SF-2400 Quick User Manual
V2.0
Beijing Starfire Control Technology Co.,Ltd
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SF-2400 and is the answer not in the manual?

Questions and answers

Related Manuals for Starfire SF-2400

Summary of Contents for Starfire SF-2400

  • Page 1 BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 STARFIRE SF-2400 Quick User Manual V2.0 Beijing Starfire Control Technology Co.,Ltd...

  • Page 2: Table Of Contents

    BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 catalogue The first chapter system operation panel ........................04 The second chapter main interface ..........................05 2.1 Main screen button description.......................... 06 2.2 Manual function description ..........................06 2.3 The menu structure ............................07 The third chapter cutting process ..........................
  • Page 3 7.7 Panasonic servo connection ..........................38 The eighth chapter Nc and height controller connection method ................39 8.1 Connect sf-2400 nc with sf-hc25k height controller ................... 40 8.2 Connect sf-2400 nc with sf-hc25C3 height controller ..................41 8.3 Connect sf-2400 nc with sf-hc30A height controller ..................42...
  • Page 4 BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 Chapter 1 system operation panel 【F1】-【F8】: Function keys, under different interface, with the corresponding prompt functions; 【F+/PgUP】：to speed up the speed /Under the code interface is up page key, 【F-/PgDn】：to slow down speed /Under the code interface is down page button；...
  • Page 5 BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 Move the Torch or move the cursor up, down, left, and right； The enter key to confirm the input value or select the project； Escape key to exit the current interface or deselect;；...

  • Page 6: Main Screen Button Description

    BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 Chapter 2 main interface description 2.1 main screen button description After starting up the system, as shown in the figure below: Under the main interface, the key functions are as follows： 【F1】 Gallery: enter the graphics library, most of which are available in sheet size and hole size. You can also enter the nesting screen.

  • Page 7: Manual Function Description

    BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 【F】Cutting speed: set the automatic cutting speed. 【T】Preheating time: set the preheating delay. 【N】Slot: the slot size can be set before the cutting operation starts. 【0】Continuous walk: after the function is turned on, press the direction button when manually moving the gun, the cutting gun will keep walking, and then press the direction button or pause button again to stop.
  • Page 8 BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 starting point. If press [ENTER], the system will return to the starting point of the correction. If press [ESC], the system has no operation and returns to the graphical interface. [F2] tapping: after pressing this key to input the tapping increment, press the direction key once to cut the gun to a certain length, and then press it again to cancel the tapping.

  • Page 9: Automatic Cutting Process Diagram

    BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 Chapter 3 cutting process Automatic cutting process diagram 3.1 select machining graphics The system can choose file from the system library to choose processing graphics and from the U disk or storage area into the user processing graphics 3.1.1 gallery function...
  • Page 10 BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 Selection of graphic parts: At present, the system provides 50 graphics units, press the direction key 【 ↑】 【 ↓】 【 ←】 【 →】 to move the highlighted cursor, select the required graphics, press the [Enter] key or [F6] to confirm, and Enter the graphic parameters interface after confirmation.
  • Page 11 BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 Press the direction key【↑】【↓】【←】【→】to move the highlighted cursor and modify the graphic parameters. [F1] artifact: switch to artifact mode. [F2] hole shape: switch to opening mode, some parts do not have opening mode.
  • Page 12 BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 Local file operation: [F1] native file: displays the native file. [F2] usb flash drive: displays usb flash drive files. [F3] edit file: edit the native file at the current cursor. [F4] delete file: delete the file at the current cursor.
  • Page 13 BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 [F1] native file: displays the native file. [F2] usb flash drive: displays usb flash drive files. [F3] edit file: edit the file at the current cursor. [F4] delete file: delete the file at the current cursor.
  • Page 14 BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 In the edit code: [F1]insert a line above the current edit line; [F2] delete the current edit line; [F3] create a new file; [F6] preview graphics; [F7] save documents; 3.1.3 part selection function...

  • Page 15: Parameters To Be Set Before Processing

    BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 [F1] select starting point: press this key continuously to select the starting point of cutting gun positioning, and the sequence is the bottom left corner the upper left corner the upper right corner the lower right corner the center point.

  • Page 16: Start Processing

    BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 Cutting mode [G] : press the keyboard key to switch the cutting mode between flame, plasma and demonstration. Cutting speed [F] : press the keyboard key , change the value to change the cutting speed, and press enter to confirm.
  • Page 17 BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 After selecting the machined parts and setting machining parameters, press the down button on the main interface. The system interface is as follows: At this point, press the [Enter] key to start automatic processing. Press the [ESC] key to exit the system and return to...
  • Page 18 BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 Chapter 4 processing This chapter describes the processing process needs to be carried out in the introduction 4.1 pause operation During the processing, if there is a break of fire, arc, or other situations that need to be suspended, press the button and the system will stop working.
  • Page 19 BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 Note: press [F7] to end the preheating delay. At this time, only the current delay will be ended and will not be recorded into the system. If the current time needs to be remembered as the system preheating delay, press the end delay (remember at the same time) to start the perforation processing.

  • Page 20: The Original Track Back Processing

    BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 2) cutting return First perforation, and then along the cutting speed along the line from the current position to adjust the starting point, do not stop according to the original trajectory to continue processing, a bit like epitaxial perforation, so that the perforation point more smooth;...

  • Page 21: Breakpoints Recovery

    BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 Press [F2] key to advance the original track on the basis of backtracking. During the fallback process, if the desired position is not reached, press the [pause] button again and repeat the above process until appropriate.
  • Page 22 BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 Select breakpoint recovery and press the [start] key to start the breakpoint recovery. 2) enter manual mode. As long as there is no change in the current program, press [F6] to find the breakpoint function, return to the main interface and then press [start] to resume the breakpoint.
  • Page 23 BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 2) the method of edge perforation is: move the cutter gun to the nearest edge of the steel plate before perforation. 3) start preheating. When the preheating is finished, press the [start] button to cut the cutter along the straight line and at the selected cutting speed to the perforation point, and then continue cutting.
  • Page 24 BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 Without a punch, the system runs directly from the current punch position. Blank line to the next punch point, a new punch prompt appears. Chapter 5 nesting function In the main screen, press [F1] key to enter the gallery, and then press [F1] key to enter the nesting screen, as shown in the figure below: 5.1 menu functions...

  • Page 25: Steel Plate Teach

    BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 [Enter] : switch part window and file list window; 5.2 steel plate teaching Press [F5] under the nesting screen and select "size of teaching steel plate". After confirmation, enter the teaching steel plate screen as shown below: Teaching steps: Move the cutter to the starting position and press the [starting point] key;...

  • Page 26: Speed Parameter

    BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 Chapter 6 parameter setting Press [F4] in the main screen to enter the parameter screen, as shown in the figure below: Menu description: [speed] : set speed related parameters. [system] : set coordinate system, electronic gear and other related parameters.

  • Page 27: System Parameters

    BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 [uniform acceleration time] : motor speed regulation auxiliary parameters, the greater the inertia of the machine tool, the smaller the setting value, the recommended value is 0.2. [blank speed] : the blank speed of cutting gun, namely the maximum blank speed that the machine tool can bear. The recommended value is 4000.

  • Page 28: Flame Parameters

    BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 [reset direction] : the direction of the machine tool back to the origin, 0 is no longer the position, -1 is to the negative direction reset, 1 is to the positive direction reset.

  • Page 29: Control Parameters

    BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 [initial positioning detection selection] : if numerical control is required for initial positioning, this value is set to 1 and the default value is 0. [cutting gun positioning delay] : when the numerical control does the initial positioning, the rising time of the cutting gun, the default value is 0.5.
  • Page 30 BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 large programs, the picture will take a long time. [calculation control precision] : automatically optimize the program line to ensure smooth cutting, and the recommended value is 0.01. [remote control selection ] : 0 -- do not test the remote control; 1 -- select the wired remote control; 2 -- select the wireless remote control.

  • Page 31: Wiring Instructions

    BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 Chapter 7 definition of wiring 7.1 wiring instructions Above is the system input screen. In the figure above, [serial number] is the pin number on the plug, and [normally open and normally closed] is the default state of the signal. The input pin is green when there is a signal and gray when there is no signal.

  • Page 32: Output Principle

    BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 Positive X-limit External control X+ Negative X-limit External control X- Positive Y-limit External control Y+ Negative X-limit External control Y- Plasma arc measurement External control start Stop Torch up Pause/drive alarm Torch down...
  • Page 33 BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 Torch down Automatic plasma height controller Flame ignition Start drilling Plasma arc start Drilling down medium pressure Cutting oxygen High pressure preheating oxygen 12,24 13, 25 24V- 7.2 interface definition and modification of normally open and normally closed...

  • Page 34: Modify Motor Direction

    BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 Under the diagnosis interface, press the "port definition" key, enter the password 1928 and enter the port definition interface. The above is IO definition interface, press 【→】 【←】 【↑】 【↓】 key to move the cursor, press [PgUp] [PgDn] key to change the serial number and the normally open and normally closed state, or press [Enter] key to select, after setting, press [save] key.
  • Page 35 BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 In the figure above, press 【↑】 【↓】 to move the cursor, press [1] [0] to change the direction, and press [save] after setting.
  • Page 36 BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 In the figure above, press【↑】【↓】to move the cursor, press [Enter] to modify the direction definition, and press [save] after setting. 7.4 definition of motor wiring motor 1 Pin number definition X1 direction +...

  • Page 37: Differential Drive Connection

    BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 motor 2 Pin number definition X2 direction + X2 direction - X2 pulse + X2 pulse - Y2 direction + Y2 direction - Y2 pulse + Y2 pulse - 5V power + 7.5 differential driver connection...

  • Page 38: Total Positive Drive Connection

    BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 7.6 total positive drive connection power XDIR+ XDIR- XCP+ XCP- YDIR+ YDIR- YCP+ YCP- stepmotor Driver power stepmotor Driver...

  • Page 39: Panasonic Servo Connection

    BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 7.7 panasonic servo connection Power XDIR+ 5 SING1 XDIR- 6 SING2 XCP+ 3 PULS1 XCP- 4 PULS2 YDIR+ YDIR- YCP+ YCP- Motor A4/A5 Power 5 SING1 6 SING2 3 PULS1 4 PULS2...
  • Page 40 BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 Chapter 8 wiring definition of nc and height controller 8.1 connection of CNC SF-2400QG with sf-hc25g height controller Successful arcing signal 24V+ 24V- 24V+ 24V- Nc system input 0 - OK DOWN...
  • Page 41 BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 8.2 connection of CNC sf-2400qg with sf-hc25c3 height controller Successful arcing signal AUTO DOWN Nc system input ARC-OK Cutting torch up Cutting torch down OUTPUT2 Arc start 24V+ Automatic height control 24V-...
  • Page 42 BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 8.3 Connection of CNC SF-2400QG with sf-hc30a height controller Cutting torch up Cutting torch down Arc start 24V+ Automatic height control 24V+ 24V- 24V- Nc system output Height controller terminal DB15 24V-...
  • Page 43 BeiJing Starfire Control Technology Co.,Ltd WeChat:18901200180 QQ: 1908817881 Chapter 9 software upgrade instructions Function: System can be through the U disk, program upgrade. The specific operations are as follows: 1. Upgrade files Copy the upgrade file SF104 to the usb drive.
  • Page 44 When excluding the upgrade file and U disk these two factors, you can follow the specific steps to upgrade again; If you still fail to upgrade after many attempts, please call customer service department of Beijing starfire control technology co., LTD Telephone :010-88797100 Mobile phone: 18901200175...
