Page 1: Table Of Contents
catalogue SF - 2100 - c fast operation manual ................. 3 The first chapter system operation panel ..............3 The second chapter main interface ................5 The third chapter cutting process ................6 Automatic cutting process diagram ................6 The first section selection processing graphics ............6 3.1.1 gallery features .................... - Page 2 6.2 Parameter explanation ..................21 6.3 Wiring definition ....................22 6.4 Fault description ....................23 6.5 Arc pressure setting ..................... 23 Appendix 1: software upgrade instructions ............. 24...
-
Page 3: Sf -2100 - C Fast Operation Manual
SF -2100 - c fast operation manual SF - 2100 - c flame/plasma CNC system fast operation manual: The first chapter system operation panel 【 F1】 -【 F8】 : Function keys, under different interface, with the corresponding prompt functions 【 S↑/PgUP】：... - Page 4 Function switch, press the button to open the corresponding function The blank space key, input composite keys for the shift key, according to an effective time, press a button to enter automatic processing interface under the main interface...
-
Page 5: The Second Chapter Main Interface
The second chapter main interface After the system is powered on, interface is shown in figure 1: figure Under the main interface, press "F1" - "F8" corresponding to the following functions： [F1]： Gallery, enter can choose commonly used 24 kinds of graphics libraries, most have die size and pore size. -
Page 6: The Third Chapter Cutting Process
The third chapter cutting process Automatic cutting process diagram... -
Page 7: The First Section Selection Processing Graphics
The first section selection processing graphics This system can select from gallery selection system processing graphics and users from the U disk or storage area to the graphics processing 3.1.1 Library function System main interface press "F1" button to enter gallery features, main picture below Selection of graphical parts 【↑】【↓】【←】【→】mobile highlight cursor, At present this system provides 24 graphic unit, press the direction key... -
Page 8: Processing File Selection
Press the direction key【↑】【↓】【←】【→】Move highlighting the cursor, modify graphics parameters，Press【F1】-【F4】 。 【F6】 ，Press【F7】 Choose graphically，Rotation discharge Press Submit the modified parameters Confirm the cutting current ， 。 graphics Confirmed the system automatically returns to the switch on the main interface, and displays the graphics editor 3.1.2 Processing file selection 【F2】，... - Page 9 USB file documents show U disk directory EDIT Edit the current cursor file DEL-FILE Delete the current cursor file COPY TO USB The current cursor file is copied to the external usb drive NEW FOLDER Can create a folder under the root directory 。...
-
Page 10: Parts Option Function
【 F3】Edit the file。 Under the file interface, move the cursor to the need to edit the file name, press 【 Shift】 Input characters, some of the key is to reuse a key, , reuse is the character that the downside of keys, click on the first Press the reuse button again, the input is to reuse the upside of keys。... -
Page 11: The Second Section Setting Processing Parameters
【 F2】： Rotation correction, can use plate leveling function and manual rotation function ： 【 F1】 ROTATE entering rotation correction interface, mobile cutting torch to plate production start position, press the starting point, the system coordinates automatically reset, and then move the cutting torch to the side to the other corner of 【... - Page 12 press the key ， ， Preheat time delay Modify the numerical change preheat time delay Press enter to confirm 3.2.2 Under the main interface press Enter the processing interface 【 F1】： BACKWARD ， 。 Cutting nozzle along the trajectory of the original cut back（The I / O port is now closed） 【...
- Page 13 ，press ， At this point, press the Start automatic processing Exit the processing Back to the main interface During processing, can press Adjust the processing speed.Click 1% deceleration, long press 10% deceleration。...
-
Page 14: The Fourth Chapter Machining Process
The fourth chapter machining process In the process of the content of this chapter is to introduce the processing needs of processing Suspend operations ， During processing, flame failure, interruption of arc voltage, or other need to suspend the case, press System to ：... -
Page 15: After Suspend Mobile Perforation Position Or Cutting Position
Press ， ， 。 Choose to change the speed modify The values press to confirm 。 After the completion of the modified,press To continue processing Change perforation position or cutting position after the pause Mobile cutting after the pause, press start again , appear the following interface ，... -
Page 16: Breakpoints Recovery And Restore Power
Pause, slow down the running system, the system shows "pause" tag, and presented the following figure. Press 【F1】 System to perform the original track back, back speed set in the parameter - speed - back. Press 【F2】 In the back, on the basis of the original trajectory.In the process of back, if do not meet the need of position, can press 【... -
Page 17: Parts Of Functions
， Choose breakpoints recovery Press "start" button, the system breakpoint began to recover。 2）Entered manually, as long as the current process does not change, can press[ F6 ] find breakpoint function, back to the main interface and then press "start" button, system breakpoint began to recover. Both breakpoints recovery and restore power, are not allowed to change, the Angle of rotation, scaling, the conditions of the system will automatically save, not affected by the switch machine).Otherwise the system may find the breakpoint. -
Page 18: The Edge Of The Thick Plate Perforation
4.6、 The edge of the thick plate perforation 。 In the automatic processing, need to use edge perforation method for thick plate processing edge of the perforation of the method is: will be in front of the punch cutting torch to move to the edge of the plate recently. -
Page 19: The Fifth Chapter Interface Definition
The fifth chapter interface definitions interface definitions Pin number definition Pin number definition X direction + X direction - X pulse + X pulse - Y direction + Y direction - Y pulse + Y pulse -... -
Page 20: The Sixth Chapter Description Of Built-In Height Control Function
The Sixth chapter Built-in height control function description 6.1 System composition The whole set is composed of the numerical control system sf-2100c, communication line, sf-hc25j2 and split-pressure plate, as shown in the figure below: The communication line needs to be welded by the user according to the length. - Page 21 6.2 Parameter description After starting the machine, press [F4] → [F6] to enter the screen of setting up parameters. The parameters are as follows: Built in height adjustment (open 1 / close 0): set the built-in height adjustment to 1, not used to 0, and the default value is 0;...
- Page 22 6.3 Wiring definition...
- Page 23 6.4 Fault diagnosis If the communication line is connected wrong or not connected, enter the automatic screen, and the system will prompt as follows: At this point, should solve the communication line problem, in order to use the normal high. 6.5 Automatic cutting, adjust the height.
- Page 24 Appendix 1 software upgrade instructions Function: System can be through the U disk, program upgrade. The specific operations are as follows: 1. Upgrade files Copy the upgrade file STARTCNC.EXE to the usb drive. 2. Operation steps After inserting the usb stick, press the pause button on the front panel of the system with your finger.
