General Installation Guide
MONROE
Wall mounted vanity basin unit 700, 900 & 1200
NOTE: Countertop wash basin not included, it is only used for illustrative purposes.
A member of
SANIPEXGROUP
Please leave these instructions with the customer
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sanipex BAGNODESIGN MONROE BDF-MNR-V070-ORO
Summary of Contents for Sanipex BAGNODESIGN MONROE BDF-MNR-V070-ORO
- Page 1 BAGNODESIGN EXPERTLY CRAFTED BATHROOMS General Installation Guide MONROE Wall mounted vanity basin unit 700, 900 & 1200 NOTE: Countertop wash basin not included, it is only used for illustrative purposes. A member of SANIPEXGROUP Please leave these instructions with the customer...
- Page 4 Remove the wall cabinet hangers from the packaging and fit them to the correct corresponding sides of the cabinet. The cabinet hangers are fitted to the sides of the cabinet using a cross headed screwdriver and the fixing screws supplied in the cabinet hanger pack as shown above.
- Page 5 you have decided on a suitat>le position for your vanity unit, mark out the internal Once distance onto the wall. line the wall fixing plates up to the inside of the marl<ings mark out the drilling positions on the wall. Attach wall fixing plates using suitable fi<ings (not supplied), making sure the wall fixing plotes are level and the distance between the outer edges cf the wall fixing plates is the same as that measure the previous stage.
- Page 6 Using a spirit level check the cabinet is level and plumb. Adjust the cabinet hanger as shown, us·1 n g the top screw to alter the vertical adjustment and the bottom screw to secure the unit to the wall once the unit is level. Once you are happy that the unit is level place the covers over the cabinet hangers.
-
Page 7: Installation Complete
� down-I> If you need to adjust the drawer unit this can be achieved by removing the plastic cover caps from the drawer sides to reveal the adjustment wheel and screw. Please follow the diagrams below to adjust the drawer in both the Vertical and horizontal planes. Please note horizontal adjustment can only be made from the RH drawer side. - Page 8 INF-MNR-VANITY-12-20...
