Service Documents
Confidential, for authorized service technicians only!
Do not disclose this information to or share these documents
L.U.C.A.S.
Note!
The components used in this product - particularly parts affecting
safety as well as speakers and transformers - were developed and
manufactured to certain specifications. Please use original spare
parts only to ensure the product remains fully functional and safe.
TECHNICAL SERVICE:
Stamer Musikanlagen GmbH • Magdeburger Str. 8 • 66606 St.Wendel • Germany
Music & Sales P.E. GmbH • Leipziger Str. 3 • 66606 St.Wendel • Germany
with third parties.
Vertraulich! Nur für autorisierte Servicetechniker!
Nicht zur Weitergabe an Dritte freigegeben!
MAX
SAT
Achtung!
Die in diesem Produkt verwendeten Komponenten, insbesondere
sicherheitsrelevante Teile, Lautsprecher und Transformatoren
wurden nach spezifischen Vorgaben entwickelt und gefertigt.
Bitte benutzen Sie ausschließlich Original-Ersatzteile – nur so ist
die volle Funktionalität und Sicherheit gewährleistet.
2006/07/06

Advertisement

loading
Need help?

Need help?

Do you have a question about the L.U.C.A.S. MAX SAT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HK Audio L.U.C.A.S. MAX SAT

Summary of Contents for HK Audio L.U.C.A.S. MAX SAT

  • Page 1 2006/07/06 Service Documents Confidential, for authorized service technicians only! Do not disclose this information to or share these documents with third parties. Vertraulich! Nur für autorisierte Servicetechniker! Nicht zur Weitergabe an Dritte freigegeben! L.U.C.A.S. Note! Achtung! The components used in this product - particularly parts affecting Die in diesem Produkt verwendeten Komponenten, insbesondere safety as well as speakers and transformers - were developed and sicherheitsrelevante Teile, Lautsprecher und Transformatoren...
  • Page 2 Directory features page: drawing-numbers-example page: standard for single wire confection page: HK1105-LUCAS MAX Satellite page: exploded drawings: complete Rev.: A page: 12-13 front grille Rev.: A page: connector panel subassy./ cabling Rev.: A page: 15-18 crossover assembly Rev.: A page: spare parts list Rev.: A page:...
  • Page 3 Satellites Satellites are loaded with a 10" HK Audio Custom speaker and a 1" compression driver with a 60° x 40° CD horn. They are rated for 400 W RMS power- handling capacity and a nominal impedance of 8 ohms.
  • Page 4 L.U.C.A.S MAX - user panel 3 Connections and Control Features 3 Balance 6 Subwoofer Level L.U.C.A.S MAX Subwoofer Operation: Twist the Balance knob to the left or right Handling: When this knob is set to the 12 o’clock to adjust the relative balance of levels between the position, the subwoofer’s and the satellite’s respec- 1 Limiter LEDs left and right channels.
  • Page 5 L.U.C.A.S MAX Manual 1.0 8 Input Left and Input Right (Combination XLR/1/4" 12 Mains Input jacks) Connections: Use the factory-included Powercon ® L.U.C.A.S MAX ® is equipped with separate left and mains cable (power cord) to connect from this right channel inputs for connecting to a mixer. socket to a wall receptacle.
  • Page 6 Otherwise, electronic components To learn more about Original HK AUDIO may overheat and suffer damage. Accessories, talk to your HK AUDIO dealer or visit www.hkaudio.com. • L.U.C.A.S MAX ®...

  • Page 7: Troubleshooting

    * Stamer Musikanlagen manufactures exclusively ® 2 If the LED displays on your mixer are in the green, for HK AUDIO ® turn back L.U.C.A.S MAX ’s Gain knob. 3 Watch the LEDs of the Limit Left, Limit Right and Limit Subwoofer displays on L.U.C.A.S MAX...

  • Page 8: Technical Service

    2.2 kHz, 12 dB / octave Class D power amp Driver protection: Dynamic protective circuit Protective circuits: DDO™ controlled multi-band limiter Pole mount: HK Audio DuoTilt™ 36 mm, -7.5° und –15° Speakers: Weights and measures: Woofer: 1x 15" Neodymium Weight: 11 kg / 24.3 lbs.
  • Page 9 KU = PLASTIC / KUNSTSTOFF LP = PCB / LEITERPLATTEN SO = MISCELLANEOUS / SONSTIGES SP = SCHEMATIC / SCHALTPLÄNE TR = TRANSFORMER / TRANSFORMATOR GK = WIRING DIAGRAM / GERÄTEVERKABELUNG PROJECT-NR.: HK = HK AUDIO HU = HUGHES&KETTNER MP = MINDPRINT...

  • Page 10: Cross Section

    Stand 17. Jun 04 Standard for single wire confection. 485 W 1015 style 1015 according UL specifications I = completely insulated with black shrinktube or appropriate sleeve IT = partly insulated; only crimp connection insulated. no marking = without insulation Z = with additional junction no marking = without additional junction W = angled faston...

  • Page 11: Service Documents

    Service Documents HK1105 L.U.C.A.S. SATELLITE Confidential, for authorized service technicians only! Do not disclose this information to or share these documents with third parties. TECHNICAL SERVICE: Stamer Musikanlagen GmbH • Magdeburger Str. 8 • 66606 St.Wendel • Germany Music & Sales P.E. GmbH • Leipziger Str. 3 • 66606 St.Wendel • Germany...
  • Page 12 E 400274 HK1105-HZ-R02-1E E 994108 voice coil as spare part: E994112-B&C MD/DE12-8/M MEMBRANA E 994216 E 974020 9 E 974216 3 E 520122 E 974108 E 974068 E 974258 E 1140 E 976001 E 972008 HK1105-EX-R01-1A HK1105-SO-R04-1A 14 E 976113 5 E 974017 E 994188 E 974419...
  • Page 13 Pos. Artikel-Nr. 1 description Titel Menge 1140 LUCAS MAX satellite front grille assembly LUCAS MAX Top Frontgitterbaugruppe 400274 cabinet Lucas Max satellite Holzgeh. Lucas Max Top 520122 52 crossover assembly MAX Satellite 52 Freqw. Lucas Max Top 972008 damping wool Dämmwolle Hochbauschvlies 974017 hexagon socket countersunk head screw, M6x25, black...
  • Page 14 Pos. Artikel-Nr. 1 description Titel Menge 970335 front grille Streckgitter-Tafel 1000x2000mm 972085 acoustic foam anthracite; 15mm Akustikschaum Anthrazit 15mm 974158 snapon retaining ring (for logo) Schnellbefestiger f. Logo 980124 logo ´HK´35*35 Logo ´HK´35*35 1 E 970335 E 972085 HK1105-SO-R02-1B HK1105-SO-R05-1A 3 E 974158 service-nr.: E 1140 TITEL:...
  • Page 15 Pos. Artikel-Nr. 1 description Titel Menge 520122 52 crossover circuit PCB, MAX Satellite 52 Freqw. Lucas Max Top 952022 speakon chassis connector, NL4MP Speakonbuchse 4pol eckig 970797 Lucas Impact Top Connection Panel Blech Anschl.pl.Lucas Impact Top 974110 self locking hexagon nut with plastic insert, M3, zinc plated Stopmutter M3 vz 974228 cross recessed raised countersunk screw, M3x10, black...
  • Page 16 TITEL: HK1105-SATELLITE CROSSOVER EXPLOSION DRAWING 66606 St. Wendel / Germany ZEICHNUNGS-NR.: VERSION: REVISION: HK1105-EX-R06-1A BLATT: ERSTELLT VON: C. LORIS 03.05.2006 ZEICHNER INDEX ÄNDERUNG GEPRÜFT/ BLÄTTER FREIGEGEBEN VON: WERKSTOFF: OBERFLÄCHE: DATEINAME: HK1105-EX-R06-1A-TOP-CROSSOVER...
  • Page 17 962074-Litze FQL24 red 450mm Q1.5 R 450 638-ABISO 962073-Litze FQL24 black 450mm Q1.5 B 450 638-ABISO 962006-Litze FQL3 black 100mm Q1.5 B 100 485I-ABISO 962005-Litze FQL3 red 100mm Q1.5 R 100 485I-ABISO 962060-Litze FQL16 black 550mm Q1.5 B 550 638-ABISO TITEL: HK1105-SATELLITE CROSSOVER EXPLOSION DRAWING...
  • Page 18 Pos. Artikel-Nr. 1 Artikel-Nr. 2 Artikel-Nr. 3 description Titel Menge 962005 stranded wire Q1. 5 -R-100-485I-ABISO Litze Q1. 5 -R-100-485I-ABISO 962006 stranded wire Q1. 5 -B-100-485I-ABISO Litze Q1. 5 -B-100-485I-ABISO 962059 stranded wire Q1. 5 -R-550-638-ABISO Litze Q1. 5 -R-550-638-ABISO 962060 stranded wire Q1.
  • Page 19 Pos. Artikel-Nr. 1 description Titel Menge 974097 blind rivet alu/steel standard, 5.0x6.0 Blindniete Alu-FLARUKO 5,0*6,0 974098 hexagon nut, class 8, M5, brass Sechskantmutter M4 ms 974103 toothed lock washer, D=4.3, AZ, zinc plated Fächer-Scheibe az, 4,3 vz 974107 plastic PCB spacer, 4.2x8x10, Polyamid black Dist.Hülse PE 4,2*8*10 [mm] 974121 slotted cheese head screw, M4x35, brass...
  • Page 20 HK1105-EX-R02-1A-SAT-COMPLETE Article No. 1 (230V) Article No. 2 (117V) Article No. 3 (100V) Description Bezeichnung Quantity E1140 LUCAS MAX satellite front grille assembly LUCAS MAX Top Frontgitterbaugruppe 400274 cabinet Lucas Max satellite Holzgeh. Lucas Max Top 520122 52 crossover assembly MAX Satellite 52 Freqw.
  • Page 21 974103 toothed lock washer, D=4.3, AZ, zinc plated Fächer-Scheibe az, 4,3 vz 974107 plastic PCB spacer, 4.2x8x10, Polyamid black Dist.Hülse PE 4,2*8*10 [mm] 974121 slotted cheese head screw, M4x35, brass Zylinderschraube M4*35 ms 974154 blind rivet steel standard, 3.0x8, black Blindniete Stahl schw.
  • Page 22 27/10WS 18R/20W_AX – SP1.5Q MKP-1.8u/250V B&C HIGH OUT MKP-3.3u/250V INPUT 24V/18W_15/41 DE 12 0.82mH/1.00mm_LU – SP1.5Q 1.50mH/0.80mm_LI SICA MID/LOW OUT MKP-12u/250V LP 266.50/N200 WT4 – NDK-R40-B12 NDK-R40-B12 NA = not assembled part ----- EX = exclusive part, no alternative allowed Title: HK1105 - L.U.C.A.S.
  • Page 23 ! " ( ) ' ( # $% & !" #$%&'( ' ()" " + -* " . * # '/() * #0...
