Quick Start Guide
EE2CL Extended Ethernet 200 Series
Introduction
Welcome to KBC Networks' Quick Start Guide for the EE2CL, 10/100
Ethernet line driver and kits. This document provides some quick tips on
how to get up and running. For more detailed information see the
Downloads section below.
Features
IEEE 802.3af/at compliant
•
Supports up to 4 IP cameras
•
Straight forward configuration
•
High data rates
•
LED indicators
•
Transmission distances up to 1.5km
•
Compact unit
•
High density rack system
•
Downloads
Installation manual - other features and functions are described in the unabridged manual:
http://www.kbcnetworks.com/downloads
Specification Sheets:
http://www.kbcnetworks.com/downloads
Joining Guide (Where there are 2 or more master units connected to a switch)
http://www.kbcnetworks.com/downloads
System Contents
EE2CL-1KT
Qty Description
2
EE2CL Extended Ethernet unit
1
48Vdc, 1.25A Power Supply Unit
EEC2L-2KT
Qty Description
3
EE2CL Extended Ethernet unit
1
48Vdc, 1.25A Power Supply Unit
1
BNC-T Splitter Adaptor
QSG-EE2CL_Series-Rev1304.docx
Copyright © KBC Networks Ltd. 2014
www.kbcnetworks.com
Advertisement
Table of Contents
Related Manuals for KBC EE2CL
Summary of Contents for KBC EE2CL
-
Page 1: Quick Start Guide
EE2CL Extended Ethernet 200 Series Introduction Welcome to KBC Networks’ Quick Start Guide for the EE2CL, 10/100 Ethernet line driver and kits. This document provides some quick tips on how to get up and running. For more detailed information see the Downloads section below. -
Page 2: Basic Configuration
Depending on power requirements and cable distances power for both the Master and Slave EE2CL units and the IP cameras can be supplied from the PSU located at the Master EE2CL unit. For high power or long distance systems, multiple PSU units will be required; see the full KBC Networks’ manual for further... - Page 3 Connect the supplied 48Vdc PSU to the EE2CL unit Connect the RJ45 cable from the EE2CL unit to the Control Room equipment. The green LEDs will light when a network link is established and flash to show when data traffic is being passed.
- Page 4 Need Help? Visit our website http://www.kbcnetworks.com or contact your nearest KBC office or dealer: Phone: +1 949 297 4930 Toll Free: +1 888 366 4276 Email: techsupport@kbcnetworks.com...
