ENFORCER SK-919T1-GBWQ Installation Manual

Wired Single-Channel
RF Transmitter
SK-919T1-GBWQ (315MHz)*
SK-939T1-GBWQ (433.92MHz)
Installation Manual
†
*
Specifications
Model SK-919T1-GBWQ SK-939T1-GBWQ
Type 1-Channel Wired RF Transmitter
Switch
Wiring
Power
Battery 3VDC battery (CR-2032, included)
Power
External 3~13 VDC output regulated adapter
RF Frequency 315MHz (FCC)
# of Buttons
Channels
Possible codes
Dimensions 1
Dimensions
1 1 / "
4
(31.5mm)
Two 6" wires for N.O.
Two 6" wires for power input
433.92MHz (CE)
1
1
Over 68 billion (6.8x10
10
1 / "x2 3 / "x 5 / " (31.5x55x8 mm)
4 16 16
2 / "
3
16
(55mm)
5 / "
16
(8mm)
• Powered by internal battery or external 3~13
VDC output regulated adapter (not included)
• Frequency 315MHz
• Operates up to 500ft (150m)*
• Over 68 billion (6.8x10
• LED transmission indicator
†
• Includes one 3VDC lithium battery (CR-2032)
• Compact size
• Compatible with all SECO-LARM SK-series
receivers of the same frequency
• Also available without logo –
SK-919T1-GBWUQ – 315MHz
SK-939T1-GBWUQ – 433.92MHz
* Actual range will vary depending on the installation and operating
environment
Sample Applications
Make any push-to-exit plate wireless
PUSH
TO
EXIT
Convert photobeam sensors with dry contacts
into an entry alert
Wireless equipment / perimeter security
)
PIR
PIR
Wireless doorbell / service call button
Transmitter
/ 433.92MHz
10 ) possible codes
Transmitter
Electromagnetic lock
Transmitter
Receiver
Transmitter
Receiver
Receiver
Receiver
SL-126Q
Strobe
Strobe
