Unit Operation
Key Function
IN
OUT
FIND
MARK
QUIT
PAGE
ENTR
V
V
Battery Installation
The GPSMAP 60Cx operates on two "AA" batteries (not includ-
ed), which are located in the back of the unit. Alkaline or NiMH
batteries may be used (see the Owner' s Manual to set the battery
type). Stored data is not lost when the batteries are removed.
1. To remove the battery cover
Locking
from the back of the unit,
Pin Slot
turn the D-Ring 1/4 turn
counter-clockwise and then
pull the cover away.
2. Insert the batteries, observ-
ing the proper polarity.
A polarity diagram can be
found molded into the battery
compartment.
3. Reinstall the battery cover by
inserting the bottom slot over
the tab at the base of the
unit and reinserting the
locking pin in the back of the
unit.
4. Turn the D-Ring 1/4 turn
Battery Compartment
clockwise to lock the cover in
place.
When replacing batteries, use only new
or fully charged batteries. Do not mix
Alkaline and NiMH batteries. Recharge-
able batteries may have less capacity than
disposable batteries.
Extensive use of backlighting and/or WAAS
as well as key beep tones will significantly
Battery Cover
reduce battery life.
Start-Up and Satellite Acquisition
Find a location where you have a clear view of the sky. If you're
starting up for the first time or you have moved over 600 miles since
last using the GPSMAP 60Cx, it must initialize (determine its loca-
tion by searching for satellites that are in position over your current
location.) Press the MENU key to use the Location option from the
Satellite Page Options Menu to mark your approximate location on
the Map Page so it looks for only those satellites above your location.
1. Turn On the GPSMAP 60Cx by pressing and releasing the
POWER key. A Welcome Page will briefly appear before
moving to the Satellite Page.
2. Observe the Satellite Page and the GPS status messages
as they appear at the top of the page.
• "Acquiring Satellites" message appears as the GPSmap
60C begins to search for satellites overhead.
• Your "Location Coordinates" display when four or
more satellites are fixed (enough to determine an ap-
proximate elevation as well as ground location).
Backlight
Adjustment
Slider
