ENFORCER SK-919TDWS-BQ Installation Manual

Installation Manual
ENFORCER
SK-919TDWS-BQ
SK-939TDWS-BQ
Wired Single-Channel RF Transmitter
FEATURES:
• Powered by internal battery or external 12VDC output
regulated adapter.
• Frequency 315 MHz (433.92 MHz also available)
• Over 68 billion (6.8 x 10
• LED transmission indicator.
• Includes one 12VDC alkaline battery.
• Compatible with all SECO-LARM receivers.
• Compact size 2" x 1.5" x 0.59" (50 x 38 x 15mm)
• Wiring: Two, 6-inch blue wires for N.O. switch input.
Two, 6-inch wires (red & black) for 12VDC power input.
• SK-919TDWSBUQ same as SK-919TDWS-BQ, but no logo.
SK-939TDWSBUQ same as SK-939TDWS-BQ, but no logo.
Note: Operating range will vary greatly depending on the installation and operating environment.

TYPICAL APPLICATIONS:

Make any push-to-exit plate wireless.
Electromagnetic Lock
Convert Dual-Beam sensors with dry contacts
into entry alert system.
) possible codes.
10
SK-910RQ
RF Receiver
ENFORCER ®
SL-126Q
Strobe
®
315MHz
433.92MHz
Compatible Receivers:
1-Channel
2-Channel
4-Channel
Wireless equipment / perimeter security.
PIR
Wireless doorbell / Service call button.
SK-910RQ (315MHz)
SK-910R-4Q (433.92MHz)
SK-910R2Q (315MHz)
SK-910R2-4Q (433.92MHz)
SK-910R4Q (315MHz)
SK-910R4-4Q (433.92MHz)
Siren, chime,
buzzer, etc.
