Fancy Foam Models IndoorDepron001 Assembly Instructions Manual

Rev. 2.0, 2-15-2012
Fancy Foam Models, LLC
635 Laramie Cir. Maize, Ks. 67101
www.fancyfoam.com
3Decathlon – Assembly Instructions.
Recommended Electronics and motors:
Motor: Hacker A10-15s outrunner or any equivalent motor
Speed control: Castle Creations PHX10, Thunderbird 9 or
equal.
Battery: 250 to 350, 2s , 20C rated or equivalent.
Receiver: 4 channel weighing less than 8 grams.
Servos: S75 or HS55 for ailerons, and S60 servos for the
tail. To get full throw, you must use a long dual servo arm
on ailerons.
Disclaimer: Fancy Foam Models has done everything
we can to caution and inform the end user regarding
the use of Lithium polymer battery technology. We
are in no way responsible for any damage that may
be caused by these batteries. Please read,
understand and follow all instructions for the
charger and batteries. Failure to use this battery
technology properly can result in the risk of fire. If
you are not comfortable with this technology, return
the batteries packs and kit to us for a refund. By
building the kit and using the batteries, you accept
full responsibility for the safety of these batteries.
Recommended building methods and glues:
Much of the construction of this model is done by laying
the parts on a flat table. It is strongly recommended that
you put wax paper down on the surface first so any excess
glue doesn't soak through the foam and glue the parts to
the table. For all assembly, use thin "foam safe" CA glue.
Gap filling or "medium" glue just adds weight. Always use
accelerant or "kicker" to get the glue to set. If possible,
apply the glue to one part and the kicker to the other part
and then press them together and hold until cured. Wipe
off any excess glue with tissues before it cures.
Wing Preparation:
Apply hinge tape to the top of the aileron hinge lines.
Carefully fold the aileron back onto the wing. Using
medium sandpaper and very light pressure sand the
inside of the vee so that the aileron will move freely.
On the "vee" side of the hinge, apply a 1" long piece of
hinge tape in the area of the bottom wing where the
control horn slots are (near the center of the wing).
Cut one flat carbon piece 32 1/2" long. Lightly sand the
"glue side" of the carbon strip to improve glue adhesion.
Lay the wing on a flat table (with wax paper underneath).
Carefully glue the flat carbon to the leading edge of the
wing. The easiest way is to apply glue to the flat carbon,
spray kicker on the wing leading edge and then bring the
two together (on a flat surface). Do one wing panel first,
then once it is cured, wrap the carbon past the wing
centerline and do the other half of the wing.
1
