- Page 1 SWD222 - INSTRUCTIONS Assembly instructions for sit-stand desktop workstation with mounting for two monitors...
- Page 2 WARNING DO NOT REMOVE SAFETY TAPE FROM THE HEIGHT ADJUSTMENT HANDLE UNTIL ASSEMBLY IS COMPLETE. The column could extend quickly causing injury or damage. 1. Attach the vertical column (A) to the base (B) 2. Attach the keyboard tray (C) using screws (H) using screws (I) and the tool provided (M).
- Page 3 5. Keyboard tray height adjustment. 6. Monitor rail height and resistance adjustment. gure 1 gure 2 gure 3 Monitor height can be freely adjusted using the When assembly is complete, peel o the safety loop handle. tape from the handle ( gure 1). If the monitors are very light or very heavy and To unlock, pull the handle out ( gure 2) and the spring does not balance the weight of the...
- Page 4 Parts List Item Column Keyboard tray Monitor rail Monitor rail cap 6mm Flat washer 5mm Hex key 3mm Hex Key Keyboard wrist rest Do not lean on the Do not stand behind the Keep the area under keyboard tray column during adjustment the keyboard tray clear Maximum equipment Leave su cient clearance...
