QUICK
SCREEN
COMPLETE KIT READY TO GO
• Height and width adjustable
Cut to desired size
• Slat spacing easily adjusted
Spacer blocks included
• Clean finish
Screw fixings hidden by snap on cover
QUICKSCREEN RANGE:
1800mm W x 1200mm H
Complete Kit
Includes: 2x side frames with snap-on cover, 16x 65mm
slats, 2x top caps, spacer blocks & screws
Full Post
Base Plate Set
1800mm or 2400mm
4x screws included
Includes free top cap
Suits standard full posts
See code list below for
See code list below for
order codes
order codes
COLOURS:
Australian Interpon Powder Coat
Black
GN150A
Woodland
grey
GL205A
See code list below
for order codes
Dress Ring
Fits over full post
Must be special ordered by
customer
ORDER CODES:
QUICKSCREEN KITS:
HB-4589 (1800x1200 kit - black)
HB-4590 (1800x1200 kit - primrose)
Primrose
HB-4591 (1800x1200 kit - w/grey)
GD037A
HB-4592 (1800x1200 kit - white)
HB-4593 (2400x1800 kit - black)
White
HB-4594 (2400x1800 kit - primrose)
GA078A
HB-4595 (2400x1800 kit - w/grey)
HB-4596 (2400x1800 kit - white)
SLAT SCRE ENIN G
• Complete kit includes:
65mm aluminium slats, side
frames, snap covers, caps, spacer
blocks & screws
• Easy, quick assembly!
2400mm W x 1800mm H
Complete Kit
Includes: 2x side frames with snap-on cover, 24x 65mm
slats, 1x mid rail, 2x top caps, spacer blocks & screws
Top Cap
Side Frame
For side frame - Nylon
With snap-on cover
See code list below for
See code list below for
order codes
order codes
QUICKSCREEN POSTS
HB-4624 (1800 post - black)
HB-4625 (1800 post - primrose)
HB-4626 (1800 post - W/grey)
HB-4627 (1800 post - white)
HB-4628 (2400 post - black)
HB-4629 (2400 post - primrose)
HB-4630 (2400 post - W/grey)
HB-4631 (2400 post - white)
See code list below
for order codes
Trade tip!
Use side
frames to
create more
screens
2100mm long
with offcuts
or unused
slats from
Quickscreen
packs
ACCESSORIES
HB-4641 (BP set - black)
HB-4642 (BP set - primrose)
HB-4643 (BP set- W/grey)
HB-4644 (BP set - white)
HB-4649 (Side frame - black)
HB-4650 (Side frame - primrose)
HB-4651 (Side frame- W/grey)
HB-4652 (Side frame - white)
