sisel ENDA EPDA1 Quick Start Manual page 2

CONNECTION SAMPLES
Three Phase Load Applied
Single Phase
With Two SSRs
R R
S
N
T
Load
INPUT
INPUT
Fuse
INPUT
ENDA ETS SERIES RAIL AND
PANEL MOUNTED HEATSINKS
Heatsink
ETS-46-62
ETS-46-80
ETS-46-100
ETS-62-100
ETS-46-100F
ETS-62-100F
Please refer to "ENDA ETS Series Rail and Panel Mounted Heatsinks" manual
for details. Contact your local dealer(s) or download the latest manual from
http://enda.com/en/automation/ssr/heatsink/ ENDA website.
9mm 77mm
Fan Supply : 24VDC, 220mA.
The fan side of the device must be located at the bottom.
ENDA ETS-46-100F ENDA ETS SERIES RAIL
AND PANEL MOUNTED HEATSINK
9mm 61mm
Fan Supply : 24VDC, 100mA.
The fan side of the device must be located at the bottom.
SİSEL MÜHENDİSLİK ELEKTRONİK SAN. VE TİC. A.Ş.
Şerifali Mah. Barbaros Cad. No:18 Y.Dudullu 34775
ÜMRANİYE/İSTANBUL-TURKEY
Tel : +90 216 499 46 64 Pbx.
url : www.enda.com.tr
Three Phase Load Applied
With Three SSRs
R
S
T
N
Fuse
INPUT
Fuse
Fuse
INPUT
Fuse
INPUT
Fuse
SSR Thermal
Dimensions
Current WxHxD Resistance
(A) (mm)
12-25 46x61x62
20-25 46x61x80
25-40 46x61x100
40-50 62x77x100
50-70 46x61x116
70-120 62x77x126
79mm
72mm
46mm
42mm
M3
M3
16mm
Fax : +90 216 365 74 01
+
3
INPUT
AC/DC
4
GND
(°C/W)
2,0
1,7
1,5
1,0
0,7
0,4
M3
M3
ENDA ETS-46-100
46mm
42mm
M3
M3
2/2
CONNECTION DIAGRAM
ZERO
CROSS
CIRCUIT
RELAY
ON
DIMENSIONS
11,6
5
2 x M5
LOAD
1 2
24-320VAC
25A
SN:1042xxxxx
ENDA
EPDA1-225Z
SSR
Made in Turkey
RELAY ON
INPUT
4 3
8-30V AC/DC
45 mm
24 mm
5
2 x M3
+ +
LOAD
1 2
24-320VAC
40A
ENDA
ESDA1-240Z
SOLID STATE
RELAY
SN:1042xxxxx
Made in Turkey
RELAY ON
8-30V AC/DC
INPUT
4 3
+ +
2 x M3
ENDA ETS-46-80
46mm
42mm
M3
M3
2
OUTPUT
AC
1
31 mm
2 x M3
29 mm
ENDA ETS-46-62
46mm
42mm
M3
M3
EPxA1-xxx-Z-EN-09-201007
