911216- 12-03-03.qxd
12/3/03
Instruction
manual
MODEL 4610
Depth-Sensing Drywall Driver
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
Copyright © 2003 Porter-Cable Corporation
8:40 AM
Page 1
ESPAÑOL: PÁGINA 11
FRANÇAISE : PAGE 23
Double-Insulated
Portable Electric
Screwdriver
IMPORTANT
Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No. ______________________________________
Type ___________________________________________
Serial No. _______________________________________
Part No. 911216 - 12-03-03
Advertisement
Table of Contents
Related Manuals for Porter-Cable 4610
Summary of Contents for Porter-Cable 4610
- Page 1 911216- 12-03-03.qxd 12/3/03 8:40 AM Instruction manual MODEL 4610 Depth-Sensing Drywall Driver To learn more about Porter-Cable visit our website at: http://www.porter-cable.com Copyright © 2003 Porter-Cable Corporation Page 1 ESPAÑOL: PÁGINA 11 FRANÇAISE : PAGE 23 Double-Insulated Portable Electric Screwdriver...
-
Page 2: Safety Guidelines - Definitions
911216- 12-03-03.qxd 12/3/03 8:40 AM SAFETY GUIDELINES - DEFINITIONS This manual contains information that is important for you to know and under- stand. This information relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you recognize this information, we use the symbols below. -
Page 3: Personal Safety
911216- 12-03-03.qxd 12/3/03 8:40 AM Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock. Do not abuse the cord. Never use the cord to carry the tools or pull the plug from an outlet. - Page 4 There are certain applications for which this tool was designed. Porter-Cable strongly recommends that this tool NOT be modified and/or used for any application other than for which it was designed. If you have any questions relative to its application DO NOT use the tool until you have written Porter-Cable and we have advised you.
-
Page 5: Replacement Parts
When servicing use only identical replacement parts. MOTOR Many Porter-Cable tools will operate on either D.C., or single phase 25 to 60 cycle A.C. current and voltage within plus or minus 5 percent of that shown on the specification plate on the tool. Several models, however, are designed for A.C. -
Page 6: Functional Description
911216- 12-03-03.qxd 12/3/03 8:40 AM FUNCTIONAL DESCRIPTION Porter-Cable screwdrivers are designed to install or remove various sizes and types of fasteners. TO START AND STOP TOOL Confirm that the trigger switch is “OFF” before connecting the tool to the power source. - Page 7 911216- 12-03-03.qxd 12/3/03 8:40 AM TO CHANGE BIT HOLDER Pull the Depth Stop Assembly (A) Fig. 2 from the clutch housing. Pull the bit holder (C) Fig. 2 out. If it is difficult to remove, grip it with pliers and pull. NOTE: Bit (D) Fig.
-
Page 8: Maintenance
Proceed if the jaws are not seriously worn and there are no other apparent faults in the mechanism. Clean the mechanism and all internal areas of chips or other foreign material and brush a thin coat of PORTER-CABLE gear lubricant on the clutch elements and surrounding areas. Attach the screwdriver mechanism to the power unit. -
Page 9: Failure To Start
FACTORY SERVICE CENTER. At approximately 100 hours of use, take or send your tool to your nearest authorized Porter-Cable Service Station to be thoroughly cleaned and inspected. Have worn parts replaced and lubricate with fresh lubricant. Have new brushes installed, and test the tool for performance. - Page 10 PORTER-CABLE LIMITED ONE YEAR WARRANTY Porter-Cable warrants its Professional Power Tools for a period of one year from the date of original purchase. We will repair or replace at our option, any part or parts of the product and accessories covered under this warranty which, after examination, proves to be defective in workmanship or material during the warranty period.
- Page 11 Porter-Cable • Delta products should be obtained by contacting any Porter-Cable • Delta Distributor, Authorized Service Center, or Porter-Cable • Delta Factory Service Center. If you do not have access to any of these, call 888-848-5175 and you will be directed to the nearest Porter-Cable •...
