Page 2
THANK YOU FOR YOUR PURCHASE OF OUR SNOW PLOW ENCLOSED IN THIS KIT IS THE ATTACHING HARDWARE KIT TO HAVE A COMPLETE PLOW ASSEMBLY, YOU MUST HAVE AT LEAST FOUR BOXES: 1. MODEL SPECIFIC ATTACHING HARDWARE KIT: TO ATTACH THE UNIVERSAL PUSH TUBE TO ATV. 2.
Page 3
Model Number 15-3591 Parts List ITEM NO. QTY. PART NO. DESCRIPTION 1 CYC3699 Attaching Bracket 2 CYC3700 Support Plate 3 CYC4306 Spacer 2 PUR1209 Clevis Pin-10mm x 35mm 2 PUR1249 #3 Hair Pin 2 PUR3194 8mm X 30mm X 70mm Sq U-Bolt 2 PUR3193 8mm X 30mm X 50mm Sq U-Bolt 2 PUR3056 Carriage Bolt 8 x 40mm 4 PUR3068 Nylon Lock Nut M8...
Page 4
WARNING Due to reduced ground clearance remove plow Mount Brackets before trail riding. Do not exceed 5 MPH with the blade or its brackets installed ♦ Periodically check for wear and tightness of all bolts, nuts and fasteners. Replace or tighten as necessary All directions referring to the right and the left are when the operator is sitting on the ATV.
Page 5
If manual lift kit #15-0015 is used, choose from the options and illustrations below for the routing of the lift strap. Option 1 Route the lift strap through the storage rack of the ATV as shown in two examples below. Your strap may appear different than the strap shown below. Option 2 1.
One Year Limited Warranty For the period of one (1) year from the purchase date, Cycle Country (a Kolpin Powersports Brand) will re- place for the original purchaser, free of charge, any part or parts found upon examination by Cycle Country to be defective in material, workmanship, or both.
