Specifications
Fuselage length: 932mm(36.7in)
Wingspan: 836mm(32.9in)
Flying Weight: 110-130g(with battery)
Additional Required Equipment
Motor:1804-2204
ESC: 6A
Propeller: 8043
Aileron Servo: 8-9g
rudder servo and elevator servo: 4-5g
Radio:4/more channel
Receiver: 4/more channel
Battery charger
Battery: 7.4V 200 mAh -400mAh Li-po
Advantage Points
•Perfect covering technology with flat polyester film
•Lighter hollow structure with same strength as not hollowed plane
•Genuine 3mm Depron Aero from Europe for best flight performance
•Lightweight carbon fiber truss system virtually eliminates flex
•Minimal assembly required flight ready in as little as 2 hours
•Gorgeous and vibrant printed pattern
Introduction
Thank you for purchasing the Dolphin Covering. On the base of Dolphin
Depron-aero we developed an advanced version with more lighter but same
strong structure, it's covering version. In order to avoid wrinkled film we use an
electrostatic technology to let the film cover on the depron's surface flatly and
tightly, so you needn't worry that the film will drone or bring resistance during the
Dolphin Covering
Instruction Manual
flight. You just enjoy it with the light and beautiful plane.
The assembly instruction can help to assemble your new airplane in the shortest
possible time. You can get many basic tips from assembling a new Plane. Please
assemble the model according to the instructions as below.
Required Tools and Adhesives
(not included in the kit)
5 Minute Epoxy Resin
Depron Friendly Glue
Uhu Por
#0 and #1 Phillips Head Screwdrivers
1.5 mm Hex Wrench
Adjustable Wrench
Wire Cutters
Z-Bend Pliers
Needle Nose Pliers
Modeling Knife
Scissors
Electric or Hand Drill
Assorted Drill Bits
Straight Edge Ruler
Pencil
Builder's Triangle
220 Grit Sandpaper with Sanding Block
Masking Tape
Paper Towels
Rubbing Alcohol
Epoxy Mixing Sticks
Epoxy Mixing Cups
Pluswing Series
Advertisement
Related Manuals for Flyrace Pluswing Series
Summary of Contents for Flyrace Pluswing Series
- Page 1 Pluswing Series Dolphin Covering Instruction Manual Specifications flight. You just enjoy it with the light and beautiful plane. The assembly instruction can help to assemble your new airplane in the shortest Fuselage length: 932mm(36.7in) possible time. You can get many basic tips from assembling a new Plane. Please Wingspan: 836mm(32.9in)
- Page 2 Kit Contents 1.Body parts included in the packing A.Wing, Aileron, winglet B.Fuselage C.Horizontal stabilizer D.Side fuselage E.Nose of the fuselage F.Vertical stabilizer G.Wheel covers H.Wing reinforcing strips I.Round doublers 2. Parts included in the packing A. Quadrate and round doublers B.
- Page 3 Instruction Steps 1.Glue the front edge stay bar onto the front edge of the wing. 2.Insert the carbon fiber strip into the pre-cut hole on the horizontal stabilizer. 3.Fix the side fuselage and nose onto the wing with some foam friendly C/A, 4.Fix the lower vertical fuselage onto the horizontal fuselage with then fix the horizontal stabilizer onto the fuselage.
- Page 4 8.Fix the other stay bars on the fuselage as shown in the picture. 7.Fix the stay bars on the nose, and then put the other side of stay bars through the base. 9.Place aileron servo into pre-cut servo hole on fuselage, then use 10.Fix the control horns into the pre-cut slots on the aileron with some screwdriver to install aileron servo arm, at last put the aileron onto the friendly C/A.
- Page 5 13.Glue the tail fin on the end of lower vertical fuselage. 14.Fix the rudder servo with some foam friendly C/A, and then fix the arm on the servo. 15.Fix the elevator servo with some foam friendly C/A, and then fix the 16.Glue the upper vertical fuselage onto the horizontal fuselage with arm on the servo.
- Page 6 20.Fix the control horns into the pre-cut slots on the vertical and horizontal 19.Fix the vertical stabilizer onto the fuselage with glass fiber tape. stabilizer with some friendly C/A. 21.Pass the thread through the elevator servo arm, fix it with some glue, 22.If the thread is not tight, you can use the adjustor to adjust.
- Page 7 25.Install the motor with the tapping screw, and then fix the propeller with the O-ring. 26.Install the ESC, receiver and battery with Velcro.
- Page 8 R/C pilots who would be willing to help you with your first few flights. Although this is an ARF(Almost- Ready-to-Fly)kit, it does have some construction features that can be challenging to the less experienced modeler. Copyright 2011 Flyrace® If you encounter difficulty in any construction sequence, please feel free to contact one of our technicians, we stand WWW.FLYRACE.COM...
