- Page 1 Extended Ethernet 100 Series Chassis EE1R3 User Manual...
-
Page 2: Table Of Contents
SYSTEM INSTALLATION EXAMPLE ............7 DIMENSIONS ................8 WARRANTY ................9 ................9 ARRANTY NFORMATION A ITE .................... 10 LASS FCC ....................... 10 UL ......................10 INSTRUCTION OF DISASSEMBLY ............11 Manual-EE1R3_Series-Rev1208A Copyright © KBC Networks Ltd. 2012 Page 2 of 12 www.kbcnetworks.com... -
Page 3: Overview
Extended Ethernet User Manual 1 Overview 1.1 Introduction This manual covers the EE1R3 chassis to be used with the KBC EE1CL series 10/100 Ethernet line drivers. 1.1.1 EE1R3 The EE1R3 chassis allows the KBC EE1CL series, 10/100 Ethernet line drivers to be mounted in a 2.4U, 19”... -
Page 4: Installation
Please contact you dealer or distributor if a part is missing or damaged within 10 days of receiving products. 2.2 Configurations 2.2.1 Physical Connections P1 P2 FA FB Chassis front view Chassis rear view Manual-EE1R3_Series-Rev1208A Copyright © KBC Networks Ltd. 2012 Page 4 of 12 www.kbcnetworks.com... -
Page 5: Installation Method
With the power switch in the ‘OFF’ position, connect the power cord and then select the ‘ON’ position for the power switch. Insert the EE1CL units into the EE1R3 chassis as required. Connect required media cables to the EE1CL devices. -
Page 6: Led Status
The fan is functioning correctly FAN A The fan is not powered or there is a fault with the fan Note: PWR2 and FAN B LEDs are not used on this product. Manual-EE1R3_Series-Rev1208A Copyright © KBC Networks Ltd. 2012 Page 6 of 12 www.kbcnetworks.com... -
Page 7: Troubleshooting
With power to the chassis the green fan light should be lit to show that the fan is functioning correctly. If the fan LED remains off when the power is on there is a fault with the Fan please contact KBC Networks. 4 System Installation Example Figure 4.1 EE1R3 Typical System Installation... -
Page 8: Dimensions
Extended Ethernet User Manual 5 Dimensions 440mm P1 P2 FA FB Chassis depth 140mm Chassis front view Chassis rear view Manual-EE1R3_Series-Rev1208A Copyright © KBC Networks Ltd. 2012 Page 8 of 12 www.kbcnetworks.com... -
Page 9: Warranty
KBC, to be defective in material or workmanship, KBC will repair or replace such part or portion at KBC’s option. The warranty period on the repaired or replaced part or portion of this product shall be limited to the unexpired term of the original warranty. -
Page 10: Classa Ite
Reliable Earthing - Reliable earthing of rack-mounted equipment should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuit (e.g. use of power strips). Manual-EE1R3_Series-Rev1208A Copyright © KBC Networks Ltd. 2012 Page 10 of 12 www.kbcnetworks.com... -
Page 11: Instruction Of Disassembly
2. Remove cover plate. 3. Remove mounting screws for printed circuit board (PCB). 4. Take out all PCBs. Notice: When a product reaches the end of its life, return to KBC Networks. Manual-EE1R3_Series-Rev1208A Copyright © KBC Networks Ltd. 2012 Page 11 of 12... - Page 12 KBC Networks 25691 Atlantic Ocean Drive Suite 3B Lake Forest, CA 92630 U.S.A Americas Phone: 1-949-297-4930 Fax: 1-949-297-4933 KBC Networks Ltd., EMEA KBC Networks Ltd. Barham Court Teston, Maidstone Kent, ME18 5BZ United Kingdom Phone: +44(0)1622 618787 Fax: +44(0)20 7100 8147 Email: info@kbcnetworks.com...
