Martin Jerry STD01 User Manual

Hide thumbs Also See for STD01:

Advertisement

Quick Links

Download this manual
User Manual for IOT devices
Part 1 - Installation (STD01)
Check Items before Installation
1. Power off the break
2. Light bulbs are dimmable (If not sure, send us the brand and model of it)
3. Make sure there is a neutral wire for the master switch. If not, the switches cannot work properly. It is in
white and
NOT
Email:
martinjerry01@outlook.com
used by your old switch. You can send us photos of the wires for both 3-way switches.
Neutral

Advertisement

loading
Need help?

Need help?

Do you have a question about the STD01 and is the answer not in the manual?

Questions and answers

Related Manuals for Martin Jerry STD01

Summary of Contents for Martin Jerry STD01

  • Page 1 User Manual for IOT devices Part 1 - Installation (STD01) Check Items before Installation 1. Power off the break 2. Light bulbs are dimmable (If not sure, send us the brand and model of it) 3. Make sure there is a neutral wire for the master switch. If not, the switches cannot work properly. It is in white and used by your old switch.
  • Page 2 User Manual for IOT devices Part 1 - Installation (STD01) FQA: 1. How can I know it is connected correctly? A: Press the on/off button, dim button on both Master and Add-On switch. They should work properly. Indicator lights on the Master Switch can show the brightness of light bulbs.
  • Page 3 User Manual for IOT devices Part 1 - Installation (STD01) Now Wire the two switches according to the diagram below: Tips:  Wires on your old switches are: Switch: Live, TRA1, TRA2 Switch: Load, TRA1, TRA2  TRA-1 & TRA-2 is very easy to identify. Generally 1red, 1black. They come from the same location and both connect to the old switch.
  • Page 4 Part 2 - Download Smart Life App Download the App Step 1: Scan the QR code or search “Smart life” in the App Store or Google Play iPhone: https://itunes.apple.com/us/app/smart-life-smart-living/id1115101477?mt=8 Android: https://play.google.com/store/apps/details?id=com.tuya.smartlife&hl=en_US...
  • Page 5 User Manual for IOT devices Part 2 - Download Smart Life App Register a New Account Step 2: Password must contain 6-20 letters and numbers Register with phone number or email address...
  • Page 6 Part 3 - Wi-Fi Connection READ HERE!!! 1. Confirm that both the Master and Add-on Switch work well manually (ON/OFF, Dim). If not, go back to the wiring part. 2. 2.4G WiFi is available. support 5G (802.11av) Set the Switch to Easy Pairing Mode Step 1: 1.

  • Page 7: All Devices

    User Manual for IOT devices Part 3 - Wi-Fi Connection Step 2: Pair the switch on App 1. Confirm that you have downloaded the right Smart Life App (Same Logo as the right side) If not, download it from the links iPhone: https://itunes.apple.com/us/app/smart-life-smart-living/id1115101477?mt=8 Android:...
  • Page 8 User Manual for IOT devices Part 3 - Wi-Fi Connection Q1: I follow all of the process above, but cannot get the switch connect to the WiFi (2.4G). Any suggestions? A: Please try our AP mode, which is more compatible. If the AP mode fails again, send your App account id to martinjerry01@outlook.com .Our Engineers will check and reply you within 12h.
  • Page 9 User Manual for IOT devices Part 4 - Alexa & Google Home READ HERE!!! 3. It can be controlled by App well when your smart phone is under 3G/4G status (NOT Wi-Fi). If not, check your Wi-Fi router connects to the Internet and pair the switch again. Send us your device virtual id (find in the App) if necessary.
  • Page 10 User Manual for IOT devices Part 4 - Alexa & Google Home Step 3: Enable the skill Step 4: Login the account you registered on the App in Part 2, then click “Link Now” The account and password MUST the same that you registered in the smart life app (Email or Tel) DO NOT input your Alexa account or use...
  • Page 11 User Manual for IOT devices Part 4 - Alexa & Google Home  If you want to delete or add new switches, please delete or add them in the Smart Life App, the Alexa will synchronize automatically.  If you cannot see the name of switches in the Devices List in Alexa Page, you can click “Discover”...
  • Page 12 User Manual for IOT devices Part 4 - Alexa & Google Home Part 4.2: Connect your Smart Switch to Google Home Step 1: Find "Home Control" in the hamburger menu on the Google Home app’s home page -> Home Control -> then tap "+".
  • Page 13 User Manual for IOT devices Part 4 - Alexa & Google Home Step 4: After you assign rooms for devices, your devices will be listed in the Home Control page. Step 5: Control your smart devices through Google Home Now you can control your smart devices through Google Home. If you set the switch name as “bedroom light”, the supported voice commands are as below: Ok Google, turn on bedroom light.
  • Page 14 User Manual for IOT devices FCC Compliance Notice FCC Compliance Notice This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
