Next 892041 Assembly Instructions Manual

Mode wall unit

Advertisement

Quick Links

IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.

Tools Needed

Helpline

If you have any problems with this product or require
any replacement fittings please contact Customer
Services Tel: 0333 777 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found
to be faulty. Should you need to return the unassembled product, please repack in the original packaging.

IMPORTANT

IMPORTANT
• We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step
instructions.
• Carefully check that you have all parts before beginning assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of two persons is required to assemble this product.
• The maximum weight this unit can hold safely is 20 kg.

PRODUCT INFORMATION

• Made from partical board with a wood effect finish.
• Made in China.

CARE INSTRUCTIONS

• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Do not use furniture polish.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent
scratching or damage.
• Do not put hot dishes directly on the surfaces of the item.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration or
warping.
• All assembly fixings should always be tightened properly and periodically check all fixings and tighten if necessary.
• Please do not apply adhesive substrates for example , sticky tape to the product.
892041 MODE WALL UNIT
892041 MODE WALL UNIT
892041 MODE WALL UNIT
892041 MODE WALL UNIT
ASSEMBLY INSTRUCTIONS.
Page 1 of 6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 892041 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Next 892041

  • Page 1 892041 MODE WALL UNIT 892041 MODE WALL UNIT 892041 MODE WALL UNIT 892041 MODE WALL UNIT ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require...
  • Page 2 FITTINGS PARTS STEP ONE 1. Insert 16 x cambolts (E) into panels 1 & 2 and tighten with a screwdriver. Page 2 of 6...
  • Page 3 STEP TWO 1. Glue and insert 4 x wooden dowels (B) into panel 3 and attach panels 5 & 7 to panel 3. STEP THREE 1. Glue and insert 2 x wooden dowels (A) into panels panels 5 & 7 . 2.
  • Page 4 STEP FIVE 1. Glue and insert 4 x wooden dowels (A) into panels panels 5 , 7 & 6 (x2) . 2. Glue and insert 3 x wooden dowels (B) into panel 3 and attach panel 1 to panels 5 , 7 & 6 (x2) 3.
  • Page 5 STEP TEN 1. Use the template (M) provided to mark on the wall the position of the fixings. NB: Place the template over the back of the wall unit to ensure that the holes match the position of the hooks before drilling into your wall 2.
  • Page 6 Check the wall unit periodically to see that no fitting has loosened and needs attention. Next Retail Ltd, Desford Road, Leicester, LE19 4AT Next Retail Ltd, Desford Road, Leicester, LE19 4AT Page 6 of 6...
