as it will go REPLACING FILTER CARTRIDGES It is recommended to only use Stefani water lter cartridges with this ltration system. This will ensure optimum performance, protection from contaminates and... - Page 14 6-8months if you notice a reduced volume or ow from the lter faucet, or the return of an unpleasant taste/odour to the ltered water. Please contact Stefani Australasia Pty Ltd on (08) 9350 6178 or email to stefani@stefani.com.au if you require any assis-...
-
Page 15: Warranty
STEFANI shall in no event be held liable for damages or delays caused by defects and assume no responsibili- ty for unauthorised repairs. -
Page 16: Stefani Water Filter Cartridge Guide
Please check the Water Filter Cartridge Guide on page 14 for other suitable lters for this system. Register online at www.stefani.com.au for a lter change reminder by email. A lter change reminder fridge magnet has been supplied for your convenience.
