Features

Feature / Specification
Cellular Capabilities
Internet Protocols
LTE CAT M1 Specifications
LTE CAT NB2 Specifications
SIM
Cellular Certifications
GNSS Specifications
Power Supply
support@embeddedplanet.com
Description
Cellular Technologies: LTE-M (LTE CAT M1), LTE CAT NB2
SMS: over NAS
Lower power modes: PSM, eDRX
Operating frequencies: 699MHz to 1980MHz
Cellular Operating Mode: Half-duplex FDD
RF Output Power: up to +20dBm (Power Class 5)
IPv4/IPv6 stack with TCP and UDP protocols
TLDS/DTLS
Bands: B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B26, B27,
B28, B66, B71, B85
RX Sensitivity CAT M1: -102.2 to -107.5 dBm depending on band
Uplink: up to 1Mbps
Downlink: up to 588kbps
Bands: B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B26, B27,
B28, B66, B71, B85
RX Sensitivity CAT NB2: -111.3 to -115.8dBm depending on band
Uplink: up to 160kbps
Downlink: up to 120kbps
Removable: 4FF (nano) SIM card slot
Soldered down: MFF2
Internal: Telit simWISE™
PTCRB: Complete
AT&T: In Progress
Verizon: In Progress
Constellations: GPS, GLONASS, BeiDou, Galileo, QZSS
Tracking Sensitivity: -159dBm
Navigation Sensitivity: -155dBm
Cold Start Sensitivity: -144dBm
Main Power Supply: 3.4Vdc to 4.2Vdc (3.8Vdc nominal)
GPIO Reference Voltage: 1.65Vdc to 5.5Vdc
