- Page 1 Instruction manual IndustrialsPC 09/2021 www.christ-es.com...
-
Page 2: Table Of Contents
Accessories and Spare Parts Software 7.1 BIOS Basic Settings 7.1.1 COM Port configuration 7.1.2 Set Boot Priority 7.2 BIOS Update 7.2.1 Preparation 7.2.2 Perform Update 7.3 OBS Client 7.3.1 Activating the OCB Client Document No.: PA10009320 2 / 33 Sep. 2021, Revision 00... -
Page 3: Table 16: Mechanical Specifications
9.2 Electrical Specifications 9.2.1 Power Consumption 9.3 Electromagnetic Compatibility 9.4 Environmental Conditions Standards and Approvals 10.1 CE Marking 10.2 RoHS 10.3 Electromagnetic Compatibility 10.4 Environmentally Appropriate Disposal Technical Support 11.1 Device Seal Document No.: PA10009320 3 / 33 Sep. 2021, Revision 00... -
Page 4: Identification
No part of this documentation may be reproduced in any form or processed, duplicated or distributed using electronic systems without the prior written consent of Christ Electronic Systems GmbH. Even trans- lation into another language requires written permission. This documentation is entrusted exclusively to the owner of the device or employees of Christ Electronic Systems GmbH for personal use. - Page 5 CAUTION Indicates a possible dangerous situation Failure to observe the advice can result in injuries or property damage NOTICE Indicates user tips and useful information Important information to avoid malfunctions Document No.: PA10009320 5 / 33 Sep. 2021, Revision 00...
-
Page 6: Product Description
The Industrial PCs can be loaded with either Windows or Linux before delivery and are then immedi- ately ready for use. Thanks to the compact housing design, Christ Industrial Computers can also be optimally used in con- fined spaces. Despite their small size, they deliver high performance when required. -
Page 7: System Overview
4 x USB: 2 x USB 2.0 Port (Type A); 2 x USB 3.0 Port (Type A) 2 x 1 GBit Ethernet (RJ45) 1 x RS-232 / RS-422 / RS-485 (Bios setting) (Sub-D) 1 x Display Port 1.1 Table 3: System overview Titanium Document No.: PA10009320 7 / 33 Sep. 2021, Revision 00... -
Page 8: Housing Variant Industrial Pc
DIN Rail, 35 mm x 7.5 mm, DIN Rail 35 mm x 15 mm Interface Area Table 4: Industrial PC Front Illustration 2: Dimensions Industrial PC Architecture Argon Titanium Table 5: Dimensions Industrial PC Document No.: PA10009320 8 / 33 Sep. 2021, Revision 00... -
Page 9: Add-On
100 % in 80 seconds Configuration Shutdown Time Dimming Time Dimming Intensity The instruction for the UPS can be found in the FAQ section of the Christ website: FAQ - Questions and Answers Document No.: PA10009320 9 / 33 Sep. 2021, Revision 00... -
Page 10: Description Hardware
StdA_SSRX- SuperSpeed transmitter differential pair StdA_SSRX+ SuperSpeed transmitter differential pair GND_DRAIN Ground for signal return StdA_SSTX- SuperSpeed receiver differential pair StdA_SSTX+ SuperSpeed receiver differential pair Table 8: Pinout USB 3.0 Document No.: PA10009320 10 / 33 Sep. 2021, Revision 00... -
Page 11: Table 9: Pinout Ethernet
Receive Data - Bidirectional + Bidirectional - Table 9: Pinout Ethernet WLAN Mating SMA / RP-SMA Connector Description Transmis- 802.11 ac/a/b/g/n (2.4 GHz, 5 GHz) sion Stand- Table 10: Pinout WLAN Document No.: PA10009320 11 / 33 Sep. 2021, Revision 00... -
Page 12: Table 11: Pinout Com Connector Titanium
Send nected nected Clear To n.c. not con- n.c. not con- Send nected nected Ring Indica- n.c. not con- n.c. not con- nected nected Table 11: Pinout COM Connector Titanium Document No.: PA10009320 12 / 33 Sep. 2021, Revision 00... -
Page 13: Table 12: Pinout Com Connector Celeron N3350 Argon
Request To not con- not con- n.c. n.c. Send nected nected Ring Indica- n.c. not con- n.c. not con- nected nected Table 12: Pinout COM Connector Celeron N3350 Argon Document No.: PA10009320 13 / 33 Sep. 2021, Revision 00... -
Page 14: Table 13: Pinout Display Port
DP++ is required for this. Display Port 1.1 is also known as "Dual-Mode Display Port" and "Display Port++". This allows compatibility with DVI and HDMI. The Argon board uses DP1.0 Document No.: PA10009320 14 / 33 Sep. 2021, Revision 00... -
Page 15: Environmental Conditions
The protection class only can be guaranteed under the following conditions: • The device is installed correctly • All components and covers of the interfaces are assembled • Compliance with all environmental conditions Document No.: PA10009320 15 / 33 Sep. 2021, Revision 00... -
Page 16: Assembly And Commissioning
Make sure that the device is installed so that is accessible for the operator. Installation instructions Check the package contents for any visible damage and for completeness. In case of damage, do not install the device and contact the Christ Service. Document No.: PA10009320 16 / 33 Sep. 2021, Revision 00... -
Page 17: Connection Of The Power Supply
The industrial PC hangs on the fastening rail. an angle from above. Press the Industrial PC down until it hooks into place. Illustration 4: Mounting Industrial PC Step 1 Illustration 5: Mounting Industrial PC Step 2 Document No.: PA10009320 17 / 33 Sep. 2021, Revision 00... -
Page 18: Dismounting Industrial Pc
Tilt the Industiral PC forward with the pull cord trial PC. pulled at the bottom and unhook it at the top. Illustration 6: Dismounting Industrial PC Step 1 Illustration 7: Dismounting Industrial PC Step 2 Document No.: PA10009320 18 / 33 Sep. 2021, Revision 00... -
Page 19: Accessories And Spare Parts
Industrial PC Instruction Manual Accessories and Spare Parts The accessories listed here have been checked by Christ and are compatible with the products. The following accessories are available: Power supply Input Voltage 90 - 264 VAC Input Current max. 1 A... -
Page 20: Software
Software The x86 architecture has a BIOS (Basic Input Output System) for the basic settings of the system. This is not present in the ARM architectures. Here, updates are performed with CURT (Christ Update and Re- covery Tool). BIOS Basic Settings AMI BIOS ROM has built-in settings program that allows users to make basic settings. -
Page 21: Set Boot Priority
2. Select "Boot mode select" "UEFI" 3. Open the "Boot Option #1" by pressing the "Enter" key 4. Select USB device with "Enter" 5. Save with keystroke "F4" (confirmation with "Yes") Document No.: PA10009320 21 / 33 Sep. 2021, Revision 00... - Page 22 Industrial PC Instruction Manual llustration 10: BIOS Boot Priority Document No.: PA10009320 22 / 33 Sep. 2021, Revision 00...
-
Page 23: Bios Update
Industrial PC Instruction Manual BIOS Update 7.2.1 Preparation Copy the AMI BIOS update files to a USB stick You can obtain the required files from Christ Electronic Systems. These are the same for Argon and Tita- nium. • • flash.nsh •... - Page 24 Restore the power supply and enter the BIOS again (do not reboot) • Press the F3 key to confirm the question "Load Optimized Defaults" with "Yes" • Press the F4 key to save and exit Document No.: PA10009320 24 / 33 Sep. 2021, Revision 00...
-
Page 25: Obs Client
Illustration 16: Start OBS Client These functions are provided by the OBS Client: System Information The System Information provides information about the processor and the operating system. Illustration 17: OBS Client System Information Document No.: PA10009320 25 / 33 Sep. 2021, Revision 00... -
Page 26: Redo Backup And Recovery
FAQ - Questions and answers Enhanced Write Filter EWF Instructions on how to set EWF and UWF filters can be found in the FAQ section of the Christ website: FAQ - Questions and Answers Document No.: PA10009320 26 / 33... -
Page 27: Maintenance
The cleaning agent must not be applied directly to the device. Under no circumstances may aggressive solvents, chemicals or scouring agents be used. Maintenance It does not require any maintenance on the part of the user. Document No.: PA10009320 27 / 33 Sep. 2021, Revision 00... -
Page 28: Technical Data
25 W Titanium up to 45 W Table 18: Power Consumption NOTICE Specifications are maximum values Peripheral devices are considered (e.g. 1 x USB 2.0 equals 2,5 W) Document No.: PA10009320 28 / 33 Sep. 2021, Revision 00... -
Page 29: Environmental Conditions
5 ~ 80 % (non condensing) Protection Class (Standard Con- IP20 ditions) Transportation and Storage Suitable packing increases shock resistance max. Installation Altitude 2000 m Cooling Natural Air Convection Table 20: Environmental Conditions Document No.: PA10009320 29 / 33 Sep. 2021, Revision 00... -
Page 30: Standards And Approvals
The device has been tested in accordance with the applicable EU directives and the associated harmonized standards. NOTICE Decleration of Conformity The declaration of Conformity can be downloaded from the Christ Electronic Systems Homepage. 10.2 RoHS The device complies with the requirement of the EU Directive RoHS 2011/65/EU. -
Page 31: Technical Support
11.1 Device Seal A device seal is affixed to every Christ device in order to prove whether the device has been opened by a third party. In case of a defect, please do not open the device, but contact our service department. - Page 32 Illustration 15: Task Manager - enable OBS Client Illustration 16: Start OBS Client Illustration 17: OBS Client System Information Illustration 18: OBS Client Hardware Monitor Illustration 19: OBS Client Settings Document No.: PA10009320 32 / 33 Sep. 2021, Revision 00...
- Page 33 Table 13: Pinout Display Port Table 14: Power supply Table 15: BIOS Table 16: Mechanical Specifications Table 17: Electrical Specifications Table 18: Power Consumption Table 19: Electromagnetic Compatibility Table 20: Environmental Conditions Document No.: PA10009320 33 / 33 Sep. 2021, Revision 00...
