- Page 1 INSTALLER: LEAVE THIS MANUAL WITH OWNER Scan QR Code for replacement parts PV2-42C & PV2-82C OPERATION & INSTALLATION INSTRUCTIONS...
- Page 2 This is a chemical free process which is simple in its concept and effective in its abilities to inactivate microorganisms which are resistant to chlorine. Simple maintenance, continuous disinfection and ultimately safe water, Pura Vida makes it that easy.
- Page 3 TABLE OF CONTENTS SAFETY CONSIDERATIONS BEFORE YOU BEGIN WATER CHEMISTRY ASSEMBLY & PARTS LIST LOCATION INSTALLATION MAINTENANCE WINTERIZATION OPERATION CONTROLLER LAMP COUNTDOWN SEQUENCE LAMP REPLACEMENT SYSTEM TROUBLESHOOTING SYSTEM SPECIFICATIONS LIMITED WARRANTY STATEMENT WARRANTY REGISTRATION P a g e...
- Page 4 SAFETY CONSIDERATIONS Although your UV system has been manufactured to the highest safety standards, care must be followed when operating and/or maintaining your system. Read and follow these instructions. Ensure manual stays with owner for future reference. 1. Before servicing this equipment, disconnect the power cord from the electrical outlet.
- Page 5 BEFORE YOU BEGIN The following will be needed for installing the UV system: Tools • Pipe cutter, hacksaw or other specialized tools required to cut/modify into your existing pool plumbing • Wrench (for tightening fittings) Other materials • PVC/PVC glue (to glue pool plumbing to union) •...
- Page 6 390110-C 310208-C P a g e...
- Page 7 RECOMMENDED PLACEMENT OUTLET PUMP FILTER HEATER SALT CELL OR CHLORINATOR INLET Figure 1. Diagram of flow FLOW RATES For detailed flow rates see page 11. leave at least an additional LOCATION chamber Place UV system in an area to ensure there is enough space at length to the lamp connector end to safely remove the UV lamp and/or facilitate...
- Page 8 INSTALLATION The chamber can be installed either horizontally or vertically. Vertical installation is the preferred method with the inlet at the bottom (lamp connection at the top) If installing horizontally additional mounting hardware is required (PN 510008). The use of a by-pass assembly is recommended as it will allow you to isolate the UV chamber.
- Page 9 PLEASE NOTE: A timer is recommended in conjunction UV Lamp Connection Figure 6. Lamp Connector with your pool pump to ensure the Pura Vida UV system is running at the same time as the pump. MAINTENANCE CLEANING THE QUARTZ SLEEVE/LAMP REPLACEMENT At a minimum, the quartz sleeve should be cleaned on an annual basis.
- Page 10 1”) WINTERIZATION Recommended operating temperature is between 2-40 degrees C (36- 104F). Please ensure the Pura Vida system and pump is turned off before winterizing. During the winterization process (or on an annual basis) it is important to inspect the zinc drain plug (see above).
- Page 11 TO MAINTAIN WARRANTY COVERAGE, IT IS REQUIRED TO STORE ELECTRONICS/ CONTROLLER INSIDE DURING WINTER MONTHS. *When ready to reconnect the Pura Vida in the spring, please refer to the original installation instructions above. **If proper winterization and installation instructions are not followed, the warranty will be rendered void.
- Page 12 LAMP COUNTDOWN SEQUENCE Starting at 420 days, the system counts down the number of days until a lamp change is required. Please note, the countdown timer will stop when unit is unplugged during winter or when PuraVida is not powered on. At thirty days remaining, the LED or display screen will change to a yellow caution indicator.
- Page 13 At any point during this sequence, the audible chirp or alarm can be deferred for seven days by holding the controller button down for a period of five seconds. The number of deferrals used will be displayed as below. Once the deferral expires, the alarm will sound once again.
- Page 14 SYSTEM SPECIFICATIONS Model PV2-42C PV2-82C 42 GPM 82 GPM 159 lpm 310.4 lpm Flow Rate 9.5 m 18.6 m Port Size 1.5” MNPT 2” MNPT Electrical 90-265V/50-60Hz. (IEC power cord included) Plug Type American, NEMA 5/15, 3 wire for all 110V systems...
- Page 15 (proper documentation required for verification). This Pura Vida Ultraviolet Water Sterilizer will be repaired or replaced, at our sole option, providing that the ultraviolet system or any component is defective in materials or workmanship for the periods outlined above and subject to the “Limitations of Warranty”...
- Page 16 For Warranty Service Select Pool Products will not be liable for any incidental or consequential damages, losses, or expenses arising from installation, use, or any other causes. There are no express or implied warranties, including merchantability or fitness for a particular purpose, which extend beyond those warranties described or referred to above.
- Page 17 3870 Bird Dog LN Deland FL. 32724-7425 1-866-649-5551...
