HARDWARE REFERENCE
Gateway Notebook

Advertisement

Table of Contents
loading

Related Manuals for Gateway MX7118

Summary of Contents for Gateway MX7118

  • Page 1 HARDWARE REFERENCE Gateway Notebook...

  • Page 3: Table Of Contents

    Gateway model and serial number ........
  • Page 4 Index ..............59 www.gateway.com...

  • Page 5: Chapter 1: About This Reference

    CHAPTER 1 About this reference • About this guide • Accessing the online User Guide • Gateway contact information • Microsoft Certificate of Authenticity • For more information...

  • Page 6: About This Guide

    This guide includes information and maintenance instructions that are specific to your model of Gateway notebook. For all other notebook information, see your online User Guide. In addition to this guide, the online User Guide has been included on your hard drive.

  • Page 7: Microsoft Certificate Of Authenticity

    The Microsoft Certificate of Authenticity label found on the bottom of your notebook includes the product key code for your operating system. For more information about your notebook, visit Gateway’s Support page at support.gateway.com or the Web address shown on your notebook’s label. The Support page also has links to additional Gateway documentation and detailed specifications.
  • Page 8 CHAPTER 1: About this reference www.gateway.com...

  • Page 9: Chapter 2: Checking Out Your Gateway Notebook

    CHAPTER 2 Checking Out Your Gateway Notebook • Identifying features • Connecting the AC adapter • Connecting the dial-up modem • Connecting to a cable or DSL modem or to an Ethernet network • Starting your notebook • Turning off your notebook •...

  • Page 10: Identifying Features

    CHAPTER 2: Checking Out Your Gateway Notebook Identifying features Front Speaker Power indicator Component Icon Description Speakers Provide audio output when headphones or amplified speakers are not plugged in. Power indicator LED on - notebook is on. ■ LED blinking - notebook is in Standby mode.

  • Page 11: Left

    Left Ventilation fan IEEE 1394 port Component Icon Description Memory card Insert a memory card from a digital camera, MP3 player, PDA, or cellular reader telephone into the memory card reader. For more information, see memory card reader” on page CompactFlash®, IBM Microdrive™, Memory Stick®, Memory Stick PRO®...

  • Page 12: Right

    CHAPTER 2: Checking Out Your Gateway Notebook Right Component Icon Description DVD drive Insert CDs or DVDs into this drive. For more information, see drive” on page the drive tray’s plastic cover and compare the logo to those listed in “Identifying drive types”...

  • Page 13: Back

    Back Ethernet jack Modem jack Power connector Monitor port Microphone jack Headphone jack Component Icon Description Modem jack Plug a modem cable into this jack. For more information, see the dial-up modem” on page Ethernet jack Plug an Ethernet network cable into this jack. Plug the other end of the cable into a cable modem, DSL modem, or an Ethernet network jack.

  • Page 14: Bottom

    CHAPTER 2: Checking Out Your Gateway Notebook Bottom Battery lock Battery latch Battery Component Icon Description Battery lock Slide to unlock the battery. For more information, see on page Battery latch Slide to release the battery. For more information, see...

  • Page 15: Keyboard Area

    Keyboard area Multi-function buttons Status indicators Component Icon Description Multi-function Press these buttons to open programs assigned to them or control the volume. buttons For more information, see Status indicators Inform you when a drive is in use or when a button has been pressed that affects how the keyboard is used.

  • Page 16: Connecting The Ac Adapter

    CHAPTER 2: Checking Out Your Gateway Notebook Connecting the AC adapter Warning Do not attempt to disassemble the AC adapter. The AC adapter has no user-replaceable or user-serviceable parts inside. The AC adapter has dangerous voltages that can cause serious injury or death. Contact Gateway about returning defective AC adapters.

  • Page 17: Protecting From Power Source Problems

    Protecting from power source problems Warning High voltages can enter your notebook through both the power cord and the modem connection. To protect your notebook and avoid electrical shock, use a surge protector. If you have a telephone modem, use a surge protector that has a modem jack.

  • Page 18: Connecting To A Cable Or Dsl Modem Or To An Ethernet Network

    CHAPTER 2: Checking Out Your Gateway Notebook Connecting to a cable or DSL modem or to an Ethernet network Your notebook has a network jack that you can use to connect to a cable or DSL modem or to an Ethernet network.

  • Page 19: Starting Your Notebook

    Starting your notebook Warning Do not work for long periods with the notebook resting on your lap. If the air vents are blocked, the notebook may become hot enough to harm your skin. Caution Provide adequate space around your notebook so air vents are not obstructed.

  • Page 20: Restarting (Rebooting) Your Notebook

    CHAPTER 2: Checking Out Your Gateway Notebook Restarting (rebooting) your notebook Important If your notebook does not turn off immediately, complete the following steps until the notebook turns off: 1. Press and hold the power button for about five seconds, then release it.

  • Page 21: Using The Status Indicators

    Using the status indicators Important If none of the indicators are on, you may need to press to toggle the status indicators on and off. Status indicators inform you when a drive is being used or when a button has been pressed that affects how the keyboard is used.

  • Page 22: Using The Keyboard

    CHAPTER 2: Checking Out Your Gateway Notebook Using the keyboard Tips & Tricks You can attach an external keyboard to the notebook using a USB port. You do not need to shut down the notebook to connect a USB keyboard.

  • Page 23: System Key Combinations

    System key combinations Key type Icon Description Press the F action. Numeric keypad Use these keys to type numbers when the numeric keypad is turned on. Press to turn on the numeric keypad. When you press the F key and a system key at the same time, your notebook performs the action identified by the text or icon on the key.
  • Page 24 CHAPTER 2: Checking Out Your Gateway Notebook Press and hold F , then To... press this system key... Skip back one CD song or DVD track. Skip ahead one CD song or DVD track. Turn on Num Lock so you can use the numeric keypad. Press this key combination again to turn off Num Lock.

  • Page 25: Using The Multi-Function Buttons

    Using the multi-function buttons Press the multi-function buttons to open the programs associated with them. Music player Volume up Volume down Button Icon Press to... Volume down Turn the volume down. Press the Volume Up and Volume Down buttons at the same time to mute or un-mute the sound.

  • Page 26: Using The Ez Pad Touchpad

    CHAPTER 2: Checking Out Your Gateway Notebook Using the EZ Pad touchpad Tips & Tricks For instructions on how to adjust the double-click speed, pointer speed, right-hand or left-hand configuration, and other touchpad settings, see “Changing the mouse or touchpad settings”...

  • Page 27: Adjusting The Volume

    Adjusting the volume Tips & Tricks For instructions on how to adjust the volume in Windows, see “Adjusting the Volume” in the online User Guide. To... Do this... Select an object on the screen. Start a program or open a file or folder.

  • Page 28: Turning Your Wireless Radio On Or Off

    For more information about using your notebook on a wireless network, see “Wireless Networking” in the online User Guide. Your Gateway notebook may have a factory-installed wireless networking mini-PCI card. To turn the wireless radio on or off: Press F + F2.

  • Page 29: Using The Dvd Drive

    Identifying drive types You can use your notebook to enjoy a wide variety of multimedia features. Your Gateway notebook may contain one of the following drive types. Look on the front of the drive for one or more of the following logos: If your drive has this logo...

  • Page 30: Inserting A Cd Or Dvd

    CHAPTER 2: Checking Out Your Gateway Notebook Inserting a CD or DVD Important When you place a single-sided disc in the tray, make sure that the label side is facing up. If the disc has two playable sides, place the disc so the name of the side you want to play is facing up.

  • Page 31: Using The Memory Card Reader

    Using the memory card reader Memory card types Inserting a memory card You can use memory cards to transfer pictures from a digital camera to your notebook. You can also use the memory card reader to transfer data between your notebook and a device that uses memory cards, such as a PDA, MP3 player, or cellular telephone.

  • Page 32: Using A Memory Card

    CHAPTER 2: Checking Out Your Gateway Notebook Using a memory card Removing a memory card Important Do not use the remove hardware icon in the taskbar to remove the memory card. If you use the remove hardware icon, your notebook may not recognize your memory card reader until you restart your notebook.

  • Page 33: Changing Batteries

    Changing batteries Warning Danger of explosion if battery is incorrectly replaced. Replace only with a battery specifically manufactured for your Gateway notebook. Discard used batteries according to local hazardous material regulations. The battery used in this device may present a fire or chemical burn hazard if mishandled.
  • Page 34 CHAPTER 2: Checking Out Your Gateway Notebook Slide the battery lock to the unlocked position, then slide and hold the battery release latch. Lift the battery out of the bay. Place a recharged battery into the bay and press down until it snaps into place.

  • Page 35: Recalibrating The Battery

    Recalibrating the battery Important Do not interrupt the battery recalibration process. If recalibration is interrupted, you must start the process over again. If your notebook unexpectedly goes into Standby mode while you are using it but the battery charge is not low, you may need to recalibrate your battery. You should also recalibrate the battery periodically to maintain the accuracy of the battery gauge.

  • Page 36: Ordering Accessories

    Carrying cases Gateway has large-capacity carrying cases if you need additional space for accessories or supplies. Memory Large programs, such as multimedia games or graphics programs, use a lot of memory.

  • Page 37: Chapter 3: Maintaining And Upgrading Your Notebook

    CHAPTER 3 Maintaining and Upgrading Your Notebook • Preventing static electricity discharge • Adding or replacing memory • Replacing the DVD drive • Replacing the hard drive kit • Replacing the keyboard...

  • Page 38: Preventing Static Electricity Discharge

    Adding or replacing memory Important Use only memory modules designed for your Gateway notebook. Tools Required You need a small Phillips screwdriver to replace memory. The components inside your notebook are extremely sensitive to static electricity, also known as electrostatic discharge (ESD).
  • Page 39 Turn your notebook over so the bottom is facing up, then remove the battery. For more information, see Remove the memory bay cover screw. Open the memory bay cover, then remove it. Gently press outward on the clip at each end of the memory module until the module tilts upward.

  • Page 40: Replacing The Dvd Drive

    CHAPTER 3: Maintaining and Upgrading Your Notebook Replacing the DVD drive Important Replace the DVD drive only with a similar drive provided by Gateway. Tools Required You need a small Phillips screwdriver to replace the DVD drive. Pull the memory module out of the slot.
  • Page 41 Remove the two DVD drive screws. Screw Screw Insert a straightened paper clip into the DVD drive’s manual eject hole, push in the paper clip to eject the drive tray, then pull the drive tray open. Carefully slide the drive out of the drive bay.

  • Page 42: Replacing The Hard Drive Kit

    Disconnect the AC adapter, modem cable, and network cable. Disconnect all peripheral devices and remove any PC cards. Turn your notebook over so the bottom is facing up, then remove the battery. For more information, see www.gateway.com Step Hard drive bay “Preventing static electricity discharge” on...
  • Page 43 Remove the hard drive kit screw. Slide the hard drive kit to remove it. If your new hard drive already includes the hard drive bracket, go to Step -OR- If you need to move the hard drive bracket from your old hard drive to...
  • Page 44 CHAPTER 3: Maintaining and Upgrading Your Notebook Remove the four screws that secure the hard drive to the hard drive kit bracket. Screw Screw www.gateway.com Screw Screw...
  • Page 45 Remove the bracket from the old drive. Insert the new drive into the bracket with the label side up and so the screw holes line up. Replace the four screws that secure the bracket to the drive. Slide the new hard drive kit into your notebook, then replace the screw that secures the hard drive kit to your notebook.

  • Page 46: Replacing The Keyboard

    CHAPTER 3: Maintaining and Upgrading Your Notebook Replacing the keyboard Important Replace the keyboard only with a similar keyboard provided by Gateway. Tools Required You need a small Phillips and a small flat-blade screwdriver to replace the keyboard. Removing the keyboard If your keyboard becomes damaged, you can replace it with a similar keyboard obtained from Gateway.
  • Page 47 Important Inserting a piece of cloth between the screwdriver and keyboard will help prevent damage to the notebook. Insert the small flat-blade screwdriver under the bottom of each hinge cover and gently loosen them. Insert the small flat-blade screwdriver under the bottom of the keyboard cover and gently pry it up.
  • Page 48 Lift the back edge of the keyboard slightly, then carefully push it toward the LCD panel to release the keyboard retaining tabs. Be careful not to damage the LCD panel. Lay the keyboard face down on the palm rest. www.gateway.com...

  • Page 49: Installing The Keyboard

    Installing the keyboard Important The keyboard cable is correctly oriented if it is not twisted. Lift the brown keyboard connector clip and remove the keyboard cable. Be careful not to touch or damage any other components. Keyboard connector clip Lift the old keyboard away from the notebook.
  • Page 50 Press down on the hinge covers until they click in place. Secure the keyboard cover with the two screws removed in Insert the battery, then turn your notebook over. Connect the power adapter, the modem cable, and the network cable, then turn on your notebook. www.gateway.com Step Step...

  • Page 51: Appendix A: Safety, Regulatory, And Legal Information

    APPENDIX A Safety, Regulatory, and Legal Information • Important safety information • Regulatory compliance statements • Environmental information • Notices...

  • Page 52: Important Safety Information

    AWG or larger telecommunications line cord. Your Gateway notebook is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this notebook, it is important that the safety instructions marked on the notebook and in the documentation are followed.
  • Page 53 The notebook does not operate properly when the operating ■ instructions are followed. The notebook was dropped or the cabinet is damaged. ■ The notebook performance changes. ■ Replacement parts and accessories Use only replacement parts and accessories recommended by Gateway. Important safety information...

  • Page 54: Regulatory Compliance Statements

    Because the wireless devices (which may be embedded into your notebook) emit less energy than is allowed in radio frequency safety standards and recommendations, Gateway believes these devices are safe for use. Regardless of the power levels, care should be taken to minimize human contact during normal operation.

  • Page 55: United States Of America

    Wireless devices are not user-serviceable. Do not modify them in any way. Modification to a wireless device will void the authorization to use it. Contact Gateway for service. Caution The transmitting device embedded in this notebook may not be used with any antenna other than the one provided with the notebook.
  • Page 56 Warning Warning FCC declaration of conformity Responsible party: Gateway Companies, Inc. 610 Gateway Drive, North Sioux City, SD 57049 (605) 232-2000 Fax: (605) 232-2023 Product: Gateway 7000 series ■ This device complies with Part 15 of the FCC Rules. Operation of this product is...

  • Page 57: Canada

    Wireless devices are not user-serviceable. Do not modify them in any way. Modification to a wireless device will void the authorization to use it. Contact Gateway for service. Caution The transmitting device embedded in this notebook may not be used with any antenna other than provide with the notebook.

  • Page 58: Japan

    The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the Ringer Equivalence Numbers of all the devices does not exceed 5. Japanese Modem Notice www.gateway.com...

  • Page 59: Laser Safety Statement

    EPA ENERGY STAR Environmental information All Gateway systems equipped with CD and DVD drives comply with the appropriate safety standards, including IEC 825. The laser devices in these components are classified as “Class 1 Laser Products” under a US Department of Health and Human Services (DHHS) Radiation Performance Standard.

  • Page 60: Notices

    Gateway is not responsible for inaccurate information which may appear in this manual. For the latest product updates, consult the Gateway Web site at www.gateway.com. In no event will Gateway be liable for direct, indirect, special, exemplary, incidental, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages.
  • Page 61 Notices Macrovision statement If your notebook has a DVD drive and an analog TV Out port, the following paragraph applies: This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners.
  • Page 62 APPENDIX A: Safety, Regulatory, and Legal Information www.gateway.com...

  • Page 63: Index

    Index AC adapter connecting connector accessories purchasing safety precautions airplane power adapter application key arrow keys audio adjusting volume back button headphone jack microphone jack muting next button pause button play button stop button automobile power adapter battery changing charge indicator charging installing latch...
  • Page 64 Index opening Firewire port Fn key folders opening function keys Gateway model number serial number Support hard drive indicator installing replacing headphone jack hot-swapping i.Link port IEEE 1394 port indicators See status indicators inkjet printer installing battery DVD drive hard drive...
  • Page 65 USB port programs closing unresponsive opening See memory rebooting notebook recalibrating battery replacing See installing resetting notebook restarting notebook right-clicking rocker switch safety general precautions...
  • Page 66 Index www.gateway.com...
  • Page 68 MAN SHADOW E/K8 HW REF R0 11/05...
