TRANSPOSE/TUNE/MIDI
CONTROL CHANGE
This message adds effects such as vibrato and volume changes ap-
plied during keyboard play. CONTROL CHANGE data includes a
control number (to identify the effect type) and a control value (to
specify the on/off status and depth of the effect).
The following is a list of data that can be received using CONTROL
CHANGE.
Effect
VOLUME
PAN
HOLD1 *
MODULATION
* Pressing the foot pedal causes the sustain effect (HOLD1) to be sent
(control number 64).

Changing MIDI Settings

This keyboard lets you change the settings of two MIDI parameters:
TONE MAP and KEYBOARD CHANNEL.
To change MIDI parameters
1.
Press the TRANSPOSE/TUNE/MIDI button either
three or four times to select the parameter you want.
Press the TRANSPOSE/TUNE/MIDI button three times: KEY-
BOARD CHANNEL
Press the TRANSPOSE/TUNE/MIDI button four times: TONE
MAP
Example: To select the TONE MAP parameter.
TONE
RHYTHM
SONG BANK
2.
Use [+] and [–] to change the setting of the parame-
ter.
Example: To change the TONE MAP parameter value to "G"
(GM).
TONE
RHYTHM
SONG BANK
• If you accidentally go past parameter you want, keep press-
ing the TRANSPOSE/TUNE/MIDI button until parameter
you want reappears on the display.
• If you leave the parameter selection screen on the display
for about five seconds without doing anything, the parame-
ter selection screen is automatically cleared.
622A-E-033A
CTK451_E30_31
Control Number
7
10
64
1
Page 31
[+]/[–]
Parameters and Their Displays
KEYBOARD CHANNEL (Basic Channel) (Default: 01)
This parameter specifies the keyboard MIDI message send channel.
TONE
RHYTHM
SONG BANK
TONE MAP G/N (Default: N)
N: This settings specifies the normal tone map, which allows receipt
of a program change value in the range of 0 to 99. Only tones that
correspond to the 100 built-in tones of this keyboard can be played,
and tone numbers outside this range are ignored.
TONE
RHYTHM
SONG BANK
G: This setting specifies the General MIDI tone map, which allows
receipt of a program change value in the range of 0 to 127. Each
of the 128 General MIDI tones is automatically assigned to one of
the keyboard's 100 built-in tones as shown on page A-1. Select
this setting when you want to listen to General MIDI data from a
computer or other external equipment.
TONE
RHYTHM
SONG BANK
NOTES
• Playing a Song Bank tune causes all MIDI parameters to revert to their
default settings. Also, MIDI messages cannot be received while the key-
board is in the Song Bank Mode.
• Song Bank data cannot be sent as MIDI data.
