Stand-alone gigabit ethernet poe media converter. power over ethernet poe, 10/100/1000mbps, rj45 to duplex lc sfp, 850nm wavelength, 550 meter distance. (20 pages)
Summary of Contents for DMSI 10
Page 1
10 / 100 / 1000 Ethernet Media Converter Series 10 / 100 / 1000 mbps You can also find the manual online at: You can also find the manual online at: www.dmsimfg.com/StandAloneManual www.dmsimfg.com/StandAloneManual www.dmsimfg.com www.dmsimfg.com...
CONTENT Overview Introduction Cables Specifications Packing List Safety Precaution Hardware Description Front Panel Back Panel LED Indicators DIP Switch Fiber Port Cabling Network Connection Installation Troubleshooting You can also find the manual online at: www.dmsimfg.com/StandAloneManual www.dmsimfg.com...
OVERVIEW INTRODUCTION DMSI’s 10/100 and 10/100/1000 stand-alone ethernet media converters are an efficient and adaptable solution in the field of LAN campus networking. It mediates between a 10, 100, or 1000Base- TX segment, and a 1000Base-FX segment. Gigabit converters can extend the conventional 10M or 100/1000M fast ethernet out to 20km-120km via the fast ethernet fiber-optical line. It is primarily designed for large, higher speed/bandwidth demanding work group.
0°C~50°C (32°F ~ 122°F) Environmental Storage Temperature -40°C~70°C (-40°F ~ 158°F) Parameters Humidit 5%~90% non-condensing UTP Cable Cat 5e, 6, 6A UTP or STP cable 8.3/125μm, 8.7/125μm, 9/125,μm, Single-mode 10/125μm (the max distance up to Cable 20 -120km) 50/125μm, 62.5/125μm Multimode (the max distance up to 2km or 5km) Dimensions (mm) 95mm(L) x 71.5mm(W) x25.4mm(H) Warranty 3 years...
OVERVIEW PACKING LIST 1 - 10/100/1000 Media Conveter 1 - SFP (Optional) 1 - 10 / 100 / 1000 Stand Alone Media Converter Manual 1 - Power Supply SAFETY PRECAUTION Attention! If DC voltage is supplied by an external circuit, please use a protection device on the power supply input. You can also find the manual online at: www.dmsimfg.com/StandAloneManual...
HARDWARE DESCRIPTION FRONT PANEL RJ-45 Port Duplex LC SFP LED Indicators BACK PANEL DIP Switch Power Supply Port You can also find the manual online at: www.dmsimfg.com/StandAloneManual www.dmsimfg.com...
HARDWARE DESCRIPTION LED Indicators LED INDICATOR STATUS EXPLANATION LAMP FX connection is good. Blink FX data is transmitting. Connection status display for electric link. “ON” indicates that electric link is in correct connection. Link/Act Active status display of fiber link Blink “Blink” indicates packet goes through Tx end. Transceiver works in the full duplex mode. Transceiver works in the half duplex mode. Power is on and normal.
HARDWARE DESCRIPTION DIP Switch The DIP switch is used to configure operation mode for LLF (Link Loss Forwarding) and operation mode for UTP/Fiber port. The default value of DIP switch is OFF. Stand-by Mode Enable LFP Disable LFP Cut-through(9K) Store-and-Forward traffic control on traffic control off FX speed is 100Mbps. FX speed is 1000Mbps. You can also find the manual online at: www.dmsimfg.com/StandAloneManual www.dmsimfg.com...
Page 9
HARDWARE DESCRIPTION DIP Switch LFP (link fault pass through) means the link fault on local side media converter will be passed to the media converter on the remote side. For instance if the media converter on the local side has the TP link loss, the media converter will disconnect the link of transmit on fiber. On the remote side, the media converter will know there is the linkage error and also disconnect the TP link.
Page 10
HARDWARE DESCRIPTION DIP Switch Cut-through(9K) Store-and-Forward traffic control on traffic control off FX speed is 100Mbps. FX speed is 1000Mbps. You can also find the manual online at: www.dmsimfg.com/StandAloneManual www.dmsimfg.com...
HARDWARE DESCRIPTION Fiber Port When you connect the fiber port to another one, please follow the figure below to connect accordingly. Wrong connection will cause the port to work incorrectly. Cable Wiring (LC to LC) Tx A ---------------------------- A Rx Tx B ---------------------------- B Rx You can also find the manual online at: www.dmsimfg.com/StandAloneManual www.dmsimfg.com...
HARDWARE DESCRIPTION Cabling Twisted-pair segments can be connected with unshielded twisted pair (UTP) or shielded twisted pair (STP) cable. The cable must comply with the IEEE 802.3u 1000Base TX standard for Category 5. The cable between the converter and the link partner (converter, switch, hub, workstation, etc.) must be less than 100 meters (328 ft.) long.
NETWORK CONNECTION LC to LC Multimode Fiber up to 550M 10/100/1000 Mbps port (RJ-45 Connector) at switch or end station You can also find the manual online at: www.dmsimfg.com/StandAloneManual www.dmsimfg.com...
NETWORK CONNECTION Installation 1. Turn on the power supply of the converter. 2. Connect local RX to remote TX via optical fiber when local FPL indicator lights up. 3. Connect local TX to remote RX when both local and remote FRX, and FPL indicators light up. 4. If its a single-fiber converter, connect the optical fiber. 5. Turn on the power supply of the connected Ethernet devices. 6.
NETWORK CONNECTION Troubleshooting 1. Verify that you are using the right power cord/adapter (48- 52VDC). Please don’t use a power adapter with DC output higher than the power input range as above or it may damage the device. 2. Select the proper UTP or STP cable to construct your network based on your bandwidth and performance requirements. Also, be sure that the length of any twisted-pair connection does not exceed 100 meters (328 feet).
Page 16
Diversified Materials Specialist, Inc (DMSI) 105 Triple Diamond Blvd. Unit 101 Venice, FL 34275 Info@dmsimfg.com 941-244-0935 www.dmsimfg.com You can also find the manual online at: www.dmsimfg.com/StandAloneManual You can also find the manual online at: www.dmsimfg.com/StandAloneManual www.dmsimfg.com...
