Sys * Stim 206 Instruction Manual— Rev. E_4/4/13 Table of Contents Section Title Page Introduction Introduction to the Sys * Stim 206 Introduction to this Manual Safety Precautions Caution Shipping Damage Package Contents Limited Warranty Control Descriptions and List of Abbreviations Control Descriptions List of Abbreviations Installation Instructions...
Page 4
Mettler Electronics Corp.— Rev. E_4/4/13 List of Figures Title Page Sys * Stim 206 Front membrane panel and LED indicators Narrow Pulse Illustration Wide Pulse Illustration AC Pulse Illustration...
Sys * Stim 206 Instruction Manual— Rev. E_4/4/13 Section 1: Introduction Introduction to the Sys * Stim 206 Thank you for purchasing the Sys * Stim 206 one-channel neuromuscular stimulator. The microprocessor controlled Sys * Stim 206 produces electrical stimulation currents through one channel. There are four waveforms available—narrow, wide and AC pulses along with continuous direct current.
NOTE: All warranty repairs must be performed by Mettler Electronics Corp. or by a service facility authorized by Mettler Electronics to perform warranty repair work. A service manual for the Sys * Stim 206 is available from Mettler Electronics Corp. for a nominal charge. Caution...
The Sys * Stim 206 neuromuscular electrical stimulator is warranted against defects in materials and workmanship for a period of one year from date of purchase. During the applicable warranty period Mettler Electronics Corp. will, at its discretion, either repair or replace the Product without charge for these types of defects.
Page 8
Mettler Electronics Corp.— Rev. E_4/4/13 Mettler Electronics Corp. shall not be liable for any indirect, special, consequential or incidental damages resulting from any defect in or use of the Product. Any legal action brought by the buyer relating to this warranty must be...
Sys * Stim 206 Instruction Manual— Rev. E_4/4/13 Section 2—Control Descriptions and List of Abbreviations Control Descriptions Mains power is controlled by an On/Off toggle switch. The unit is off when the switch is pressed to the right and on when pressed to the left.
Page 10
Mettler Electronics Corp.— Rev. E_4/4/13 The three-digit output display shows the peak output voltage for narrow, wide, and AC pulse modes, or the 0 0 0 electrical current (Milliamps) for the DC continuous mode while treatment output is active. The meter function is dependent upon the current mode selected prior to the start of operation.
Page 11
Sys * Stim 206 Instruction Manual— Rev. E_4/4/13 Press the “Surge” button to enter the Surge mode. The green indicator to its left illuminates when activated to show that the Surge mode is selected. Selection of this mode is in conjunction with selection of any one of the pulse current types.
Mettler Electronics Corp.— Rev. E_4/4/13 Frequency is controlled by a three quarter turn adjustment knob. This control varies the repetition rate of pulses applied to the patient during all pulse modes except when the Surge mode is selected. It is inoperative in the DC Continuous mode.
Sys * Stim 206 Instruction Manual— Rev. E_4/4/13 Section 3—Installation Installation Instructions 1. Plug the attached line cord into a grounded wall outlet that is rated at 120 VAC (±10%)/60Hz (220 VAC/50Hz for export models). Your power supply must match the voltage requirements listed on the serial number label of your device.
Page 14
Mettler Electronics Corp.— Rev. E_4/4/13 Mode Indication Table Waveform Current Function Output Characteristics Indication Pulse frequency control, adjust Pulse frequency pulse repetition rate from 1 – 83 Hz AC output will rise, hold and fall at a present rate when Surge is selected.
Mettler Electronics Corp.— Rev. E_4/4/13 A Note about Electrodes To ensure safe operation of the Sys * Stim 206, follow the recommendations listed below: 1. Current is introduced to the body by means of two electrodes, one Active (black and negative) and one Dispersive (red and positive). The...
Sys * Stim 206 Instruction Manual— Rev. E_4/4/13 b) Use Mettler Electronics electrodes to ensure safe and effective operation. c) Verify connection of the line cord to a grounded wall receptacle. d) Connect the electrode cable (ME 2260) into the electrode jack.
Page 18
Mettler Electronics Corp.— Rev. E_4/4/13 treatment time in combination treatment. However stimulation continues until hold button is depressed on the Sys * stim 206. 7. Select the desired current mode by depressing one of four selector keys: 1) Narrow pulse; 2) Wide pulse; 3) AC; or 5) DC Continuous. (a green indicator light will come on next to the mode key that is selected.)
Sys * Stim 206 Instruction Manual— Rev. E_4/4/13 Section 5—Indications, Contraindications, Precautions and Adverse Reactions Indications The application of pulsating electric currents to the body via electrodes elicits responses from nerves which conduct pain sensation and muscle contraction information. Stimulation of sensory fibers will help block pain while the stimulation of motor fibers will generate pulsatile contractions of the muscle groups innervated by the nerves being stimulated.
Mettler Electronics Corp.— Rev. E_4/4/13 disease, electrical stimulation should be used only after careful physician evaluation and patient instruction. Place electrodes in such a way to avoid stimulation of the carotid sinus (neck) region. Patients with arterial or venous thrombosis, or thrombophlebitis are at risk of developing embolisms when electrical stimulation is applied over or adjacent to the vessels containing the thrombus.
Sys * Stim 206 Instruction Manual— Rev. E_4/4/13 The long–term effects of chronic electrical stimulation are unknown. Electronic monitoring equipment (such as ECG monitors and ECG alarms) may not operate properly when electrical stimulation is in use. Precautions Care should be taken in the treatment of patients receiving another type of electrotherapeutic treatment (such as conventional TENS) or having indwelling electrodes, lead wires, or transmitters (for electrophrenic pacing or cerebellar or urinary bladder stimulation).
Mettler Electronics Corp.— Rev. E_4/4/13 15. Iontophoresis to be used only if the labeling of the drug intended for use with the Sys * stim 206 bears adequate directions for use of the device with the drug. 16. Turn on the Sys * Stim 206 before applying electrodes to the patient.
Sys * Stim 206 Instruction Manual— Rev. E_4/4/13 Section 6—Maintenance and Troubleshooting Cleaning the Sys * Stim 206 The Sys * Stim 206 can be wiped off with a damp cloth. The power cord should be disconnected from the wall before this is done. In the case of stubborn dirt a gentle household cleaner can be sprayed on the cloth and then wiped on the unit.
Page 24
Mettler Electronics Corp.— Rev. E_4/4/13 4. Timer is running but the Cycle the Main power control by meter reads 0 even when the pressing it once and wait 3 intensity is set at maximum. seconds then press it again. This...
Sys * Stim 206 Instruction Manual— Rev. E_4/4/13 Section 7—Specifications General Specifications: Input: 120 VAC (±10%)/60Hz 220 VAC/50Hz—export models only Weight: 5.6 pounds (2.5 kg.) Dimensions: 4.3 in (H) x 6 in (D) x 13.4 in (L) (11 cm (H) x 15 cm (D) x 34 cm (L)) Maximum Treatment Time: 29 minutes Output Specifications:...
(800) 854–9305 or phone (714) 533–2221 in areas outside the continental United States. Ask for Customer Service. Mettler Electronics is open from 7 AM until 5 PM Pacific Time for your convenience. The email address for Customer Service is mail@mettlerelectronics.com.
Page 28
Mettler Electronics Corp.— Rev. E_4/4/13 electrodes/pkg.) 2260 Electrode cable for the Sys * Stim 206 with pins 2702 V Trode –2" diameter round electrodes with lead wires, case of ten packages (four electrodes/pkg.) 2703 V Trode –2.75" diameter round electrodes with lead wires, case of 10 packages (four electrodes/pkg.)
