fEaTurEs
Choosing a Channel
To choose a channel on the transmitter/
receiver press MENU and select with the
+ and – button. Press MENU to confirm.
Master Channel Selection*
All receivers on the same channel react to
channel changes of the transmitter and follow
automatically.
Multi Brand Connectivity*
All MKII receivers are equipped the Multi
Brand Connectivity Feature that makes them
compatible with most common non-DFS WHDI
wireless video transmitters on the market.
Choose a channel from different frequency sets
(marked with letters, e.g. A0) using the + and –
buttons and confirm with MENU. Channels used
by DwarfConnection show no letter (0-9). For
more detailed information, read the full product
manual provided on our website.
Use the MENU button to navigate to the OSD
menu and select the desired state by using
the + or – button. Confirm your selection with
MENU. An indicator on the OLED display of
the receiver shows the OSD state. With MKII
devices, the OSD shows a Record Indicator, so
you always know if the camera is recording.
Reducing Transmission Power
Use the MENU button to navigate to the
transmission power lever (shown as superscript
numbers next to the channel indicator).
Customize the transmission power using the
+ and – buttons and confirm your selection
with MENU. One step reduces 5 % of the
transmission power. The lowest transmission
power selectable is 10 %.
OSD
Encryption Mode*
To activate encryption mode, press and hold
the Menu button on your device to enter the
encryption menu. Use + or – to check either
ON or OFF and confirm with MENU. The main
menu will show either X ENC or ✓ ENC to
indicate weather encryption is on or off.
To link your devices, set your transmitter and
all the receivers to the same channel, then
activate encryption on your transmitter.
All receivers will follow into encryption mode
automatically. For more detailed information,
read the product manual provided on our
website.
Fan Control & Cinema Mode
To switch the fan on the transmitter /
receiver on or off, use the MENU button
to navigate to the fan menu and select the
desired state by using + or – turns the fans
on permanently. X turns the fans off.
AUTO selects cinema-mode, which triggers
the fans using the record and stop signals of
the camera. When recording is over the fan
starts automatically. (Cinema mode is bound
to metadata support and only available with
SDI connection.)
Caution!
Switching off the fans may be required
in some situations but doing this
permanently is not recommended.
Prolonged heat will affect the lifetime of
your wireless equipment.
If the temperature of your device exceeds
75°C/165° F, turn on the fans
immediately!
THERE IS NO EMERCENCY OUT!
Any damage caused by over-heating
voids warranty.
* only on MKII devices
