All manuals and user guides at all-guides.com CONTENTS Specification........Disassembly Instructions......03 Operation Check.........04 DVD DECK........05 adjustment......06 Alignment and Troubleshooting......... 08 Printed Circuit Boards......0 9 Wiring Diagram........16 Electrical Parts List....... 17 View........23 Exploded List......26 Mechanical Parts Schematic Diagrams......
All manuals and user guides at all-guides.com SPECIFICATION General Power Supply Requirements: DC 14 Negative Ground Load Impedance 4 ohms Maximum Output Power: 25W x 4(CH) Chassis Dimensions: 178 x 163x 50mm (W x D x H) DVD Deck Section Discs Played DVD, MPEG4,DIVX,VCD 1.0/2.0/3.0,MP3 WMA,CD,CD-R,CD-RW,Picture-CD...
All manuals and user guides at all-guides.com DISASSEMBLY INSTRUCTIONS 1.Mounting Box: Slide out the mounting box in parallel. 2.Top cover: Release screw at the back of top cover, and pull out the cover. 3.Bottom Cover: Turn over the unit to release the screws at the back of bottom cover and one the top surface.
All manuals and user guides at all-guides.com OPERATION CHECK GENERAL SPECIFICATIONS OF SIGNAL Standard frequency 1000 KHz (600, 1400 KHz) 98.0 MHz (90.0, 106.0 MHz) Signal output 74 dB/uV 60 dB/uV Modulation 1 kHz 1 KHz 22.5KHz FM mono AF output level AM/FM Power source voltage DC 14.4 V (backup voltage is the same as this )
All manuals and user guides at all-guides.com ADJUSTMENT FM IF/RF ADJUSTMENT Equipment Required FM IF/RF signal generator Oscilloscope Solid-state voltmeter (SSVM) Frequency counter Regulated DC power supply DC digital voltmeter Distortion meter FM IF and RF Alignment Using FM Signal Generator Note : Press the radio power switch to turn on the radio.
Page 8
All manuals and user guides at all-guides.com ADJUSTMENT AM /RF ADJUSTMENT Equipment Required >AM/RF signal generator >Oscilloscope >Solid-state voltmeter (SSVM) >Frequency counter >Regulated DC power supply >DC digital voltmeter >Distortion meter AM/RF and RF Alignment Using AM Signal Generator Note : Press the radio power switch to turn on the radio. Signal generator output must be kept as low as possible to avoid overload and clipping.
All manuals and user guides at all-guides.com TROUBLE SHOOTING Before going through the check list, check wiring connection. If any of the problems persist after checklist has been made, consult your nearest service dealer Symptom Causes Solution If the power supply is properly No Power The car ignition key not connected to the car accessory...
All manuals and user guides at all-guides.com WIRING DIAGRAM Радио антенна Коаксиальный выход Видео выход Монитор DVD проигрыватель Линейный аудио выход 4%х канальный усилитель Линейный аудио выход Выход на сабвуфер усилитель Синий Провод управления антенной, усилителем и т.д. Красный Замок зажигания Черный...
