Product specifications
Specifications
Mains input
Power rating (VA)
Fuse (front panel)
Output range (V)
Max current (A)
Thermal trip/reset
Temperature &
humidity limits
Dimensions (mm)
Mass (kg)
Similar to UNILAB
Applications
Locking mechanisms
NOTE: AC and DC are NOT available simultaneously.
Retro Basic
230V ac 50Hz
80
T1A (time delay)
2,4,6,9,12 AC or DC
Unsmoothed
4
Yes
-5 to 50°C
10 to 90% RH
290 x165 x 165
4.1
022.104
Basic power supply for
ray boxes, simple
circuits, heaters and
electrolysis.
Retro Ranger
230V ac 50Hz
242
T2A
0-15 AC & 0-20 DC
Smoothed by 4700µF
8 total AC + DC
Yes
-5 to 50°C
10 to 90% RH
290 x165 x 165
5.6
022.106
Higher power for
halogen lamps, heaters
and for basic general
use.
Basic and Regulated
A hexagon key is used to turn the locking
screws. Turn any screw anticlockwise until it
just stops. It protrudes from the front panel
and blocks rotation of the control knob.
The screws are captive.
Using a single screw, an upper limit can be set.
Using two screws, a fixed voltage can be set, by
trapping the pointer.
Similarly, it is also possible to lock the power
supply to AC or DC only (Basic).
Retro Regulated
230V ac 50Hz
108
T1A
2,4,6,9,12 DC only
Regulated
4
Yes
-5 to 50°C
10 to 90% RH
290 x165 x 165
4.3
None
Regulated supply for
quantitative circuit
work, e.g. Ohm's law,
datalogging.
