Summary of Contents for Grant C1G
- Page 1 Refrigerated immersion Coolers C1G, C1GL C2G, C2GL Operating Manual...
-
Page 3: Table Of Contents
CONTENTS Safety Getting started Unpacking Installation 2.2.1 C1G, C2G Specifications Maintenance and service C1G, C2G Cleaning Replacement of fuses Guarantee Service Compliance... -
Page 4: Safety
Safety The following symbols marked on the equipment mean:- Caution: Read these operating instructions fully before use and pay particular attention to sections containing this symbol Caution: Surfaces can become hot during use. Always observe the following safety precautions • Use only as specified by the operating instructions, or the intrinsic protection may be impaired. -
Page 5: Getting Started
2.2.1 C1G, C2G The C1G and C2G are designed for use with the Grant Optima, Y and W Series baths. The C2G is only suitable for fitting in the 26, 28 and 38 litre baths. For fitting coiling coil in the Optima, Y and W series baths refer to instruction included with cooling coil locator pack. -
Page 6: Specifications
Specifications Cooling power @ 20°C 350W 400W @ 0°C 110W 320W Overall power 300VA 500VA consumption Refrigeration gas R134A 100g 160g Dimensions d/w/h 460/305/225mm 460/305/225mm Flexible pipe length 925mm 925mm Coil Diameter 77/55mm 77/105mm /length Electrical Supply 240V 50 Hz 240V 50Hz 120V 60Hz 120V 60Hz... -
Page 7: Maintenance And Service
Maintenance and Service All Grant laboratory products are designed to comply with IEC61010-1 and can be flash tested. Some are fitted with radio frequency interference suppressors. Therefore it is recommended that only a d.c. test is performed. C1G, C2G Dust the refrigeration condenser: Cooling power will be reduced if the fins behind the front grille become clogged with dust. -
Page 8: Guarantee
When used in laboratory conditions and according to these working instructions, this equipment is guaranteed for THREE YEARS against faulty materials or workmanship. Service repairs outside of the guarantee period, carried out by Grant Instruments, carry a further one year guarantee. -
Page 9: Compliance
For information regarding WEEE collections in the UK please contact our B2B Compliance Scheme directly on 01691 676 124 Grant Instruments complies fully with the Waste Electrical & Electronic Equipment (WEEE) regulations 2006. We are a member of the B2B compliance scheme (Scheme Approval Number WEE/MP3338PT/SCH), which handle our WEEE obligations on our behalf. - Page 10 Notes...
- Page 12 Grant Instruments (Cambridge) Ltd Representative in the European Union Shepreth Grant Instruments Europe B.V Cambridgeshire Strawinskylaan 411 SG8 6GB WTC, Tower A, 4th Floor 1077 XX AMSTERDAM THE NETHERLANDS Tel: +44 (0) 1763 260811 salesdesk@grantinstruments.com grant@eu.grantinstruments.com www.grantinstruments.com 16601 V9 DMN S90 July 2021...
