1701 38TH AVE W
PO BOX 257
SPENCER, IA 51301
PHONE: 712-262-4191
FAX: 712-262-0248
SERVICE: 800-841-2222
E-MAIL: ccac@cyclecountry.com
www.cyclecountry.com
UTV
TM
SNOW FORCE
HYDRAULIC
BLADE ANGLE KIT
For Straight Plows
OWNER'S MANUAL
MODEL NUMBER: 18-0050
CUSTOMER MUST RECEIVE A COPY OF THIS
OWNERS MANUAL AT TIME OF SALE
© 2009 Cycle Country Accessories Corp.
7/1/09
MAN0039
Advertisement
Table of Contents
Related Manuals for Cycle Country SNOW FORCE 18-0050
Summary of Contents for Cycle Country SNOW FORCE 18-0050
- Page 1 SERVICE: 800-841-2222 E-MAIL: ccac@cyclecountry.com www.cyclecountry.com SNOW FORCE HYDRAULIC BLADE ANGLE KIT For Straight Plows OWNER’S MANUAL MODEL NUMBER: 18-0050 CUSTOMER MUST RECEIVE A COPY OF THIS OWNERS MANUAL AT TIME OF SALE © 2009 Cycle Country Accessories Corp. 7/1/09 MAN0039...
- Page 2 Model Number 18-0050 Parts List ITEM NO. QTY. PART NO. DESCRIPTION 1 PUR2335 Electro Hydraulic Actuator 2 UTV0326 Cylinder Bracket Front 2 UTV0327 Cylinder Bracket Rear 1 PUR2323 3/8" x 1-1/2" Clevis Pin 2 PUR1152 3/8" x 3-1/4" Bolt 2 PUR1272 Locknut 3/8" Nylock 1 PUR2324 1/2"...
- Page 3 The Snow Force Hydraulic Blade Angle Kit for Straight Plows attaches to the Snow Force Pushtube Kit, 18-0030, and allows the UTV operator to change the angle of his plow without leaving the seat of his UTV. An electrically powered hydraulic cylinder attaches to the pushtube and provides the force needed to pivot the blade to the desired angle.
- Page 4 Assembly Remove the pivot head by first removing the locking pin from the bottom of the pivot head pin and pulling the pivot head pin out of the top of the pivot head. Remove the spring anchor by pulling up on it to unhook it from the pushtube.
- Page 5 Insert the two front cylinder mounting brackets (Item 2) into the slots on the pivot head as shown below. Reinstall the pivot head with the pivot head pin passing through the holes in the front cylinder mounting brackets (Item 2). Bolt on the two rear cylinder mounting brackets (Item 3).
- Page 6 Installation Use the supplied cable ties to attach the wiring harness to the UTV as shown below. Do not allow harness to come in contact with any moving parts or hot surfaces. Use the Scotch Lock Connector (Item 15) to connect the yellow wire to a wire on your UTV that is energized only when the Attach to Roll Bar...
- Page 7 ONE YEAR LIMITED WARRANTY For the period of one year from the purchase date Cycle Country Accessories Corporation will replace for the original purchaser, free of charge, any part or parts, when found, upon examination by Cycle Country Accessories Corporation, to be defective in material, workmanship, or both.
- Page 8 If a winch is what you must have, then you’ve come to the right place: 1500lb and 2500lb Winches We also have an extensive line of winch mounts for both Cycle Country and Warn winches If you need to haul more gear on your quad, check out our baskets:...
