- Page 1 TuBAR Retrofit for ® Dresser Wayne Ovation Receipt Door Copyright © 2009 CompX Security Products. Any companies and/or products referred to herein are marks or registered trademarks of their respective companies owners and/or mark holders.
- Page 2 TuBAR Receipt Door ® Retrofit: Ovation Part # DWC-ORD-1 A. TuBAR Lock ® B. Gasket C.Cam Adapter D.Cam E. Cam Nut F. Drill & Mounting Template G.Lock Washer H.Cylinder Nut...
- Page 3 TuBAR Receipt Door ® Retrofit: Ovation Part # DWC-ORD-1 1. Use Drill Template (F) to drill Ø3/16” pilot hole in Door by placing template in upper corner of receipt door interior. Align template against door frame with rounded corners positioned as shown.
- Page 4 TuBAR Receipt Door ® Retrofit: Ovation Part # DWC-ORD-1 2. Drill Ø3/4” hole through pilot hole.
- Page 5 TuBAR Receipt Door ® Retrofit: Ovation Part # DWC-ORD-1 3. Install Lock A through Gasket B and into Ø3/4 hole in door. Orientation mark on lock face to left.
- Page 6 TuBAR Receipt Door ® Retrofit: Ovation Part # DWC-ORD-1 4. Install Mounting Plate F and Retaining Washer G over Lock and secure with Cylinder Nut H Mounting Plate is required to prevent entire Lock from rotating...
- Page 7 TuBAR Receipt Door ® Retrofit: Ovation Part # DWC-ORD-1 5. Install Cam Adapter C, Cam D, and Cam Nut E on back of Lock...
- Page 8 TuBAR Receipt Door ® Retrofit: Ovation Part # DWC-ORD-1 6. Optional – Remove or reposition cam on existing lock to disable. Leave lock in place to fill hole.
