4.2.2 Output routing in 2-CHANNEL mode
® ®
T7ÃPˆ‡ 6hy‚tÃPˆ‡ 8‚h‘Pƒ‡ÃPˆ‡
## #'ÃxC“
High-Speed Mode (480 Mbit/s)
1 Main Out 1/L
Digital Out L
2 Main Out 2/R
Digital Out R
3 Analog Out 3
4 Analog Out 4
5 Analog Out 5
6 Analog Out 6
7 -
Digital Out L
8 -
Digital Out R
Full-Speed Mode (12 Mbit/s)
Main Out 1/L
1
Digital Out L
Analog Out 5
Main Out 2/R
2
Digital Out R
Analog Out 6
3 Analog Out 3
Digital Out L
4 Analog Out 4
Digital Out R
1) Sw itchable betw een USB Outs 1-2 and USB Outs 7-8
(High-Speed Mode) via button 23. Format selection (AES/EBU
or S/PDIF) via control panel software.
2) Sw itchable betw een USB Outs 1-2 and USB Outs 3-4 (Full-
Speed Mode) via button 23. Format selection (AES/EBU or
S/PDIF) via control panel software.
