- Page 1 BONECO 2055 Umschlag 2055 07.05.2003, 1:27 Uhr...
- Page 2 Instructions for use Käyttöohje BD_2055-en/fi/pl.p65 11.05.2003, 1:38 Uhr...
-
Page 3: Usage Tips
A specially tuned antibacterial protection system (Ionic Silver Stick) prevents germ formation in the water bath. Thus, no chemical additives are necessary to Congratulations on your choice of the Air Washer 2055. disinfect the water. Did you know that dry room air... - Page 4 Esipuhe Erityisesti tähän tarkoitukseen sovitettu antibakteerinen suojajärjestelmä (Ionic Silver Stick) estää mikrobinmuodostusta vesihauteessa. Tämän takia ei tarvita Sydämelliset onnittelumme siitä, että olette valinneet Air Washer 2055:n. kemiallisia lisäaineita veden desinfioimiseksi. Tiesitkö, että liian kuiva huoneilma kuivattaa limakalvoja sekä aiheuttaa huulten rohtumista ja silmien kirvelyä? Turvaohjeita edistää...
- Page 5 BD_2055-en/fi/pl.p65 11.05.2003, 1:38 Uhr...
-
Page 6: Pakkauksen Avaaminen
Unpacking Remove the air washer carefully from the packaging; the top section is only placed on the base tray; it is not attached. Remove all strips of cardboard from the disc pack (5). Use the original packaging for storing the appliance if you do not use the air washer all year round. -
Page 7: Laitteen Sijoitus
Setting up Check the mains rating information on the rating plate. Place the air washer on the floor, or a flat, dry surface in the room. The rating plate is on the underside of the base tray (a). Ensure that there is good access to the air washer and that there is sufficient space for maintenance and cleaning. -
Page 8: Power Cable
Power cable The overall length of the power cable is approx. 2 m and is adjustable. To remove the cover (a) 1. Insert a screwdriver in the hole as shown. 2. Press out (2) 3. Push up (3) Pull out the cable from the cable compartment Adjust the cable to the length desired by pulling/pushing Store the remaining cable in the cable compartment Johto... - Page 9 Filling/re-filling the tank Only fill the water tank with fresh, cold tap water. Do not put the water tank under pressure, e.g. by filling with carbonated mineral water. Do not add any essential oils or fragrances to the water; the plastic material might then become discoloured and damaged.
-
Page 10: Putting Into Operation
Putting into operation Connect the air washer to the mains supply. Place the rotary switch in position • • as required. The green lamp (LED) lights. To switch off, place the switch in position 0. The air washer operates particularly quietly in night mode (setting•), •... - Page 11 Water purification An Ionic Silver Stick keeps the water pure. The anti-microbial action of silver is used (silver is effective against more than 650 bacteria and virus types). The Ionic Silver Stick releases an exactly proportioned amount of silver ions to the water over a long period (approx. two years).
- Page 12 Fragrances A special fragrance container is in the tray. A cotton pad moistened with fragrance can be placed in it. Place fragrances in this container only. Hajusteet Kaukalossa on erityinen hajustesäiliö. Tähän säiliöön voidaan asettaa hajusteella kostutettu vanutuppo. Täytä hajusteita ainoastaan tarkoitukseen varattuun säiliöön! BD_2055-en/fi/pl.p65 11.05.2003, 1:38 Uhr...
- Page 13 Cleaning – water tank and base tray every 2 weeks humidification discs every 4 weeks First clean the housing with a damp cloth and wipe dry; if necessary use a plastics cleaner. Regular cleaning is a prerequisite for hygienic, malfunction-free operation. The recommended cleaning intervals are dependent on the quality of the air and water, as well as on the operating time.
-
Page 14: Cleaning The Fan
Cleaning the water tank and base tray Wipe clean the interior of the upper housing once or twice a year using a moistened cleaning cloth (7). Cleaning the fan The fan is located under the cover. It can be cleaned when required, using a moistened cleaning cloth (10). - Page 15 Before cleaning, remove the Ionic Silver Stick from the base tray. Remove deposits from the base tray using a plastic or wooden brush and a commercially available, diluted cleanser. Cleaning the humidification discs Pour a commercially available decalcifier into the water-filled base tray and allow it to work in.
- Page 16 Cleaning the humidification discs (continued) Proceed as follows to clean individual humidification discs: Loosen the rotary lock (a). Remove the discs individually (b). When placing the discs in a dishwasher, be careful not to bend or squeeze them. DO NOT wash at temperatures above 55 °C –...
- Page 17 Rectifying malfunctions Problem Possible cause Rectification Does not operate Mains cable not plugged in. Connect to the mains. • Rotary switch is set to (0). Set rotary switch to (•/ Scraping noise Disc pack not placed correctly in the Insert disc pack correctly. base tray.
-
Page 18: Käytöstä Poisto
Storage Disposal Empty the water tank. Return your worn out air washer to your dealer for proper disposal. Clean the air washer as described and leave to dry fully. Remove bayonet lock from water tank and store separately in order to spare the You can obtain information on other ways to dispose of your appliance from washers. -
Page 19: Spare Parts
Spare parts You can purchase the spare parts shown from your dealer and replace them yourself. It is only permitted to use original parts from the manufacturer. All other repairs are only to be made by qualified service engineers or customer service. -
Page 20: Warranty
Technical data BONECO 2055 Warranty Legal notice See attached warrants card. The air washer is UL-listed. Dimensions (LxBxH) 14.8“x12.5“x16.6“m Cable length approx. 78.7“ Subject to technical change. Weight empty approx. 138bs The instructions for use are protected Mains voltage 120V/60 HZ by copyright. - Page 21 BONECO is a brand name of Plaston, Switzerland. Umschlag 2055 07.05.2003, 1:27 Uhr...
