6.6 GNSS Antenna Requirements
An active GNSS antenna must be used. The antenna must meet or exceed the following requirements:
Frequency Range
Gain
Impedance
Noise Figure of LNA
DC supply voltage
VSWR recommended
6.7 Recommended GNSS Antennae
The general recommendation is to use a wide-band LTE antenna with acceptable efficiency across
applicable bands. The table below has examples of several LTE antennae that are compatible with
Chronos.
Type
Manufacturer Part Number
Internal adhesive
Taoglas
support@embeddedplanet.com
1559 – 1610MHz
15 – 30dB
50Ω
<1.5 recommended
1.8 – 3.3Vdc
≤ 3:1
AP.12F.07.0045A Antenna has U.FL connector
| 4760 Richmond Road Suite 400 Cleveland, OH 44128 | (216) 245-4180
Copyright © 2020 Embedded Planet, Inc. All Rights Reserved.
User Manual | Chronos
