Summary of Contents for Dixon D26KH54
- Page 1 REPAIR PARTS MANUAL MODEL NO. D (96041018400) GARDEN TRACTOR 532 43 69-44...
-
Page 2: Table Of Contents
The model number for your tractor can be found on the fender under the seat. When ordering parts, always give the following information: • Product - “Tractor” • MODEL NUMBER - “D26KH54 (96041018400)” • Part Number • Part Description TABLE OF CONTENTS SCHEMATIC ........................ -
Page 3: Schematic
TRACTOR - - MODEL NO. D26KH54 (96041018400), PRODUCT NO. 960 41 01-84 SCHEMATIC SCH15 BATTERY SOLENOID STARTER FUSE AMMETER BLACK (OPTIONAL) ELECTRIC LIFT SWITCH CONNECTOR WHITE PTO SWITCH BLACK WHITE (DISENGAGED) ELECTRIC CLUTCH WHITE GRAY CLUTCH/BRAKE CHASSIS (PEDAL UP) BLUE... -
Page 4: Electrical
TRACTOR - - MODEL NO. D26KH54 (96041018400), PRODUCT NO. 960 41 01-84 ELECTRICAL T23S... - Page 5 TRACTOR - - MODEL NO. D26KH54 (96041018400), PRODUCT NO. 960 41 01-84 ELECTRICAL PART DESCRIPTION 532 16 34-65 Battery 874 76 04-12 Bolt Hex Head 1/4-20 x 3/4 532 18 64-91 Box Battery 532 17 61-38 Switch Interlock Push-In 532 17 56-88 Harness Socket Light w/4152J...
-
Page 6: Chassis
TRACTOR - - MODEL NO. D26KH54 (96041018400), PRODUCT NO. 960 41 01-84 CHASSIS chassis-tex_stealth pl_8_r1... - Page 7 TRACTOR - - MODEL NO. D26KH54 (96041018400), PRODUCT NO. 960 41 01-84 CHASSIS PART DESCRIPTION 532 43 63-68 Dash 532 42 63-64 Hood 532 16 18-41 Lens LH 532 18 71-14 Grille 532 16 18-42 Lens RH 532 19 61-25 Plate Engine...
-
Page 8: Drive
TRACTOR - - MODEL NO. D26KH54 (96041018400), PRODUCT NO. 960 41 01-84 DRIVE Drive-tex_K66_pedal_2_r3... - Page 9 TRACTOR - - MODEL NO. D26KH54 (96041018400), PRODUCT NO. 960 41 01-84 DRIVE PART PART DESCRIPTION DESCRIPTION - - - - - - - Transaxle, TuffTorq K66Y 532 19 43-22 Keeper Belt Centerspan 532 00 70-70 Key 872 11 06-16 Bolt...
-
Page 10: Engine
TRACTOR - - MODEL NO. D26KH54 (96041018400), PRODUCT NO. 960 41 01-84 ENGINE SPARK ARRESTER KIT engine-tex_Kawa-2cyl_6... - Page 11 TRACTOR - - MODEL NO. D26KH54 (96041018400), PRODUCT NO. 960 41 01-84 ENGINE PART DESCRIPTION - - - - - - - Engine Kawa Model No. FR730V-AS04 532 14 97-23 Muffler 532 19 43-20 Keeper Asm. Belt Engine 532 17 93-35 Clutch Electric...
-
Page 12: Steering
TRACTOR - - MODEL NO. D26KH54 (96041018400), PRODUCT NO. 960 41 01-84 STEERING ASSEMBLY 53 8 steering-tex_LEGND2_6_r1 PART PART DESCRIPTION DESCRIPTION 532 42 41-46 Wheel, Steering 819 11 38-12 Washer 11/32 10 x 2 3/8 00 x 12 Ga. 532 19 59-68 Axle Asm., Front 873 94 08-00 Nut Hex Jam Toplock 1/2-20 unf 532 40 30-89 Spindle Asm., LH... -
Page 13: Seat
TRACTOR - - MODEL NO. D26KH54 (96041018400), PRODUCT NO. 960 41 01-84 SEAT ASSEMBLY seat-tex_6.5SL_2 PART PART DESCRIPTION DESCRIPTION 873 80 05-00 Nut, Lock 5/16-18 unc 532 43 14-50 Seat 532 19 76-61 Handle Slide Seat 532 18 01-66 Bracket Pivot Fender... -
Page 14: Mower Deck
TRACTOR - - MODEL NO. D26KH54 (96041018400), PRODUCT NO. 960 41 01-84 MOWER DECK mower_deck 54-tex_18_r2... - Page 15 TRACTOR - - MODEL NO. D26KH54 (96041018400), PRODUCT NO. 960 41 01-84 MOWER DECK PART PART DESCRIPTION DESCRIPTION 532 18 73-44 Baffle Left 532 43 63-76 Deck Weldment Mower 532 18 76-07 Baffle Center 532 19 60-66 Cover Mandrel LH...
-
Page 16: Mower Lift
TRACTOR - - MODEL NO. D26KH54 (96041018400), PRODUCT NO. 960 41 01-84 MOWER LIFT lift-tex_elec_2 PART PART DESCRIPTION DESCRIPTION 532 42 20-27 Shaft Asm., Lift 532 42 17-69 Actuator Decklift 532 41 94-96 Rod Indicator Lift Electric 532 12 68-75 Rivet Drilled 1/4 Dia. -
Page 17: Decals
TRACTOR - - MODEL NO. D26KH54 (96041018400), PRODUCT NO. 960 41 01-84 DECALS PART PART DESCRIPTION DESCRIPTION 532 17 83-02 Decal, Operator Cruise Control 532 19 68-41 Decal, Warning Engine Symbols 532 12 44-33 Decal, DBA 521 97 17-01 Decal, Logo... - Page 18 SERVICE NOTES...
-
Page 20: Warranty
LIMITED WARRANTY The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in materi- als and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we find to be defective due to materials or workmanship.
