AC current clamp-on tester
M-1141/ M-1141X/ M-1141XR
Instruction Manual (English)
Thank you very much for selecting our digital AC current clamp-on tester.
This model is complex instrument and employ a very reliable mechanical design.
Before using your new instrument, read this Instruction Manual completely and
familiarize yourself thoroughly with all functions.
With proper use and care, your tester will give you years of satisfactory service.
MULTI MEASURING INSTRUMENTS CO., LTD.
Address; Akihabara Murai Building 7-F,
1-26 Kanda Sakuma-cho, Chiyoda-ku,
Tokyo, 101-0025, JAPAN
Tel; +81-3-3251-7016
Fax; +81-3-3253-4278
Webpage; www.multimic.com/e
AFTER-SALE SERVICE
1 / 15
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Multi M-1141
Summary of Contents for Multi M-1141
- Page 1 Before using your new instrument, read this Instruction Manual completely and familiarize yourself thoroughly with all functions. With proper use and care, your tester will give you years of satisfactory service. MULTI MEASURING INSTRUMENTS CO., LTD. Address; Akihabara Murai Building 7-F, 1-26 Kanda Sakuma-cho, Chiyoda-ku, Tokyo, 101-0025, JAPAN Tel;...
-
Page 2: Warranty
When the instrument failed, contact your dealer or distributor. When sending the instrument for repair, wrap the instrument in cushioning material, store it in a sturdy box, and send it to us with the following information. 1. Customer's name, address, and telephone number 2. - Page 3 Trademarks (TM, (R) mark, etc. are not specified in this manual.) • Bluetooth is a trademark of Bluetooth SIG,Inc. Multi Measuring Instruments Co., Ltd. uses it under a license agreement with the company. • Android and Google Play are trademarks of Google LLC •...
- Page 4 • This instrument has a Bluetooth communication function. It communicates with a smartphone / tablet with the dedicated application "Multi-Tracer" installed, and can display measured values or save them on a server. (Only applicable with M-...
-
Page 5: Performance Specification
*0 (zero) is displayed for values of 10-counts or less of each range. *Crest factor: <2 *Temperature and Humidity measurement accuracy; reference value *Displayed by Multi Tracer (M 1141XR, M 1141X) GENERAL SPECIFICATIONs Measurement; AC leakage current (Io), AC load current (I) Window Diameter;... - Page 6 RoHS Directive Battery; 1pc of coin-type lithium battery (CR2450) Duration (continuous use) <between 23℃±5°C reference value only> (M-1141) About 36-hours (backlight off) (M-1141X/ M-1141XR) About 30-hours (backlights off/ Bluetooth off) (M-1141X/ M-1141XR) About 16-hours (backlights off/ Bluetooth on) Dimensions; 66(W) x206(H) x35(D) mm (excluding protrusions) Weight;...
-
Page 7: Function Specification
It delays to 30-minutes (during MAX-hold/ Bluetooth is on) Bluetooth communication (Bluetooth 4.2) *only on M-1141X and M-1141XR; Press “Bluetooth” switch to transfer a displayed value to Multi-Tracer (smart- phone application) Multi-Tracer displays simple waveform on the smartphone connected via Bluetooth. - Page 8 smartphone connected via Bluetooth. 8 / 15...
- Page 9 "Multi-Tracer". (While waiting for Bluetooth pairing, M-1141X/ M-1141XR) To cut-off the pairing. (While Bluetooth is on) To transfer a displayed value to the dedicated “Multi-Tracer” By pressing and holding for 1-second, it turns on/off the backlight. (5) Liquid Crystal Display (LCD);...
-
Page 10: Description Of Display
~/ AC mark; (upper LCD) blinks during MAX-hold (lower LCD) lights always while power-on RMS mark (M-1141XR)/ True-RMS indicator; lights always on while power-on AVG mark (M-1141/ M-1141X)/ average value rectification; lights always on 10 / 15... - Page 11 Battery Replacement (1) Make sure the power is turned off, then remove the battery-cover screw on the back with a Phillips screwdriver, and remove the battery cover. (2) Pull the coin-battery out, and insert new battery. *Check the battery polarity marks displayed on the battery case.
- Page 12 MEASUREMENTS (1) Press “Power” button② to power-on (2) It starts with AUTO-range. To change the range to manual, press “Range” button⑦ *Ranges change as AUTO→ 30mA→ 300mA→ 3A→ 30A→ 300A→ AUTO→ ….. (3) Open CT and clamp a target conductor wire. Close the clamp properly. For AC load currents measurements;...
- Page 13 (5) Using the filter function; Automatically starts when the power is turned on and display FL on the LCD to activate filter-mode. Press it again to turn-off. (Filter specification; Band pass filter fo=55Hz) (6) Using the data hold function; Press "DH / MAX" button③ once and display DH on the LCD.
-
Page 14: Bluetooth Function
“Multi-Tracer”, the Bluetooth function is automatically turns-off. After about 30-minutes with no switch operation, the auto power-off function works.) *If your mobile device is an iPhone, iPad, etc., download “Multi-Tracer” from the App Store, and install. For Android devices, download “Multi-Tracer” from Google Play and install. - Page 15 Name of Model; AC currents clamp tester Model Number; M-1141/ M-1141X/ M-1141XR Confirmed Accuracy; Range: Accuracy (23.5 ℃, 85% RH or less, no condensation) 30mA ±1.2%rdg±5dgt...
