INSTRUCTION MANUAL
INSTRUCTION MANUAL
Designed and Manufactured by
Designed and Manufactured by
ITEC Tontechnik und
ITEC Tontechnik und
Industrieelektronik GesmbH
Industrieelektronik GesmbH
8200 Laßnitzthal 300
8200 Laßnitzthal 300
Austria / Europe
Austria / Europe
1
1
1
1
1
1
1
1
1
1
1
TWIN-BOX
TWIN-BOX
TWIN-BOX_EN_2019/10_REV_2021/0
TWIN-BOX_EN_2019/10_REV_2021/03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TWIN-BOX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Itec TWIN-BOX

Summary of Contents for Itec TWIN-BOX

  • Page 1 TWIN-BOX TWIN-BOX INSTRUCTION MANUAL INSTRUCTION MANUAL Designed and Manufactured by Designed and Manufactured by ITEC Tontechnik und ITEC Tontechnik und Industrieelektronik GesmbH Industrieelektronik GesmbH 8200 Laßnitzthal 300 8200 Laßnitzthal 300 Austria / Europe Austria / Europe TWIN-BOX_EN_2019/10_REV_2021/03 TWIN-BOX_EN_2019/10_REV_2021/0...
  • Page 2 The TWIN-BOX offers two possibilities of sound distribution: 1. In two directions - to the front and to the rear: carry the TWIN-BOX with the shoulder strap and use it to expose a group of people to sound.

  • Page 3: Table Of Contents

    TWIN-BOX INHALTSVERZEICHNIS the twist how to wear the TWIN-BOX how to stand the TWIN-BOX how to start using a cable microphone playback using a radio microphone music attenuation - optional recording connecting an external amplifi er connecting a passive speaker - optional...

  • Page 4: The Twist

    2. how to wear the TWIN-BOX simply click the carrying strap shut in the 2 strap eyes on the top side of the TWIN-BOX. Wear it over your shoulder, one speaker facing the front, the other one the rear. Make sure the controls point outward for your easy and quick access.

  • Page 5: How To Start

    TWIN-BOX is connected (socket 10) to the mains supply (220V), the red mains indicator (3) will show in addition to the indicator light (2). As soon as you switch off the TWIN-BOX the battery will start recharging immediately with the mains indicator light (3) staying on and the indicator light (2) disappearing (see 12.

  • Page 6: Using A Radio Microphone

    Using WM-716, WM-802 or TOA: this is the case when the green LED light shows; when the red LED light shows the batteries should be replaced. see 12. recharging the TWIN-BOX 8. music attenuation (optional) should your device have an automatic music attenuation the volume of the music playback will be turned down while somebody is speaking.

  • Page 7: Recording

    5°C recharge after use not having used the TWIN-BOX for months we recommend you switch it on for several hours and then recharge it. www.itec-audio.com TWIN-BOX_EN_2019/10_REV_2021/03...

  • Page 8: General Advice

    TWIN-BOX 13. general advice • do not place microphones and speakers close to each other in order to avoid acoustic feedback; too great a distance, on the other hand, between microphone and speaker has an unnatural effect on the audience (the sound, bear in mind, does not come from the person speaking) and makes speaking more diffi...

  • Page 9: Changing Batteries Of Radio Microphones

    Note the poles (- pole at spring contact, left)! Battery type: 2 „AA“ 1.5V Mignon Battery status on display. Hereby ITEC Tontechnik und Industrieelektronik GmbH declares that these radio systems comply with the directive 2014/53/EU. The EU Declaration of Conformity for each product is available at https://www.itec-audio.com/products/itec-microphones-and-conference-technology/.

  • Page 10: The Integrated Usb-Player/Recorder - Optional

    TWIN-BOX 17. The integrated USB-Player (optional) You can connect USB storage media to the USB port ( 4 ). For playback only fi les in .mp3 format can be used! Important: Please only use high-quality USB sticks of reputable manufacturers.

  • Page 11: The Integrated Bluetooth Receiver - Optional

    TWIN-BOX Previous title Start / Pause Next title Previous title Previous folder / Next folder Stop Next title Playback mode Record Stop USB port Delete Record Mute Playback mode Direct song selection A-B playback Switch USB/SD Volume control 18. BLUETOOTH (optional) - Switch on the Bluetooth receiver on the box (14).
  • Page 12 Microphone connector, symmetrical, combinational XLR/jack plug, 12 V phantom power Line input Stereo-cinch socket Line out Stereo-cinch socket for recording devices All information without guarantee. Subject to technical changes. ITEC- Tontechnik und Industrieelektronik GesmbH, A-8200 Gleisdorf, Lassnitzthal 300 Tel.: +43 (0)3133 / 3780-0, offi ce@itec-audio.com, www.itec-audio.com TWIN-BOX_EN_2019/10_REV_2021/03...
