Summary of Contents for AMBIC EasiDoser
-
Page 2: Table Of Contents
Opto Isolator Connection ......................6 Initial Set Up – Electrical Connections & Calibration/Programming Functions ..... 7 EasiDoser™ – Power Up/Down & Normal Run Displays ............7 EasiDoser™ – Basic Menu Option Displays................8 EasiDoser™ – Set Two Pump Operations ................8 EasiDoser™... -
Page 3: Introduction
The EasiDoser™ also has a “delay pump start” feature and a direct mode (Relay Mode) which allows for a timed signal from a microprocessor to control the pump run timing. The EasiDoser™ is offered in various configurations: one, two or three low volume pumps, or an industrial pump version. -
Page 4: Installation (Refer To Fig.1, 2, 4)
Chemical – is sucked up from a chemical container by peristaltic pump(s). The enclosure housing the EasiDoser™ pump(s) is rated at IP44 (IEC 60529); the power unit (A) must, therefore, be positioned in a dry location and close to a 220-240V AC power socket (Maximum Power consumed: 50W). -
Page 5: Electrical Connections
Ambic Equipment Ltd – EasiDoser™ Operating Notes Electrical Connections Figure 3 – EasiDoser ™ Switch Operations WARNING! DISCONNECT UNIT COMPLETELY ON/OFF SWITCH FROM MAINS POWER BEFORE OPENING PUSH > ON LID. PUSH > OFF Unscrew the 2 screws in the corners of the enclosure. -
Page 6: Opto Isolator Connection
Ambic Equipment Ltd – EasiDoser™ Operating Notes Opto Isolator Connection For volts-free signal (switch) there is no requirement for Opto Isolator and the switch can be connected directly to the inputs marked on the PCB as Opto 4 & Opto 5. For a 12-24V DC signal or 24-230V AC signal unit, the signal MUST be connected via the Opto Isolator(s) supplied with the unit. -
Page 7: Initial Set Up - Electrical Connections & Calibration/Programming Functions
Warning “Bleep” before screen blank. Mains Power The EasiDoser™ is supplied as either a single, twin or three pump system and can be set to run up to the maximum number of pumps fitted. This is controlled by the user-programmable settings selected from the menus detailed below. -
Page 8: Easidoser™ - Basic Menu Option Displays
Ambic Equipment Ltd – EasiDoser™ Operating Notes EasiDoser™ – Basic Menu Option Displays EasiDoser™ – Set Two Pump Operations Action Display Comment /Action Display Number 5 Enter the current PIN Code by pressing the Enter PIN Code Press Button twice buttons (in sequence):- (default factory PIN = ... - Page 9 Ambic Equipment Ltd – EasiDoser™ Operating Notes Action Display Comment /Action Display Number 15 Press buttons until correct pump mode From Display 14 Pump 2 Mode Press Button once for Pump 2 is displayed. (Manual, Signal or Manual Mode ←↑↓→...
-
Page 10: Easidoser™ - Changing Pin Code
Ambic Equipment Ltd – EasiDoser™ Operating Notes EasiDoser™ – Changing Pin Code Action Display Comment /Action Display Number 21 To change the PIN code used to access Change PIN Code ↑ Use MENU to select certain MENU items. 0 ↓... - Page 11 Ambic Equipment Ltd – EasiDoser™ Operating Notes – CHANGING MENU LANGUAGE ™ EASIDOSER By using the MENU screens, it is possible to set the screen language to either ENGLISH, FRANCAIS, or DEUTSCH as may be most appropriate. Display Number 5...
-
Page 12: Easidoser™ - Pump 1 Calibration Method
Ambic Equipment Ltd – EasiDoser™ Operating Notes EasiDoser™ – Pump 1 Calibration Method Action Display Comment/Action Display Number 23 To check the dispensing volume of Pump 1 ↑ Calibrate Press Button once take calibration vessel place Pump 1 ↓... -
Page 13: Easidoser™ - Pump Statistics
Ambic Equipment Ltd – EasiDoser™ Operating Notes To check the Pump Statistics, switch OFF the unit by pressing the button on the front of the unit. Then press both the down arrow and the button at the same time. EasiDoser™ – Pump Statistics... -
Page 14: Initial Set Up - Priming & Setting Up The System Ready To Use
“Initial Set Up section” above. Maintenance In order to preserve the efficiency and reliability of the EasiDoser™ system, we recommend that the following parts be inspected regularly for physical wear and replaced EVERY 1 – 2 YEARS, depending on the chemical used and the frequency of use. - Page 15 Ambic Equipment Ltd – EasiDoser™ Operating Notes -15- ADE7500 v1.3 (16/03/18)
- Page 16 Ambic Equipment Ltd – EasiDoser™ Operating Notes Ambic Equipment Limited 1 Parkside, Avenue Two, Station Lane, Witney, Oxfordshire, OX28 4YF. England Tel: +44 (0)1993 776555 Fax: +44 (0)1993 779039 www.ambic.co.uk -16- ADE7500 v1.3 (16/03/18)
