REPAIR PARTS MANUAL
MODEL NO. 96017000900
Lawn Tractor
¨
412661 Rev. 1 05.08.07 AP
PRINTED IN U.S.A.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 96017000900 and is the answer not in the manual?

Questions and answers

Summary of Contents for Murray 96017000900

  • Page 1 REPAIR PARTS MANUAL MODEL NO. 96017000900 Lawn Tractor ¨ 412661 Rev. 1 05.08.07 AP PRINTED IN U.S.A.
  • Page 2: Table Of Contents

    The model number for your tractor can be found on the fender under the seat. When ordering parts, always give the following information: • Product - “Tractor” • Model Number - “96017000900” • Part Number • Part Description TABLE OF CONTENTS SCHEMATIC ........................
  • Page 3: Schematic

    TRACTOR - - MODEL NUMBER 96017000900 PRODUCT NO. 960 17 00-09 SCHEMATIC BATTERY STARTER FUSE AMMETER (OPTIONAL) WHITE CLUTCH / BRAKE ATTACHMENT CLUTCH (PEDAL UP) (CLUTCH OFF) BLACK BLACK SEAT SWITCH (NOT OCCUPIED) BLACK BLACK GRAY GRAY REVERSE SWITCH SHORTING CONNECTOR...
  • Page 4 REPAIR PARTS TRACTOR - - MODEL NUMBER 96017000900 PRODUCT NO. 960 17 00-09 ELECTRICAL 197428...
  • Page 5: Electrical

    REPAIR PARTS TRACTOR - - MODEL NUMBER 96017000900 PRODUCT NO. 960 17 00-09 ELECTRICAL PART DESCRIPTION 163465 Battery 74760412 Bolt Hex Hd 1/4-20 unc x 3/4 176689 Box Battery 176138 Switch Interlock 175688 Harness Asm Light W/4152j 4152J Bulb Light #1156 4799J Cable Battery 6 Ga.
  • Page 6 REPAIR PARTS TRACTOR - - MODEL NUMBER 96017000900 PRODUCT NO. 960 17 00-09 CHASSIS...
  • Page 7: Chassis

    REPAIR PARTS TRACTOR - - MODEL NUMBER 96017000900 PRODUCT NO. 960 17 00-09 CHASSIS PART DESCRIPTION 174619 Chassis 176554 Drawbar, Stretch 155272 Bumper, Hood/Dash 193510X010 Dash 72140608 Bolt, Carriage 3/8-16 x 1 174996 Panel Dash LH 172105X010 Panel Slkscr Dash RH...
  • Page 8: Drive

    REPAIR PARTS TRACTOR - - MODEL NUMBER 96017000900 PRODUCT NO. 960 17 00-09 DRIVE drive-hydro.stlt_64...
  • Page 9 REPAIR PARTS TRACTOR - - MODEL NUMBER 96017000900 PRODUCT NO. 960 17 00-09 DRIVE PART PART DESCRIPTION DESCRIPTION - - - - - - - - - Transaxle, 322-0510 134683 Guide Belt Mower Drive RH (Order Parts From Transaxle Manu-...
  • Page 10: Steering

    REPAIR PARTS TRACTOR - - MODEL NUMBER 96017000900 PRODUCT NO. 960 17 00-09 STEERING steering_pl.lt_68...
  • Page 11 REPAIR PARTS TRACTOR - - MODEL NUMBER 96017000900 PRODUCT NO. 960 17 00-09 STEERING PART DESCRIPTION 186780 Wheel Steering 195673 Axle Asm 169840 Spindle Asm LH 169839 Spindle Asm RH 6266H Bearing Race Thrust Harden 121748X Washer 25/32 x 1-5/8 x 16 Ga.
  • Page 12: Engine

    REPAIR PARTS TRACTOR - - MODEL NUMBER 96017000900 PRODUCT NO. 960 17 00-09 ENGINE OPTIONAL EQUIPMENT Spark Arrester engine-bs.1cyl_66...
  • Page 13 REPAIR PARTS TRACTOR - - MODEL NUMBER 96017000900 PRODUCT NO. 960 17 00-09 ENGINE PART DESCRIPTION 170551 Control Th/ch Flag 17720408 Screw Hex Thd Cut 1/4-20 x 1/2 - - - - - - - - Engine, B&S 31A607 (Order parts from engine manufacturer) 137352 Muffler Exhaust B&S...
  • Page 14: Mower Deck

    REPAIR PARTS TRACTOR - - MODEL NUMBER 96017000900 PRODUCT NO. 960 17 00-09 MOWER DECK 42_deck_man-t-path_3...
  • Page 15 REPAIR PARTS TRACTOR - - MODEL NUMBER 96017000900 PRODUCT NO. 960 17 00-09 MOWER DECK PART PART DESCRIPTION DESCRIPTION 165892 Mower Deck Assembly, 42" 137729 Screw, Thdrol 1/4-20 x 5/8 T 72140506 Bolt 133944 Washer, Hardened 138017 Bracket Asm Fr. Sway Bar 3/42...
  • Page 16: Mower Lift

    REPAIR PARTS TRACTOR - - MODEL NUMBER 96017000900 PRODUCT NO. 960 17 00-09 MOWER LIFT 16 17 lift-rh.1piece_3 PART PART DESCRIPTION DESCRIPTION 159460 Wire Asm Inner/Sprg w/plunger 173288 Link Front 159471 Shaft Asm Lift RH 73350800 Nut Jam Hex 1/2-13 unc...
  • Page 17: Decals

    REPAIR PARTS TRACTOR - - MODEL NUMBER 96017000900 PRODUCT NO. 960 17 00-09 DECALS PART PART DESCRIPTION DESCRIPTION 413702 Decal, Side Panel 145005 Decal, Caution Battery 412733 Decal, Replacement 411658 Decal, Fender Warning 408817 Decal, Engine HP 160396 Decal, V-Belt Sch.
  • Page 18: Seat

    REPAIR PARTS TRACTOR - - MODEL NUMBER 96017000900 PRODUCT NO. 960 17 00-09 SEAT seat_lt.knob_13 PART PART DESCRIPTION DESCRIPTION 197895 Seat 121248X Bushing Snap Blk Nyl 140551 Bracket Seat Pivot 72050412 Bolt Rdhd Sht Nk 1/4 - 20 x 1 -1/2...
  • Page 19 SERVICE NOTES...
  • Page 20: Warranty

    LIMITED WARRANTY The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in materi- als and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we find to be defective due to materials or workmanship.
