Quick Start Guide
EE1CL-1-W*
Introduction
Welcome to KBC Networks' Quick Start Guide for
the EE1CL, 10/100 Ethernet line driver. This
document provides some quick tips on how to
get up and running. For more detailed
information see the Downloads section below.
Features:
Automatic data rate adjustment
•
Up to 100Mbps symmetrical line rate
•
supported
Transmission distances up to 3km
•
Selectable transmission modes
•
Compact unit
•
High density rack system
•
10/100 auto-sensing
•
MDI/MDIX
•
Downloads
Installation manual
Other features and functions are described in the
unabridged manual:
http://www.kbcnetworks.com/extended-
ethernet-100-series/network-products/ee1cl
Specification sheet:
http://www.kbcnetworks.com/extended-
ethernet-100-series/network-products/ee1cl
Release notes:
http://www.kbcnetworks.com/downloads
Quick_Start_Guide-EE1CL-Rev1207A
Copyright © KBC Networks Ltd. 2012
Extended Ethernet 100 Series
System Contents
Qty Description
1
Extended Ethernet unit
1
5Vdc, 2A Power Supply Unit
Equipment Required for Deployment
You will need a 5Vdc, 2A power supply; this is
supplied with the unit.
www.kbcnetworks.com
