- Page 1 INSTALLER: LEAVE THIS MANUAL WITH OWNER Scan QR code for French Manual. Scannez le code QR pour le manuel en français. PV2-42C & PV2-82C OPERATION & INSTALLATION INSTRUCTIONS...
- Page 2 This is a chemical free process which is simple in its concept and effective in its abilities to inactivate microorganisms which are resistant to chlorine. Simple maintenance, continuous disinfection and ultimately safe water, Pura Vida makes it that easy. PROUDLY MADE IN NORTH...
-
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY CONSIDERATIONS BEFORE YOU BEGIN WATER CHEMISTRY ASSEMBLY & PARTS LIST LOCATION INSTALLATION MAINTENANCE WINTERIZATION OPERATION CONTROLLER LAMP COUNTDOWN SEQUENCE LAMP REPLACEMENT SYSTEM TROUBLESHOOTING SYSTEM SPECIFICATIONS LIMITED WARRANTY STATEMENT WARRANTY REGISTRATION P a g e... -
Page 4: Safety Considerations
SAFETY CONSIDERATIONS Although your UV system has been manufactured to the highest safety standards, care must be followed when operating and/or maintaining your system. Read and follow these instructions. Ensure manual stays with owner for future reference. 1. Before servicing this equipment, disconnect the power cord from the electrical outlet. -
Page 5: Before You Begin
BEFORE YOU BEGIN The following will be needed for installing the UV system: Tools • Pipe cutter, hacksaw or other specialized tools required to cut/modify into your existing pool plumbing • Wrench (for tightening fittings) Other materials • PVC/PVC glue •... -
Page 6: Assembly & Parts List
GLAND NUT 320006 for mounting) PV2RCHO-4.12 O-RING 300038 Pressure Test Plug 390110 Optional Mounting Hardware UV LAMP 510008 (2 clamps) PV2RL-600HO (PV2-42C Series) PV2RL-950HO (PV2-82C series) *not included POWER CABLE SLEEVE SPRING 260004 310039 North American QUARTZ SLEEVE PV2RQ-600 OUTLET... -
Page 7: Location
RECOMMENDED PLACEMENT OUTLET PUMP FILTER HEATER SALT CELL OR CHLORINATOR INLET Figure 1. Diagram of flow FLOW RATES For detailed flow rates see page 11. leave at least an additional LOCATION chamber Place UV system in an area to ensure there is enough length to space at the lamp connector end to safely remove the facilitate... -
Page 8: Installation
INSTALLATION The chamber can be installed either horizontally or vertically. Vertical installation is the preferred method with the inlet at the bottom (lamp connection at the top) If installing horizontally additional mounting hardware is required (PN 510008). The use of a by-pass assembly is recommended as it will allow you to isolate the UV chamber. -
Page 9: Maintenance
(See page 8). PLEASE NOTE: A timer is recommended in conjunction with your pool pump to ensure the Pura Vida UV system Figure 7. Ground Screw is running at the same time as the pump. -
Page 10: Winterization
IT IS ESSENTIAL TO STORE ELECTRONICS/CONTROLLER INSIDE DURING WINTER MONTHS. *When ready to reconnect the Pura Vida in the spring, please refer to the original installation instructions above. **If proper winterization and installation instructions are not followed, the warranty will be rendered void. -
Page 11: Operation
OPERATION Pura Vida systems come with a feature laden controller that incorporates both the lamp driver (ballast) and control features in a fully sealed case to prevent water intrusion. Controllers feature a built in lamp monitor, with both audible and visual indication of lamp life, and auto sensing dual voltage for plug in or hard wired use. -
Page 12: Lamp Replacement
At any point during this sequence, the audible chirp or alarm can be deferred for seven days by holding the controller button down for a period of five seconds. The number of deferrals used will be displayed as below. Once the deferral expires, the alarm will sound once again. -
Page 13: System Specifications
SYSTEM SPECIFICATIONS Model PV2-42C PV2-82C 42 GPM 82 GPM Flow Rate 159 lpm 310.4 lpm 9.5 m 18.6 m Port Size 1.5” MNPT 2” MNPT Electrical 90-265V/50-60Hz. (IEC power cord included) Plug Type American, NEMA 5/15, 3 wire for all 110V systems... -
Page 14: Limited Warranty Statement
F.O.B. Select Pool Products’ closest Distribution Facility or applicable service depot. Pura Vida will not be liable for any costs of removal, installation, transportation, or any other charges which may arise in connection with a warranty claim. -
Page 15: Warranty Registration
For Warranty Service SELECT POOL PRODUCTS will not be liable for any incidental or consequential damages, losses, or expenses arising from installation, use, or any other causes. There are no express or implied warranties, including merchantability or fitness for a particular purpose, which extend beyond those warranties described or referred to above. - Page 16 1-855-881-0889 104A-3345 North Service Road, Burlington, ON L7N 3G2 www.selectpoolproducts.ca PN#:910432 EPA Establishment #088776-CAN-001 Version Date: 11-2021...
