Instruction
manual
MODELS 4630 and 4634
Depth Sensing Drywall and Deck Drivers
MODEL 4640
Depth Sensing Fastener Driver
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
Copyright © 2003 Porter-Cable Corporation
ESPAÑOL: PÁGINA 13
FRANÇAISE : PAGE 27
Double Insulated
Portable Electric
Screwdrivers
IMPORTANT
Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No. ______________________________________
Type ___________________________________________
Serial No. _______________________________________
Part No. 896132 - 06-03-03
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Porter-Cable 4630
Summary of Contents for Porter-Cable 4630
- Page 1 FRANÇAISE : PAGE 27 Instruction manual Double Insulated Portable Electric Screwdrivers MODELS 4630 and 4634 Depth Sensing Drywall and Deck Drivers MODEL 4640 Depth Sensing Fastener Driver IMPORTANT Please make certain that the person who is To learn more about Porter-Cable...
-
Page 2: Safety Guidelines - Definitions
SAFETY GUIDELINES - DEFINITIONS This manual contains information that is important for you to know and under- stand. This information relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you recognize this information, we use the symbols below. Please read the manual and pay attention to these sections. indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. -
Page 3: Personal Safety
Avoid body contact with grounded surfaces such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is grounded. Don’t expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock. Do not abuse the cord. -
Page 4: Additional Specific Safety Rules
There are certain applications for which this tool was designed. Porter-Cable strongly recommends that this tool NOT be modified and/or used for any application other than for which it was designed. If you have any questions relative to its application DO NOT use the tool until you have written Porter- Cable and we have advised you. -
Page 5: Replacement Parts
When servicing, use only identical replacement parts. MOTOR Many Porter-Cable tools will operate on either D.C., or single phase 25 to 60 cycle A.C. current and voltage within plus or minus 5 percent of that shown on the specification plate on the tool. Several models, however, are designed for A.C. -
Page 6: Extension Cord Selection
14-16 16-18 18-20 OPERATING INSTRUCTIONS FOREWORD Porter-Cable screwdrivers are designed to install or remove various sizes and types of fasteners. TO START AND STOP TOOL Make sure that the switch is off before connecting the tool to the power source. - Page 7 A lock button (B) Fig. 1 is provided to keep the motor running without holding the trigger switch “ON”. TO LOCK the trigger switch “ON”, squeeze the trigger as far as it will go, push in lock button and release trigger. TO UNLOCK the lock button, squeeze the trigger and release, leaving the lock button free to spring out.
- Page 8 Replace Depth Stop Assembly and adjust the depth stop (see “ADJUST DEPTH STOP, MODELS 4630 AND 4634”) Fig. 4 ADJUST DEPTH STOP – MODELS 4630 AND 4634 Turn the adjusting collar until the end of the bit extends 3/32" beyond the end of the depth stop.
- Page 9 DRIVING DRYWALL SCREWS – MODELS 4630, 4634 NOTE: Maximum size screw for use with this tool is #12 Wood Screw. Install a drywall bit and bit holder in the screwdriver. Set the screwdriver for the correct rotation. Start the screwdriver and place a drywall screw on the bit.
-
Page 10: Maintenance
AUTHORIZED PORTER-CABLE SERVICE STATION for service. Proceed if the jaws are not seriously worn and there are no other apparent faults in the mechanism. -
Page 11: Failure To Start
SERVICE CENTER. At approximately 100 hours of use, take or send your tool to your nearest authorized Porter-Cable Service Station to be thoroughly cleaned and inspected. Have worn parts replaced and lubricate with fresh lubricant. Have new brushes installed, and test the tool for performance. - Page 12 PORTER-CABLE LIMITED ONE YEAR WARRANTY Porter-Cable warrants its Professional Power Tools for a period of one year from the date of original purchase. We will repair or replace at our option, any part or parts of the product and accessories covered under this warranty which, after examination, proves to be defective in workmanship or material during the warranty period.
- Page 13 (Desarmadores) Portátiles Instrucciones Eléctricos con Aislamiento Doble Desatornilladores para Paredes en Seco con Tope de Profundidad MODELOS 4630 y 4634 Desatornilladores para Sujetadores con Tope de Profundidad MODELO 4640 IMPORTANTE Asegúrese de que la persona que va a usar Para obtener más información...
-
Page 14: Pautas De Seguridad/Definiciones
PAUTAS DE SEGURIDAD/DEFINICIONES Indica una situación de inminente riesgo, la cual, si no es evitada, causará la muerte o lesiones serias. Indica una situación potencialmente riesgosa, que si no es evitada, podría resultar en la muerte o lesiones serias. Indica una situación potencialmente peligrosa, la cual, si no es evitada, podría resultar en lesiones menores o mode- radas.
