Fancy Foam Models Funfly003 Assembly Instructions

Speed control: 10-12 amp.
Battery: 500mah, 3 cell, 20C rated Li-Po or equivalent.
Receiver: 4 channel.
Servos: (1) HXT 900 – Ailerons, (2)HXT 500 - Tail.
Disclaimer: Fancy Foam Models has done
everything we can to caution and inform the end
user regarding the use of Lithium polymer battery
technology. We are in no way responsible for any
damage that may be caused by these batteries.
Please read, understand and follow all instructions
for the charger and batteries. Failure to use this
battery technology properly can result in the risk of
fire. If you are not comfortable with this
technology, return the batteries packs and kit to us
for a refund. By building the kit and using the
batteries, you accept full responsibility for the
safety of these batteries.
Recommended building methods and glues:
Much of the construction of this model is done by
laying the parts on a flat table. It is strongly
recommended that you put wax paper down on the
surface first so any excess glue doesn't soak through
the foam and glue the parts to the table. For all
assembly, use "Welders" contact adhesive. The hinges
are also done with Welders, see our video on the web
site. Hot glue can be used to attach the servos and
control horns.
Starting out:
Look over the parts and dry fit them together to check
for proper fit.
When the spar glue is dry, hinge the ailerons to the
wing, elevator to the horizontal stabilizer and the
rudder to the vertical stabilizer.
1
