6.2 Castellated Pins
The diagram below shows the top side of Chronos:
Pin #
Pin Name
1
DVI_WA0
2
DVI_RX
3
DVI_TX
4
DVI_CLK
5
Vcell
6
DOUT
7
DIN
8
GND
9
RSVD
10
IO3
11
IO4
12
VUSB
13
USB_DP
14
USB_DN
support@embeddedplanet.com
Pin Type
Description
Digital I/O
Digital audio
Digital output
Digital audio
Digital input
Digital audio
Digital I/O
Digital audio
Power input
Main power supply
input
Digital output
Main UART data
output from cell
module
Digital input
Main UART data
input to cell module
n/a
GND
n/a
Reserved for future
use
Digital I/O
GPIO
Digital I/O
GPIO
Analog input
USB power sense
Digital I/O
USB data (+)
Digital I/O
USB data (-)
| 4760 Richmond Road Suite 400 Cleveland, OH 44128 | (216) 245-4180
Copyright © 2020 Embedded Planet, Inc. All Rights Reserved.
User Manual | Chronos
If not used
Leave open
Leave open
Leave open
Leave open
Must be
implemented
Leave open
Leave open
Must be
implemented
Leave open
Leave open
Leave open
Leave open
Leave open
Leave open
Notes
Do not connect
pin
page 9
