HIGHONE DAV 7 C W566C Instructions For Use Manual page 4

A
Preview of the appliance
Description of the appliance
Top platform
1
Control panel
2
Door
3
Lint filter
4
Front panel
5
Control panel
On/Off
1
Start/Pause
2
Programme (Blend/Cotton/Synthetic/1 Hour)
3
4
Drying level (Extra/Standard/Low)
Anti-crease
5
NOTE
• Press the [Program] button to select the desired program.
• Press the [Drying level] button to select the desired drying level.
• Press the [Anti-crease] button to activate the Anti-crease function.
• Press the [Start/Pause] button.
• To activate the childproof function, press the [Programme] and [Drying level]
buttons simultaneously for 3 seconds.
• The tumble dryer will sound an audible alarm when the cycle is complete. Press
the [ON/OFF] button and unplug the power cord.
• Clean the filter, body and drum.
• This symbol is associated with the energy efficiency of the standard cotton
programme. This is best suited for drying standard cotton textiles loaded to capacity.
4
6
Side panel
7
Drum hatch
8
Switch
9 Power cord
10
Hose
EN
B
Using the appliance
Installation
• The dryer should be installed in a ventilated environment, at least 10 cm from the wall.
There should be no obstacles within 1.5 m of the front of the dryer. The room must also be
properly ventilated.
Horizontal adjustment:
Attach a weight to a string at the front and sides of the machine. Refer to the illustration
below. If distance A=A' and distance B=B', the dryer is installed horizontally. If this is not the
case, place a wedge on the floor.
NOTE
If the dryer cannot be installed horizontally (inclination greater than 2°), it will
operate unbalanced and intermittently.
WARNING
• Do not install the device outdoors or in an environment exposed to rain;
• Make sure that the back of the unit is not near a curtain or anything else which
may blow in the wind;
• Do not install the appliance near a gas source or flammable area.
5 EN
